Cast iron is an iron-carbon-silicon alloy where most of the carbon is not dissolved in the matrix. It sits as free graphite flakes, nodules, or carbide particles. That single fact drives every tool choice downstream. The metal matrix is machined, but the graphite acts like a built-in chip breaker and a mild solid lubricant at the shear zone.

Gray iron is the classic case. Carbon forms flake graphite, which interrupts the chip and produces short, broken segments instead of a long stringy curl. Cutting forces stay moderate even at high removal rates. On a Brinell hardness of roughly 150 to 250 HB, coated carbide can run fast and dry.

Ductile iron inverts part of that picture. Magnesium or cerium additions turn the graphite into nodules, so the material gains tensile strength and elongation. Nodules do not break the chip as cleanly, and the matrix is often pearlitic. Tools see more rubbing and more heat.

White iron sits at the other extreme. Almost all carbon is tied up as hard iron carbide, giving 400 to 600 HB or higher. It is abrasive in a way that reshapes tool life expectations, and in many cases grinding or a CBN insert is the honest answer.

Uncoated carbide and CVD-coated carbide are the workhorses for gray iron. Grades in the ISO K10 to K20 range are the usual starting point. They combine high hot hardness with enough toughness to survive interrupted cuts on a block face or a flywheel rim.

Coatings matter less than the substrate on gray iron. An uncoated fine-grain grade often outlasts a coated one because there is no coating to flake at a thermal crack. Where a coating helps, titanium carbonitride or a thin aluminum oxide layer on a cobalt-enriched substrate is a common compromise.

Edge geometry deserves more attention than grade labels. A light hone of 0.02 to 0.05 mm on the cutting edge reduces chipping on scaly cast skins. A small negative land of 10 to 15 degrees supports the edge during interrupted cuts. For ductile iron, a slightly larger rake angle keeps cutting pressure down and limits work hardening at the flank.

Milling inserts for cast iron typically use a stronger edge preparation than steel inserts. Round or button inserts with a strong edge are effective for roughing a large face, while a 45 degree lead angle spreads the load and reduces notch wear at the depth-of-cut line.

Holes in cast iron are forgiving compared to stainless, but not trivial. Solid carbide drills with internal coolant run best when the drill can pass coolant through the flutes, which keeps the tip cool and flushes the fine, powdery chips that gray iron produces.

For gray iron, a drill point angle of 118 to 140 degrees works. Higher point angles give a stronger tip for harder grades. Feed per revolution of 0.10 to 0.25 mm depending on diameter keeps the chip broken. Too light a feed rubs the edge and dulls it fast, which is a common mistake on small-diameter work.

Ductile iron produces a more continuous chip, so chip evacuation needs attention. Peck cycles or high-pressure through-coolant help. A drill with a 140 degree point and a slightly thicker web resists the higher thrust forces.

Tapping cast iron rarely needs a cutting fluid, but the tap geometry does matter. Spiral-flute taps pull chips out of blind holes. Form taps work well in ductile iron because the material has enough ductility to flow; they are a poor fit for gray iron, which crumbles instead of deforming.

Turning cast iron is where the free graphite pays off. Chips break into small segments and slide away from the insert. A typical roughing pass on gray iron runs 2 to 4 mm depth of cut with a feed of 0.2 to 0.4 mm per revolution, leaving a finish pass of 0.3 to 0.5 mm for dimensional control.

Dry cutting is standard for gray iron. The graphite lubricates the interface, and flood coolant can cause thermal cycling that cracks inserts. An air blast clears dust and keeps the work zone visible, which matters on large housings and manifolds.

Ductile iron is less forgiving. The nodular structure and higher ductility generate more heat, and a coolant stream can help on continuous boring operations. If coolant is used, it should be applied consistently, not intermittently, so the insert sees one thermal regime.

Boring is where rigidity decides tool life. Cast iron parts are often thin-walled, and a boring bar with a large length-to-diameter ratio will chatter before the insert wears out. Reducing the overhang, using a heavy-metal bar, or moving to a larger-diameter bar usually beats changing grades.

Cast iron is chosen for damping, wear resistance, and thermal stability, not for strength-to-weight. When a part needs high tensile strength in a thin section, ductile iron can be replaced by steel or aluminum with less risk. The tool selection question becomes irrelevant at that point.

White iron and Ni-hard are abrasive enough that carbide tool life collapses. Ceramic and CBN inserts can cut them, but the setup must be very rigid and the machine must have enough spindle power. For small lots, grinding is often cheaper than chasing insert life.

Thin-wall gray iron castings are a known trap. The material cuts easily, but the part deflects during clamping and machining. Tool wear is not the limiting factor; the fixture is. Soft jaws, minimal clamping force, and a finishing pass with light depth of cut do more for tolerance than any insert change.

Castings also carry skin, sand inclusions, and hard spots. A first pass below the skin removes the abrasive layer. Skipping that step and cutting to final depth in one pass is a common cause of sudden insert failure and scrapped parts.
