In CNC screw machining the bar does not spin past a fixed tool. It sits inside a guide bushing, and the bushing supports the material a few millimeters from the cutting edge. The Z axis pushes the bar forward, the tools work right at the bushing face, and the unsupported length never grows as the part gets longer. That single detail is why a long, thin part holds diameter without a tailstock.

The X and Y axes on the gang slide move the tools, not the work. On a Swiss-type machine the tool moves in two axes while the bar indexes in Z. Turning, grooving, threading and even milling with a live tool happen within a few millimeters of the bushing. Cutting force stays close to the support point, so deflection stays small even at length-to-diameter ratios of 10:1 or more.

The trade-off is bar diameter. A guide bushing is made for one bar size, and the common range runs from about Ø1 mm to Ø32 mm. Push past that and you move to a fixed-head lathe or a mill-turn center, where the work spins and the tool travels. Different machine, different deflection math.

One more consequence: the bar must be ground and straight. A cold-drawn bar with a bent end will not feed through the bushing. If your stock arrives bowed, the machine will stop before it cuts anything.

CNC screw machining fits parts that are mostly cylindrical and mostly small. Think of a fitting with a hex, a thread, two diameters and a cross hole. That part leaves the machine complete in one cycle, with no second op and no re-chucking error. The more features you can reach from the side of a bar, the better the process pays off.

Cross holes, slots and flats are cut with live tools on the gang slide or on a sub-spindle. A Ø3 mm cross hole through a Ø12 mm stainless shaft is routine. What is not routine is a deep axial pocket or a feature that needs a tool approaching along the part axis at an angle the slide cannot reach.

Length-to-diameter ratio is the second filter. Above roughly 3:1, a conventional lathe needs a tailstock or a steady rest, and each adds setup time and a chance of chatter. The guide bushing removes that problem. Long slender pins, needles, bone screws and spool valves are classic screw machine work for exactly this reason.

Threads are where the process is strongest. Rolled or cut threads on a small diameter come off the same cycle as the turning. For high-volume fasteners, that is the whole point.

Prismatic parts do not belong here. If your part is a plate with pockets on two faces, a screw machine cannot reach most of it with side tools. A 3-axis or 5-axis mill will finish it faster and cheaper. Sending a bracket to a Swiss shop wastes the setup and produces a worse part.

Very large diameters are out too. The guide bushing range tops out around Ø32 mm on our machines, and the 4,000 mm maximum processing size applies to our other turning and milling platforms, not to screw work. If your blank starts at Ø60 mm, ask for a mill-turn quote instead.

Deep bores and internal features with tight concentricity to the outside diameter are awkward. The tools come in from the side, so a bore that runs the full length of the part usually needs a second operation on a lathe. That second op reintroduces the concentricity error you were trying to avoid.

Finally, consider volume. CNC screw machining is set up for runs, but our MOQ is zero, so a single prototype is fine. What changes with volume is how you amortize the cam-style setup and bar preparation. Below about 50 pieces, a lathe with bar feeder may be simpler to schedule.

The ±0.005 mm figure is a process capability, not a default. It applies to a diameter measured at a stable temperature, on a machine that has been warmed up, with a ground bar that fits the bushing. Ask for it on every dimension and you will pay for it in inspection time.

Thermal drift is the main enemy. A screw machine runs at high spindle speed in a small envelope, and the bar grows as it warms. Shops that hold tight tolerances run warm-up cycles before the first article and keep coolant temperature steady. If a shop quotes ±0.005 mm and does not mention warm-up, ask how they control it.

Tool wear shows up first on the smallest diameters. On a Ø2 mm feature, 0.005 mm of flank wear is a quarter of the tolerance. In-process gauging or scheduled tool changes every few hundred parts are the usual answers. We monitor in process and inspect 100% before shipment.

Surface finish follows the same logic. Ra 0.8–1.6 μm is a normal as-machined result for aluminum and brass. Below Ra 0.8 μm you are usually looking at a finishing pass, a different insert geometry, or a secondary operation.

Free-machining grades run best. Brass C36000 and stainless 303 break chips cleanly and hold finish at high feed. They are the default for high-volume screw parts, and the tool life is predictable. If your design allows 303 instead of 316L, the cycle time difference is real.

316L and 17-4PH are machinable but stringy. They need higher pressure coolant directed at the cutting edge and more conservative feeds. On a Ø4 mm feature in 316L, we typically drop the feed and accept a longer cycle rather than risk a built-up edge that tears the finish.

Titanium TC4 (Ti-6Al-4V) and Inconel sit at the other end. They cut hot, they work-harden, and they wear tools fast. Small screw parts in these alloys are possible and we run them, but the cost per part is dominated by tool changes, not by machine time. Budget accordingly.

Plastics are a different set of rules. POM and PEEK machine cleanly on a screw machine if you control chip evacuation, since a wrapped chip will jam the guide bushing. ABS and PC are soft enough that a sharp insert and light depth of cut matter more than speed.

A screw machine produces thousands of parts from one setup, so sampling is not enough on its own. The first article proves the setup, and in-process monitoring catches drift. Final inspection covers the features the drawing calls out. Ask for the report on the dimensions you care about, not a generic sheet.

Material traceability matters more than most buyers expect. A heat number on the mill certificate lets you trace a batch back if a field failure happens. For medical and automotive work this is a requirement, and our ISO 13485:2016 and IATF 16949:2016 systems are built around it.

If your part is a medical device component, the process also has to be repeatable across lots, not just within one. That means documented parameters and a change-control step when a tool or a supplier changes. Ask how the shop handles a bar supplier switch.

For confidential programs, uploads stay secure and an NDA is available on request. Drawings should not travel by email if the part is sensitive.
