A reliable supplier delivers three things together: parts to specification, parts on schedule, and paperwork that proves both. Any shop can hit two of those on a good week. The third is where most sourcing problems start, because a missing inspection report is invisible until an auditor or a customer asks for it.

Simultaneous five-axis work cuts setups by letting the tool reach five faces in one clamping. That is the real reason to buy it. Fewer setups means fewer datum transfers, and every datum transfer adds error to your stack. On a bracket with four bored holes on three faces, the difference between three setups and one is often the difference between passing and reworking.

So the question to ask is not whether a shop owns five-axis machines. It is whether they can hold your tolerance across the whole batch, not just on the first article. That is a process question, and it has process answers: fixture design, thermal control, tool wear tracking, and an inspection plan written for your part number.

GreatLight runs 16 simultaneous 5-axis machining centers inside a fleet of 127 high-precision CNC machines, across three wholly-owned plants and 7,600 m² of floor space. Capacity like that matters less than how it is assigned, but it does remove the queue risk that small shops carry.

• 1
  SpecificationDimensional and surface requirements met on every part, not the sample.
• 2
  ScheduleDates you can plan a build around, backed by a stated late-delivery history.
• 3
  DocumentationMaterial certs, inspection data and traceability available when requested.

Every supplier brochure carries a tight number. Ours is ±0.005 mm (±0.0002 in), but the number alone is not useful to you. What matters is the size of the feature, the material, and whether the callout sits on a single surface or across a chain of features.

Ask for the measurement method, not just the result. A CMM report with datum callouts and a stated temperature tells you the shop understands uncertainty. A PDF with a red circle around one dimension does not. If your part has a true position callout, ask how they verify it and on which machine.

Material changes the answer. Aluminium 6061-T6 machines and holds well on thin walls. Titanium TC4 and Inconel move, work-harden and wear tools faster, so the achievable tolerance drifts unless the shop adjusts speeds and inspection frequency. If a quote treats all materials the same, expect surprises on the harder ones.

Surface finish runs on a separate scale from dimensional tolerance. Ra 0.8–1.6 μm is a normal machined finish on most alloys. Getting to Ra 0.2–0.8 μm usually means slower passes, different tooling, or a finishing operation after machining. Decide early which surfaces actually need it.

• 1
  Feature size±0.005 mm on a 20 mm bore is not the same job as on a 400 mm plate.
• 2
  Feature chainTolerances that stack across faces are harder than tolerances on one face.
• 3
  VerificationCMM with named datums beats a photo with a caliper.

Five-axis is not automatically better. A simple prismatic part with holes on one face is cheaper and faster on a three-axis mill or a mill-turn center. The five-axis advantage shows up on contoured surfaces, angled features, deep pockets reachable from several directions, and parts where re-clamping would break a tolerance.

Machine envelope decides feasibility before price. GreatLight covers 4,000 mm maximum processing size, with travels of 4,000 × 400 × 150 mm for long parts, 750 × 1,150 × 550 mm and 600 × 600 × 600 mm for mid-size work, and 500 × 500 × 450 mm or 500 × 310 × 200 mm for compact parts. The Ø400 mm rotary table sets the practical limit on parts that need continuous rotation.

For long, slim parts, ask how the shop controls deflection. Support strategy, fixture stiffness and pass planning matter more than spindle taper. A part that vibrates mid-cut will not hold ±0.005 mm no matter how good the machine is.

There are also parts to keep off five-axis. Very simple geometries, parts with a single drilling axis, and parts where the cosmetic surface matters more than the geometry usually belong on three-axis or four-axis equipment. Choosing the simpler process is a sign of a supplier that is thinking about your cost, not their machine utilization.

• 1
  Good fitImpellers, housings, angled ports, medical instruments, multi-face brackets.
• 2
  Poor fitFlat plates with one drilling face, simple shafts, high-volume turned parts.

Certifications are a starting filter, not a quality guarantee. What matters is the scope printed on the certificate and whether your part type falls inside it. GreatLight holds ISO 9001:2015, IATF 16949:2016, ISO 13485:2016 and ISO 27001:2022. That covers general quality management, automotive, medical devices, and information security respectively.

Map them to your product. Automotive and EV programs usually need IATF 16949 because it drives PPAP-style documentation and change control. Medical device work needs ISO 13485 for design transfer, process validation and traceability. Aerospace buyers often care more about material certification and first-article inspection than about a specific badge.

Inspection practice tells you more than the certificate. GreatLight inspects 100% of parts before shipment, with raw material checks, in-process monitoring and final inspection, and reports on request. Ask what happens when a dimension drifts mid-batch: does the operator stop, or does the part ship and get sorted later?

Confidentiality is a real procurement item, not a formality. If your drawings carry a program name or a customer logo, you want an NDA on file before the first file upload. GreatLight offers an NDA on request, and uploads are handled as secure and confidential.

• 1
  ISO 9001:2015Baseline quality management for general industrial work.
• 2
  IATF 16949:2016Automotive and EV programs with change control needs.
• 3
  ISO 13485:2016Medical devices, validation and traceability.
• 4
  ISO 27001:2022Information security around your files and data.

A quote is a specification of the job, not just a number. The useful ones list material grade, stock form, finish callout, setup count, inspection method and shipping terms. If half of those are missing, the missing half becomes a change order later, and change orders are where schedules slip.

GreatLight returns a quotation and free DFM analysis within 12 hours, can start production within 24 hours, and ships parts in 3–5 days. Historical late-delivery probability sits below 2%. Those numbers are useful because they are specific. Treat any supplier that answers “depends” to every scheduling question as a schedule risk.

MOQ blocks more prototyping programs than price does. GreatLight has no minimum order quantity, so a single prototype and a 10,000+ part run go through the same intake. If a supplier quotes a high minimum on a first article, ask what changes at the second order.

Materials and finishes belong in the same conversation. Incoming material certificates, anodizing color match, plating thickness and laser marking legibility all affect the final part. GreatLight runs anodizing, electroless nickel, zinc, silver and gold plating, powder coating, black oxide, bead blasting, tumbling, brushing, polishing and laser marking in-house.

• 1
  Quote completenessMaterial, finish, setup count and inspection method stated in writing.
• 2
  Schedule realismStated production start and ship window, not a vague range.
• 3
  FinishingOne vendor for machining and finish removes a handoff and a queue.
