A CNC program is a list of coordinates. G01 X50.0 Y25.0 Z-3.0 F400 tells the control to move the tool to a point that exists only in the machine's coordinate system. The control has no idea where your workpiece actually is. Somebody has to tell it. That instruction is the CNC machining position: the workpiece origin, plus the orientation of the part axes relative to the machine axes.

Think of it as a chain. The drawing defines the part origin. The fixture locates the blank against that origin. The probe or edge finder measures the fixture's relationship to machine zero. The operator stores that offset in the work coordinate system (G54 through G59, or G54.1 P1 and up). Only then does the toolpath land where the designer intended.

Break one link and the error propagates through every feature cut after it. A 0.05 mm shift in the workpiece origin moves every hole, every pocket and every face by 0.05 mm in that direction. On a single part that may still pass. On a 200-part assembly run it will not.

This is why position is not a setup detail you can leave to the last minute. It is the first engineering decision on the process sheet, and it constrains everything downstream: fixture design, tool reach, number of setups, inspection strategy.

• 1
  Work coordinate systemG54–G59 offsets translate the programmed origin onto the physical part.
• 2
  Datum frameworkThree mutually perpendicular references that the drawing and the machine both agree on.
• 3
  Position errorAny deviation between the intended part origin and where the machine thinks it is.

A datum is a theoretically exact point, line or plane used as a reference. In practice it is a real surface on the blank that is flat enough, stiff enough and accessible enough to be trusted. A typical primary datum for a milled part is a faced bottom surface. Secondary and tertiary datums are usually two perpendicular edges or, better, two bored holes.

Holes make stronger datums than edges. A reamed Ø10 H7 hole locates in two directions at once and repeats to within a few microns when you drop a pin into it. A sawn edge repeats to whatever the saw left behind, which can be 0.1 mm or worse. If a drawing calls for a hole-based datum, respect it. If it does not, adding one usually pays for itself on the second setup.

The 3-2-1 rule still applies for prismatic parts: three points on the primary plane, two on the secondary, one on the tertiary. That removes all six degrees of freedom. Over-constrain the part and the fixture fights itself; under-constrain it and the part moves under cutting force. Both show up as chatter, taper or a wall that is out of square.

Watch the datum hierarchy against the function. A bearing bore that mates with a shaft should be the datum, not the rough casting face. When the drawing datums and the manufacturing datums disagree, ask before you cut. Moving a datum later means re-cutting the fixture and re-proving the first article.

A fixture does two jobs: locate the part repeatably, and hold it while the cutter pushes on it. Those are different requirements. A vise locates well enough for a bracket and badly for a thin plate that bows 0.2 mm under clamping. Soft jaws bored to the part profile, or a dedicated plate with dowel pins and swing clamps, solve both.

Clamping force is where most position problems start. A 40 kN hydraulic clamp on a 6 mm aluminium wall will distort the part, and the distortion relaxes when you unclamp. The machined face is then flat in the fixture and bowed on the bench. Use the minimum force that stops vibration, support thin sections from below, and clamp over a rib or boss rather than a free span.

For parts with a 4,000 mm maximum processing size, thermal growth matters as much as clamping. Aluminium expands about 23 μm per metre per °C. A 1,000 mm part that warms 5 °C during roughing moves roughly 0.1 mm. On a ±0.005 mm feature that is the whole tolerance. Let the part cool before the finishing pass, or finish in the same thermal condition you inspect in.

Chip evacuation also belongs in the fixture conversation. Pockets that trap chips push the part off its stops on the next cycle. Add clearance under the part, aim coolant at the pocket floor, and program a chip-break dwell if the material is gummy.

On a 3-axis mill, the workpiece position is fixed for the whole cycle. The table moves in X, Y and Z, and the part never rotates. Every face you cannot reach from the top needs a new setup: unclamp, flip, re-indicate, re-set Z. Each flip resets the datum, and each reset adds its own error. Two setups on a tight-tolerance part are common. Four is a warning sign.

A 4-axis machine adds one rotary axis, usually A around X. The part can be indexed to several faces while staying clamped to the same fixture and the same datum. That removes the flip-and-re-indicate loop and typically cuts position error by the number of setups you eliminated. It is the right answer for shafts with cross-holes, or a part with features on four sides of a prism.

A 5-axis machine adds a second rotary axis, so the tool can approach the part from almost any direction while the part stays in one position. Simultaneous 5-axis also lets you tilt a ball-nose cutter to keep the contact point at the optimum angle, which improves surface finish and tool life on contoured surfaces. GreatLight runs 16 simultaneous 5-axis machining centers alongside 12 four-axis mills and 27 three-axis machines, so the setup count is chosen from the geometry, not from what happens to be free.

The catch: 5-axis does not remove the datum problem, it hides it. Rotary axis centreline error, trunnion squareness and the distance between the rotary centre and the part all become position variables. A 5-axis machine needs its rotary axes calibrated and its post-processor matched to the machine. Otherwise parts come off correct in the flat and wrong on the angle.

Setup time is the invisible line item. A part that machines in 12 minutes but needs three setups spends 40 minutes on the spindle. Fixtures have to be designed, made and proved. A custom plate with dowel pins can take a day. That cost is fine on a 5,000-part run and hard to justify on three prototypes. It is also why prototype geometry should avoid features that need a fourth and fifth face.

Design for manufacturability and position are the same conversation. A deep pocket on the underside of a part forces a flip. A cross-hole at 30° forces either a rotary setup or an angled fixture. Moving that hole to a face that the first setup already reaches can remove an entire operation and a whole class of position error.

Tolerances should match the datum strategy. If the drawing gives a ±0.005 mm position tolerance on a hole referenced to a rough edge, the shop has to build a fixture that finds a better datum, or the tolerance is not achievable at a sane cost. Reference the tight tolerance to a machined hole or face and it becomes routine.
