A survey lidar returns a usable point cloud only if the scanner keeps pointing where the flight controller believes it points. Every gram you bolt to the airframe sits at the end of a lever arm, so its mass multiplies into inertial load during a bank or a gust. A 900 g payload flown 200 mm below the center of gravity produces a moment the airframe must trim out continuously.

Stiffness matters more than strength here. The mount rarely yields. It bends elastically, by tens of microns, at frequencies the scanner cannot distinguish from real motion. That elastic deflection shows up in the data as a misregistration between overlapping flight lines, not as a visible crack.

The two requirements pull in opposite directions. Adding wall thickness raises stiffness with the cube of the section height, but raises mass linearly. Removing mass from the wrong place, usually the web between the camera bore and the airframe interface, drops the first natural frequency and lets the mount ring at rotor harmonics.

So the design question is not how light can we make it. It is where can we remove mass without moving the boresight axis. That is a stiffness-per-gram problem, and it is solved by geometry first, alloy second.

• 1
  Lever armPayload offset multiplies inertial load; keep the sensor mass close to the airframe interface.
• 2
  Elastic, not plasticFailure mode is micron-level bending, not fracture.
• 3
  Frequency floorKeep the first mode well above rotor and gimbal excitation.

Three alloys cover most drone survey lidar mount lightweight alloy work: 7075-T6 aluminum, AZ31B magnesium, and Ti-6Al-4V. Density runs roughly 2.81, 1.77 and 4.43 g/cm³. Specific stiffness, the number that matters for a vibration-limited part, is close between 7075 and AZ31B and drops for titanium.

7075-T6 is the default. Yield strength around 503 MPa, good machinability, and a well-understood anodize process. It is the right pick when the mount also carries an antenna, a GNSS board or a battery plate, and when you need threaded inserts that survive repeated assembly.

AZ31B saves about 35% of the mass of an equivalent 7075 part. That is real endurance on a small airframe. The cost is corrosion behavior: magnesium needs a conversion coating plus a sealed topcoat, and any bare edge becomes a corrosion site in coastal survey work.

Ti-6Al-4V only wins in one scenario. When the mount is also a structural frame member, or when the thermal expansion of the mount has to be close to a titanium sensor housing. Otherwise you are paying for strength the part never uses and carrying mass you did not need.

• 1
  7075-T6Default choice. Best balance of stiffness, threads and finish options.
• 2
  AZ31BLightest option. Requires coating discipline and dry assembly.
• 3
  Ti-6Al-4VUse only for structural or thermal-expansion reasons.

A lidar mount is mostly thin walls, deep pockets and bores that must stay parallel to each other. On a three-axis machine, every refixturing step adds a small angular error. Stack four setups and the dowel hole pattern can walk out of position by 0.03 mm before you cut a single finish pass.

Five-axis machining removes that stack. The part stays in one setup while the trunnion and the spindle reach the underside of the flange, the inner faces of the web, and the sensor bore without the operator loosening a clamp. Positional tolerance holds at ±0.005 mm, and the bore-to-bore relationship stays inside the tolerance the scanner manufacturer specifies.

The other benefit is wall thickness. Topology-optimized mounts often land at 1.2 to 2.0 mm walls with 4 to 6 mm bosses. A five-axis cutter with a long reach and a small corner radius can follow those surfaces without chatter, provided the toolpath keeps radial engagement constant.

Cutting parameters matter as much as the machine. For 7075 at 1.5 mm wall, we run light radial engagement and high spindle speed rather than heavy passes. That keeps cutting forces low so the wall does not deflect away from the cutter and leave a tapered surface.

• 1
  One setupEliminates refixturing error on bore-to-bore relationships.
• 2
  ReachUndercut flanges and internal webs without repositioning.
• 3
  Light engagementLow radial depth of cut protects thin walls from deflection.

Aluminum expands about 23 µm per meter per degree C. A 150 mm mount that warms 20 °C from ground to cruise grows roughly 0.07 mm. That does not move the boresight by itself, because both bores grow together. It becomes a problem when one side of the mount sees motor heat and the other sees airflow.

The fix is symmetry, not a different alloy. Put the mounting feet on a common thermal plane, keep the sensor interface thick and the compliant web thin, and avoid long unsupported spans on one side. Where the sensor housing is titanium, a thin titanium interface plate can absorb the mismatch.

Surface finish affects fatigue life more than it affects accuracy. A Ra 1.6–3.2 μm as-machined wall is fine for a static mount, but vibration cycles concentrate at tool marks. Bead blasting or a light polish on the high-stress fillets removes the initiation sites. Anodizing adds no meaningful stiffness.

The most common mistake is anodizing a bore that has to hold a dowel pin. Hardcoat builds 20 to 50 µm per surface and changes the fit. Mask the bores, or specify the pre-plate dimension and let the coater work to it.

• 1
  Symmetry firstThermal drift is a geometry problem before it is a material problem.
• 2
  FilletsBlast or polish high-stress radii to delay fatigue cracking.
• 3
  Mask boresHardcoat thickness will change a press fit if you ignore it.

Alloy mounts have a boundary. Below roughly 250 mm of unsupported span and 1.5 kg of payload, aluminum and magnesium win on every metric that matters. Above that, the wall thickness needed to hit a frequency target makes the part heavy enough that the alloy advantage disappears.

The second boundary is corrosion exposure. Long-duration coastal or agricultural survey work sprays the mount with salt or chemistry. Magnesium needs a coating system that survives abrasion from handling, and any scratch reopens the corrosion path. In that case 7075 with hardcoat is the safer engineering decision even at a weight cost.

The third boundary is dimensional stability over temperature. If the lidar has to hold boresight across a 60 °C swing without recalibration, an alloy mount plus an Invar or titanium interface plate is a better system than a monolithic alloy part.

A composite mount is sometimes suggested at this point. It is lighter, but the coefficient of thermal expansion is anisotropic and the bolted interface creeps under preload. For a survey payload that must return to the same boresight after every flight, machined alloy at ±0.005 mm is still the predictable answer.

• 1
  Size limitPast ~250 mm span, wall thickness cancels the alloy weight saving.
• 2
  CorrosionSalt and ag chemistry favor hardcoated 7075 over bare magnesium.
• 3
  Wide ΔTUse a low-CTE interface plate instead of a monolithic alloy body.
