Every axis on a CNC machine is a positioning problem. The controller sends a command, the drive converts it into current, and the motor turns a ballscrew, a rack, or a rotary table to a target coordinate. The motor used in a CNC machine therefore sets how fast an axis can accelerate, how tightly it holds position under cutting load, and how much heat it dumps into the frame.

Stepper motors move in fixed increments. Send 200 pulses and the shaft turns one revolution, usually 1.8° per full step. Movement follows the pulse count directly, so the control loop is simple and cheap. The catch is that nothing confirms the shaft actually arrived. If chips pack a flute or a cutter grabs, the motor can lose steps and the rest of the program runs at the wrong origin.

Servo motors close that gap. An encoder or glass scale reports the true position, and the drive corrects the error in real time. The result is higher acceleration, higher top speed, and a fault signal instead of a silent shift. On aluminium and steel parts held to ±0.005 mm, servo is the normal answer.

Linear motors remove the screw entirely and drive the slide directly along a magnetic track. There is no backlash and no screw whip, so contouring stays smooth at feed rates that would shake a ballscrew machine. The trade-off is cost, heat, and a real sensitivity to chips near the magnet track.

Steppers are not obsolete. They are predictable, inexpensive, and easy to wire. On a router cutting plywood at 3,000 mm/min, or an engraver tracing a logo in brass, a stepper holds position well enough and costs a fraction of a servo package. The torque curve is strongest at low speed, which suits drilling and slow plunging more than high-speed contouring.

The practical limit shows up as speed rises. Stepper torque falls off quickly past a few hundred rpm, and the drive runs open loop. Mid-band resonance can appear on some frames, showing as vibration and a rippled surface finish. A damper or microstepping helps, but it does not restore closed-loop control.

Adding an encoder turns a stepper into a hybrid. The drive can detect a stall and fault out, which protects the part. Speed and acceleration still trail a comparable servo, so hybrid steppers fit budget retrofits and light aluminium work rather than production runs.

If your drawings call for Ra 0.8–1.6 μm on a hardened steel pocket, a stepper is the wrong tool. If you are proving a bracket shape in POM before committing to a mould, it is fine.

An AC servo pairs a permanent-magnet motor with a drive that closes the position loop thousands of times per second. Acceleration is high, top speed is high, and the drive reports following error continuously. That data is useful. A rising following error tells you a tool is dulling or a slide is binding before the part is scrapped.

Servo systems tolerate a wider range of materials because the loop absorbs load changes. Cutting 4140 steel at a heavier chip load pulls more torque, and the drive simply draws more current to hold the commanded feed. The same cut on an open-loop stepper risks a lost step and a scrapped pocket.

Servo accuracy is set by the feedback device, not the motor. A shaft encoder gives good repeatability at the screw. A linear scale measures the table itself and picks up thermal growth in the screw, which matters on long parts where the screw can stretch 20–30 μm over a warm shift.

Tuning is the hidden cost. A poorly tuned servo hums, overshoots corners, and leaves chatter marks. A well-tuned one holds ±0.005 mm all day. That difference lives in the integrator's setup, not the catalog.

A direct drive rotary table couples the motor rotor to the table with no gearbox and no worm. Backlash disappears, so a 4th axis can interpolate a smooth helical port without the reversal error a worm drive leaves behind. On parts with blended surfaces, that shows up directly in the surface finish.

Linear motors do the same for straight axes. The slide rides on the magnet track with no screw to wind up, so a 4,000 mm axis can accelerate hard and still hold a fine contour. Aerospace ribs and long thin pockets benefit most, because the machine can keep feed constant through direction changes.

The costs are real. Linear motors generate heat in the magnet track, which pushes into the machine structure and needs cooling. They attract chips if covers fail, and they cost more per axis than a ballscrew servo. On a 500 mm axis cutting a handful of features, the gain rarely justifies the price.

Direct drive rotary tables also lose mechanical reduction, so the motor must produce the full cutting torque itself. That means a larger, heavier motor. Where the part is small and the torque demand is low, it is still a clean answer.

Start with the tolerance band. If the drawing allows ±0.05 mm and the material is plastic or aluminium, a stepper or hybrid machine can hold it. If the print says ±0.005 mm with a fine finish callout, you want servo axes and, on long parts, linear scales.

Next, look at the geometry. Deep cavities, thin walls, and blended surfaces reward smooth interpolation and high acceleration. That points to servo or direct drive. Simple prismatic parts with flat faces and drilled holes do not care about contouring speed, so a stepper machine is often enough.

Then check the lot size. One prototype and a 10,000-part run do not need the same drive. A prototype shop can absorb a slower feed rate. A production cell cannot, because cycle time sets the unit cost.

Finally, ask how the shop verifies position. Feedback on the table beats feedback on the motor. If a supplier quotes a tight tolerance on a long part and cannot say where the scale sits, that number is optimistic.
