The housing is the outer body of the surgical handpiece. Inside it sit the drive coupling, the bearing or bushing that supports the blade shaft, and the internal passage that carries saline and aspirated vitreous. The surgeon grips this tube at roughly 20–40 mm behind the tip, so wall thickness and mass affect how steady the hand feels during a 30-minute case.

Most designs are a stepped tube, 0.9–2.4 mm outer diameter at the cannula end, opening to a 6–12 mm grip body. The blade shaft passes through the full length. Every internal diameter that touches that shaft becomes a functional surface, not a cosmetic one.

That is why vitrectomy cutter housing custom cnc work is judged on bore alignment, not on the outside profile. A housing that looks perfect on a comparator can still fail if the drive bore runs 0.02 mm off the cannula axis.

• 1
  Cannula tipThin wall, often 0.1–0.2 mm; the cut edge must stay burr-free.
• 2
  Drive boreLocates the blade shaft; roundness and straightness set vibration.
• 3
  Fluid passageCross-section and surface roughness set flow resistance.
• 4
  Grip bodyExternal profile, threads or flats, laser mark area.

Three features control function: the cannula bore, the drive coupling seat, and the face that sets blade stroke depth. Each is machined in a different orientation. If you cut them in three separate setups, you add three fixture errors. On a Ø1.2 mm bore, a 0.01 mm fixture shift is already half the working clearance.

The practical target is total runout of 0.01 mm or better between the cannula tip and the drive coupling. That is not a single-tolerance number. It is the sum of spindle error, fixture repeatability, thermal drift over a 4-hour run, and tool wear.

A common mistake is to hold the outside diameter in a collet and bore from the back. The collet grips on a surface that was turned in the same setup, so any ovality in the bar stock transfers straight into the drive bore. Once the blade shaft is fitted, the handpiece vibrates at the cutter frequency, usually 1,000–4,000 cuts per minute, and the surgeon feels it.

The fix is not a tighter drawing. It is one setup, or as close to it as the part allows.

• 1
  One setup beats threeEach re-clamp adds 0.005–0.015 mm of position error.
• 2
  Probe the datumLive probing before the finish pass catches fixture drift.
• 3
  Watch the heatA 3–5 °C rise over a run moves a 100 mm part by micron scale.

Simultaneous five-axis lets the tool approach an angled port or an internal relief without a second fixture. For a housing with a side fluid port drilled at 30–45°, this removes one handling step and one datum transfer. On our 16 simultaneous five-axis centers, that is the usual reason a medical housing gets quoted on five axes rather than three.

It also lets a single tool path blend the cannula taper into the grip body. Tool marks stay continuous, so anodizing or electropolishing does not reveal a step. For a part that will be inspected under magnification, that matters.

Five-axis does not fix a bad blank. If bar stock runs 0.03 mm out of round, no axis count recovers the bore. It also does not replace a cleanroom or a validated passivation line. Those are separate steps in the process chain.

• 1
  Good fitAngled ports, blended tapers, deep internal bores reached from one side.
• 2
  Poor fitSimple straight tubes where a three-axis lathe with a bar feeder is faster.

Most housings are machined from 316L stainless or 17-4PH. The 300-series grades are easier to passivate and stay non-magnetic, which matters if the handpiece sits near electromagnetic tracking. 17-4PH gives higher yield strength for thin cannula walls but needs a defined heat treat condition before final machining.

Titanium TA2 or TC4 is used when weight or corrosion resistance drives the design. Titanium cuts with more spring and more heat, so feeds drop and tool life shortens. That shows up in unit cost, not in the drawing.

For the fluid path, a finish of Ra 0.2–0.8 μm reduces protein adhesion and makes flushing predictable. External grip surfaces usually sit at Ra 0.8–1.6 μm, which gives enough texture without trapping residue. Bead blasting is common outside, but never inside a bore.

• 1
  316LBest default for passivated, non-magnetic housings.
• 2
  17-4PHHigher strength; specify condition before final cut.
• 3
  TitaniumLight and corrosion resistant; slower to machine.

The failures we see are rarely dramatic. A burr at the cannula tip is one. It is 20–40 μm tall, invisible at arm's length, and it drags tissue on entry. Deburring a 0.1 mm wall without rounding the cut edge is a hand operation with a scope, and it belongs in the routing from the start.

The second is residual chips in a blind bore. A 0.5 mm chip left in the fluid passage will move once the device is primed and can block the aspiration path. Ultrasonic cleaning plus a flow check catches this. Visual inspection alone does not.

The third is dimensional drift late in a run. The first ten parts measure in tolerance, the last ten do not, because nobody re-probed after the spindle warmed. In-process monitoring and 100% inspection before shipment exist for exactly this reason.

• 1
  Burrs at the tipPlan a deburr step; do not leave it to the operator's judgment.
• 2
  Trapped chipsBlind bores need ultrasonic cleaning and a flow check.
• 3
  Thermal driftRe-probe after warm-up and at fixed intervals.
