The die is the part. Everything downstream, from flash to porosity to the position of a boss, is set by the tool steel and the cooling layout inside it. When a factory designs and cuts its own molds, the engineer who reviewed your DFM can walk to the machine and change a gate. When the mold is brokered out, that feedback loop breaks and you become the messenger between two suppliers.

A custom metal die casting factory china buyers keep on their approved list usually runs simulation before steel is cut. Filling, solidification and shrinkage get checked on screen, and the gate position is adjusted while it is still cheap to change. This step costs a day and saves a weld or a scrapped die.

Ask one direct question: who cuts the cavity insert, and on what machine? If the answer involves a partner company, add a week to your first article and a layer of blame when dimensions drift. If the answer is an in-house shop, ask to see the electrode or insert before assembly.

Tooling also sets your floor on wall thickness. Thin walls freeze before the metal fills the far corner. Thick walls pull porosity toward the center. Neither is a machining problem you can fix later.

• 1
  Look forIn-house mold design, simulation and first-article report
• 2
  Ask aboutGate and runner changes after the first shot
• 3
  Watch forTool steel grade listed only after you ask

Die casting is a near-net process. A well-run cell holds roughly ±0.1 mm on small features, and looser on long dimensions as the die heats up across a shift. If your drawing calls for ±0.05 mm on a bore, casting alone will not get there. That is normal, and it is not a reason to reject a factory.

The question is what happens next. A factory with CNC on site can cast with stock and then machine the sealing faces, bores and bearing seats to ±0.005 mm, with finishes from Ra 0.2–0.8 μm up to Ra 1.6–3.2 μm depending on the cut. A factory without CNC ships the casting and lets someone else own the final dimension.

This split matters for cost. Machining every surface is slow and expensive. Good practice is to cast the shape, then machine only the datums and the functional surfaces. Bring that list to the quote so the price reflects real work, not a blanket machining allowance.

One more detail: datum choice. If the casting has no machined datum, the machinist has to invent one, and your first article may pass while part 500 does not. Specify the datum on the drawing.

• 1
  Cast only±0.1 mm on small features, good for covers and housings
• 2
  Cast plus CNC±0.005 mm on machined features, Ra 0.8–1.6 μm typical
• 3
  AvoidTolerancing every surface when three would do

Certificates are a starting filter, not a verdict. ISO 9001:2015 covers the quality system. IATF 16949:2016 adds automotive process controls such as PFMEA, control plans and traceability. ISO 13485:2016 is the medical route. ISO 27001:2022 speaks to how your drawings and CAD files are stored.

The trap is scope. A factory can hold a certificate for one plant, one process or one product family. Ask which site and which process your order will run through, then check that the certificate names it. A Dongguan plant and a partner workshop are not the same entity.

Then ask for the actual records: material certificates for the alloy heat, in-process checks, and a final inspection report before shipment. 100% inspection before shipment is a reasonable expectation, and reports should be available on request rather than argued over.

If your part is medical or automotive, add a first article inspection report and a control plan to the purchase order. It costs a few days and prevents a shipment that arrives with no paper trail.

• 1
  SystemISO 9001:2015 for general industrial work
• 2
  AutomotiveIATF 16949:2016 with PFMEA and control plan
• 3
  MedicalISO 13485:2016 plus full traceability
• 4
  DataISO 27001:2022 for file handling, NDA on request

Two numbers tell you how a factory is set up: the smallest order it will take and the time from drawing to quote. A plant tooled for 10,000-piece runs often prices a single prototype badly, and a prototype shop struggles with volume repeatability. The useful answer is a range, from one piece to 10,000+ parts, with the same process route on both ends.

Lead time is where quotes get soft. Break it into pieces. DFM and quotation inside 12 hours. Production start within 24 hours of a released drawing. Parts shipping in 3–5 days for machined work. If a supplier gives one number for the whole job, ask which step it measures.

Push on the quote pack. It should list the alloy, the casting process, the machined features, the finish, the inspection plan and the packing method. A price with no assumptions is not comparable to a price with them.

Cost drivers are mostly alloy, wall thickness, tooling complexity and how much CNC you add. Magnesium and titanium alloys cost more and need different handling than ADC12 aluminum. Say so up front so the first quote is close to the last.

• 1
  Order rangeOne prototype to 10,000+ part runs, no minimum
• 2
  QuoteDFM and price within 12 hours
• 3
  ShippingMachined parts in 3–5 days after release
• 4
  FilesSecure uploads, NDA available on request

A casting that leaves the cell is not a finished part. It needs trimming, deflashing, tumbling or bead blasting, then whatever the drawing calls for: anodizing, plating, powder coating, or laser marking with a minimum character height of 1.5 mm. Each handoff between suppliers is a chance for a scratch or a lost lot.

Keeping finishing in the same building shortens the route and keeps the inspection data with the part. Anodizing can be clear, colored, hardcoat or conductive, and each changes a dimension slightly. If a bore is anodized after machining, tell the machinist so the pre-plate size accounts for it.

For prototypes, the bridge matters. A factory that can run vacuum casting or 3D printing while the die is being cut lets you test fit and function weeks earlier. Then the die arrives already validated against real parts.

Ask who packs the parts and how. Foam, trays and labeled bags are small costs that prevent a claim on delivery.

• 1
  Common finishesAnodizing, electroless nickel, zinc, powder coat, black oxide
• 2
  MarkingLaser engraving with 1.5 mm minimum character height
• 3
  BridgeVacuum casting or 3D printing while the die is cut
