A milling supplier is only as good as the spindles behind the quote. GreatLight runs 127 high-precision CNC machines across three wholly-owned plants covering 7,600 m², including 16 simultaneous 5-axis machining centers, 12 four-axis mills, 27 three-axis machines and 16 mill-turn centers. That mix matters because most parts need two or three of those machine types, not just one.

Size range is the second gate. Travel goes from 500 × 310 × 200 mm on the compact machines up to 4,000 × 400 × 150 mm on the large gantry side, with a Ø400 mm rotary table for round and prismatic work. If a supplier has to turn your 900 mm housing away, that is a capability answer, not a price answer.

The third gate is the material list. Aluminium 6061, 7075 and 6082 cut fast and hold tight tolerances. Stainless 17-4PH and 316L move during roughing. Titanium TC4 and Inconel wear tools and need slower passes. A shop that lists these materials has already solved the feeds, speeds and tool life for each family.

Ask for the machine that will run your part, not the machine count in the brochure. A 5-axis center sitting idle behind a two-week backlog is not capacity you can use.

±0.005 mm (about ±0.0002 in) is the tight end of general milling. It holds when the machine is thermally stable, the fixture is rigid and the drawing is dimensioned from datums the shop can actually reach. It does not hold because someone typed it in a quotation template.

Surface finish follows the same logic. As-machined faces land around Ra 1.6–3.2 μm, a good production finish sits at Ra 0.8–1.6 μm, and fine finishing reaches Ra 0.2–0.8 μm. Those steps cost different amounts of time, so state which faces actually need the finer number. Chasing Ra 0.4 μm on a face that sits against a rubber gasket wastes money.

Watch for tolerance callouts that fight each other. A true position of Ø0.05 mm on a hole pattern that also carries a ±0.1 mm profile tolerance on the same surface is a conflict. Good shops flag it during DFM review instead of machining to the tighter one and charging you for it.

The practical test is the inspection plan. If the supplier cannot describe how the critical dimension will be measured, on what instrument, and at what point in the run, the tolerance claim is not verified. Ask for that description before you place the order.

Lead time in milling is really three separate clocks: how fast the quote and DFM feedback come back, how fast material and fixtures are ready, and how fast the cutting runs. GreatLight quotes with a free DFM analysis within 12 hours and can start production within 24 hours, with parts shipping in 3–5 days. Ask each supplier to break the number down the same way.

A single blended lead time hides the risky step. If a shop takes ten days to review the drawing, the cutting schedule is irrelevant. If material is not in stock, no machine speed fixes it. Split the question and you will see which supplier is genuinely fast and which one is optimistic.

Order size is the other half. No minimum order quantity means the same shop, the same process and the same inspection standard apply to one prototype and to a 10,000+ part run. That removes a second qualification cycle when the design moves to volume.

Read the quote line by line. Material, machining, finishing, inspection reports, material certificates and shipping are separate lines. A cheap machining line with expensive finishing and inspection is not a cheap part. Compare the total scope, and confirm whether uploads are handled under NDA.

ISO 9001:2015 is the baseline quality system. It says the shop documents its process and audits it. For general industrial machinery, robotics and electronics work, it is usually enough.

IATF 16949:2016 is the automotive and EV standard. If your part feeds a vehicle program, a supplier without it will be pushed out during your own PPAP process. ISO 13485:2016 covers medical devices, where process validation and traceability carry more weight than dimensional capability alone.

ISO 27001:2022 is about information security. It matters when your drawings are the product and a leak is a commercial risk, which is common for robotics and consumer electronics programs. Ask which certificate scope covers the plant that will machine your part.

Certification is a filter, not a ranking. Two suppliers can both hold ISO 9001 and sit far apart on five-axis skill and inspection depth. Use certificates to remove suppliers, then compare capability.

Milling removes material with a rotating cutter, so it wins on prismatic parts, tight bores, flat sealing faces and pockets with sharp internal corners. It is also the fastest route to a functional prototype in aluminium or engineering plastic.

It is the wrong answer for thin-walled shells with large surface area, where sheet metal fabrication or vacuum casting is cheaper and faster. It is also a poor fit for very high volumes of a simple part, where die casting or injection molding amortises a tool and beats per-part machining cost.

Deep narrow pockets are a milling limit too. When depth is more than about four times the cutter diameter, the tool deflects and the finish drops. Redesign the pocket, or accept a slower run with a smaller stepover.

If your part has both turned and milled features on one axis, mill-turn centers remove the second setup. That is a real accuracy gain. If the geometry is purely rotational, a lathe is the honest choice.
