A piezoelectric buzzer is a thin ceramic disc bonded to a brass or stainless plate. When voltage is applied, the disc flexes and radiates sound. The disc is light, maybe 1–3 g, and it moves only a few micrometers. Anything that clamps or preloads the disc changes its resonance frequency and output level. That is the whole reason the mount is not a bracket.

In a multirotor, the mount also sits on a structure that shakes at 80–300 Hz from the rotor blades, plus higher harmonics from the motor bearings and the frame. If the mount is stiff, it passes that vibration straight into the buzzer plate, and the plate starts moving at frequencies it was never designed for. Output drops, or the tone turns rough.

The uav buzzer mounts rapid prototype stage exists to test that interaction before you cut a mold. Wall thickness, rib placement, and screw torque all shift the acoustic result. You cannot predict the final sound from a CAD file alone.

So the prototype is not just a fit check. It is an acoustic and structural experiment, and the machining method has to hold the features that control the experiment.

• 1
  Sound pathOpenings and wall thickness set how much pressure escapes the cavity.
• 2
  Vibration pathMount stiffness and damping decide what reaches the disc.
• 3
  Electrical pathGrounding and wire routing affect noise on the drive signal.

Engineers often size a buzzer mount for strength, then wonder why the alarm sounds weak. Strength keeps the part from breaking. Stiffness decides whether it transmits vibration. Those are different properties, and you can trade one against the other with geometry.

A thin, flat plate in 6061-T6 at 1.5 mm wall will flex at low frequency and act as a spring. That can isolate the buzzer from frame shake, but it also lets the plate flop under rotor wash. A 3 mm plate with a short rib is far stiffer and will pass more vibration. Neither is wrong. It depends on where the buzzer sits.

On an arm-mounted buzzer, the arm already carries high-frequency content. A softer mount helps. On a body-mounted buzzer near a flight controller, a stiff mount keeps the cavity volume stable and the tone predictable.

The practical rule: prototype two wall thicknesses, 1.5 mm and 3.0 mm, in the same geometry. Measure sound pressure at 1 m with the drone armed but not flying. The difference tells you which direction to go.

• 1
  Arm mountFavor damping; 1.5–2.0 mm walls with a compliant pad.
• 2
  Body mountFavor stiffness; 2.5–3.0 mm walls with a rib.
• 3
  Test methodCompare SPL at 1 m, armed, props off.

A buzzer mount usually has four or five features: a shallow pocket for the buzzer body, a small through hole or slot for the sound port, two or four screw bosses, a cable exit, and a mounting flange. Each one has a machining limit.

The sound port is the tightest. A 1.0 mm slot 8 mm long is fine on a 3-axis mill with a 0.8 mm end mill, but the tool will deflect if the depth exceeds about 3 times its diameter. Keep the port wall under 2 mm, or drill it from both sides.

The buzzer pocket sets the acoustic cavity. Depth tolerance of ±0.10 mm is usually enough, but the floor finish matters more than the dimension. A floor at Ra 3.2 μm scatters sound; a floor at Ra 0.8 μm gives a cleaner tone. That is a finishing decision, not a tolerance decision.

Screw bosses need enough wall around the thread. In ABS or POM, keep at least 1.5 mm of material around an M2 thread. In aluminium, 1.0 mm is enough. If the boss is thinner, the screw will crack it on the second assembly.

• 1
  Sound portKeep depth under 3× tool diameter, or drill both sides.
• 2
  Cavity floorTarget Ra 0.8–1.6 μm for a clean tone.
• 3
  Boss wall1.5 mm in plastics, 1.0 mm in aluminium, around M2.

Aluminium 6061-T6 is the default for a machined buzzer mount. It is stiff, light, and takes anodizing well. Density is about 2.70 g/cm³, so a 4 g aluminium mount is realistic. It also conducts heat away from the buzzer, which matters if the buzzer runs continuously.

If you need damping, POM or ABS is better. Both absorb vibration instead of passing it. The trade-off is stiffness and creep: a plastic boss can relax over months under screw preload, and the buzzer will start to rattle. Use a metal insert or a through-bolt if the part will be serviced.

PEEK is the choice when the mount sits near a motor or a battery that gets hot. It keeps stiffness up to about 250 °C and does not creep like POM. It costs more, and it machines slower, but it removes a failure mode.

Titanium Ti-6Al-4V is rarely justified for a buzzer mount. It is heavier per unit stiffness than aluminium and harder to finish. The one case where it makes sense is a mount that is also a structural bracket and must survive a crash.

• 1
  6061-T6Default choice: light, stiff, anodizes cleanly.
• 2
  POM / ABSDamping, but watch creep at screw bosses.
• 3
  PEEKHot zones near motors or ESCs.

CNC prototyping wins when the geometry is complex, the quantity is under a few hundred, or the material is not moldable. It loses when the part is a simple flat plate in a commodity plastic, because a laser-cut or stamped version will be cheaper and just as good.

It also loses when the design is already frozen and the annual volume is above roughly 5,000 pieces. At that point the per-part cost of machining stops competing with a mold, even after tooling.

The useful middle ground is 10–200 units for field trials. That range covers most drone programs, and it is where CNC gives you real parts in a real material without tooling risk.

One more boundary: if the buzzer mount is bonded into a composite frame, the mating surface flatness matters more than anything else. A machined face at 0.05 mm flatness is easy. A printed face is not.

• 1
  Good fitComplex geometry, 1–200 units, engineering plastics or metal.
• 2
  Poor fitSimple flat plate, high volume, frozen design.

Not every feature on a buzzer mount needs tight tolerance. Over-tolerancing raises cost and slows inspection without improving the acoustic result. Split the drawing into functional and non-functional dimensions.

Functional: the buzzer pocket diameter, the pocket depth, the screw hole positions, and the mounting face flatness. These control fit and cavity volume. Tighten these.

Non-functional: the outer profile, the cable relief shape, the flange radius. These can sit at ±0.20 mm and nobody will notice. Marking them general tolerance keeps the quote down.

GreatLight holds ±0.005 mm on critical features when the drawing calls for it, with 100% inspection before shipment. The point is to spend that precision where it changes the part, not across the whole print.

A practical split for a typical 30 × 20 × 8 mm mount: pocket diameter and depth at ±0.02 mm, hole positions at ±0.05 mm, outer profile at ±0.20 mm.

• 1
  TightenPocket bore and depth, screw holes, mounting face.
• 2
  LoosenOuter profile, relief cuts, cosmetic radii.
