Gear stamping starts with flat stock, usually low-carbon or alloy steel coil between 0.5 mm and 6 mm thick. A hardened punch pushes the profile through a die. The metal does not melt or cut in the machining sense. It shears. The edge you get has three zones: a rounded rollover at the top, a smooth bright band in the middle, and a rough fracture zone at the bottom. That edge is why gear stamping is different from gear cutting, where the tooth flank is machined to a controlled involute.

Gear cutting covers hobbing, milling and shaping. A hob is a rotating cutter that generates the involute as the blank indexes. Shaping uses a reciprocating pinion cutter that strokes up and down while the blank rotates. Both remove material from a solid blank, so wall thickness and hub height are not limited by sheet gauge. A hobbed gear at module 2 typically holds total profile error within 0.02 mm to 0.03 mm on a good machine, and much tighter on a ground gear.

Shaping has one advantage over hobbing: it reaches internal gears and shoulders where a hob cannot swing. The cutter passes inside the bore and cuts the internal tooth form. If your drawing shows an internal ring gear with a closed shoulder, shaping is often the only practical cut route. Stamping cannot form internal teeth at all, because the punch has to push straight through.

None of these three is universally better. Stamping trades tooth accuracy for speed and low piece cost. Cutting trades cycle time for accuracy and material freedom. The choice usually falls out of three questions: how many parts, how thick, and how tight.

Stamped gears are judged on a different set of numbers than cut gears. The die sets the profile, so pitch and index repeat well once the die is correct. The problem is the edge. Rollover and fracture vary with material hardness, clearance and die wear. A stamped gear often needs a shaved or machined second operation before it can run quietly at high speed.

Cut gears are judged on lead, profile and runout. A shaped gear can hold lead error around 0.01 mm over a 25 mm face width on a well-maintained machine. A hobbed gear runs a little looser on lead but faster on cycle time. Ground teeth push profile error below 0.005 mm. That is the range where automotive transmission gears live.

Thickness is the hard wall for stamping. Past roughly 6 mm, punch force and die stress climb steeply, the fracture zone grows, and the edge quality drops. You can stamp a 10 mm plate on a large press, but the cut face will not look like a gear tooth. For any gear with a face width above 8 mm, plan on cutting.

There is also a geometry limit. Stamping produces a straight, prismatic tooth. It cannot crown a tooth, taper the lead, or put a helix on the gear. If your design calls for a helical gear or a crowned tooth for misalignment, stamping is off the table. Cutting handles both.

The cost curve is what separates these processes more than anything else. A progressive stamping die for a simple spur gear can run from a few thousand dollars into five figures depending on stations, shaving and coining. That cost is paid once and then spread over the run. Cutting has almost no dedicated tooling. You pay machine time and, for shaping, a cutter that may already be on the shelf.

At low volume, cutting wins on total cost. One hundred gears off a lathe and mill are cheaper than building a die. At high volume, stamping wins hard. Once the die is amortized, piece cost is mostly material and press time. The crossover for a simple spur gear usually sits somewhere between 5,000 and 20,000 pieces a year, but it moves with part size, tooth count and required edge quality.

Lead time follows the same split. A stamped gear needs die design, build and trial, which is weeks. A cut gear can start as soon as the material arrives. For a prototype or a bridge build, cutting is the only route that fits a short schedule. Our own shop quotes and returns DFM notes within 12 hours, and production can start within 24 hours of approval.

One more cost hides in stamping: die maintenance. Punches wear, clearances open, and the fracture zone grows. If your print calls for a controlled edge, add a shave station or budget for periodic die service. That line item rarely shows up in a first-pass comparison.

Stamped gears fail in predictable ways. A worn punch opens the die clearance, which pushes the fracture zone higher up the tooth flank. The gear still measures on pitch, but it runs noisy. Inspect the edge under 20× magnification and track the bright band height as a die-wear indicator. If the band drops below about one third of the thickness, schedule a die service.

Burrs are the other common complaint. A small burr on the tooth edge is harmless in a low-speed application but becomes a fatigue crack starter in a high-cycle gear. Tumbling or brushing removes most of it. If the print forbids burrs, add a shave station or plan on a vibratory finish with a defined edge break.

Cut gears fail differently. The usual issues are lead error from a worn hob, chatter from insufficient rigidity, and runout from a poorly seated blank. Chatter leaves a periodic pattern on the flank that shows up as noise at running speed. Check the setup before blaming the cutter. A dial indicator on the blank while it turns will show runout in seconds.

Shaping has one specific trap: cutter interference near a shoulder. The cutter needs clearance to stroke past the gear face. If the shoulder is too close, the cutter rubs and the tooth form goes wrong at one end. Check the drawing for axial clearance before the job is set up, not after.
