PEEK is a semi-crystalline thermoplastic with a continuous service temperature up to 260 °C. It resists fuels, solvents and steam, burns with low smoke, and holds strength at a fraction of steel's weight. Those properties are why it shows up in aircraft fittings, surgical instruments, semiconductor fixtures and EV connectors.

The same properties make it hard to cut. PEEK conducts heat poorly, so heat stays at the tool tip instead of flowing into the chip. Above roughly 300 °C the surface can soften, smear and pick up material. A good PEEK CNC machining service controls heat at the edge, not at the machine enclosure.

PEEK also has a high thermal expansion compared with metals. A part machined at 25 °C and measured at 20 °C will read differently. For a ±0.005 mm callout on a long feature, the shop should say what temperature the measurement was taken at and whether it let the part stabilize first.

Chip formation is another factor. PEEK cuts into stringy chips that wrap around the tool and scratch finished surfaces. Tool geometry, feed per tooth and chip evacuation matter more here than on a 6061 aluminium job, where almost any reasonable cutter works.

• 1
  Poor heat conductionHeat concentrates at the cutting edge; coolant strategy decides surface quality.
• 2
  High thermal expansionMeasure at a controlled temperature, after the part has cooled and stabilized.
• 3
  Stringy chipsPlan chip evacuation and keep finished surfaces away from the chip path.
• 4
  Grade mattersUnfilled, glass-filled and carbon-filled PEEK machine very differently. State the grade on the drawing.

Through-tool high-pressure coolant is the baseline for deep pockets and long bores. It pushes chips out and pulls heat away at the point where it is generated. For some medical parts, a mist or filtered compressed air is preferred so no fluid residue remains in the part. The choice has to be made per part, not per shop.

Coolant type matters as much as pressure. Some fluids leave residues that are hard to remove from porous or textured PEEK surfaces. If the part goes into a cleanroom or a body-contact application, ask what fluid is used and how the part is cleaned afterwards.

Internal stress is the quiet problem. Extruded PEEK bar carries residual stress from the extrusion process. When you remove material, the balance changes and the part can bow, twist or open up a bore. Annealed stock and a balanced material-removal sequence reduce this. Rough, stress-relieve, then finish is the standard route for tight parts.

For thin walls and long parts, the sequence matters more than the final pass. Take material off both sides in turn, leave uniform stock for the finishing cut, and avoid removing a large amount from one face before touching the other.

• 1
  Ask for the anneal stateAnnealed bar costs more but holds size after machining.
• 2
  Rough and relieveLeave 0.3–0.5 mm for finishing, then let the part rest before the final cut.
• 3
  Balance removalAlternate faces so stress releases evenly instead of pulling one way.
• 4
  Keep coolant dataRecord pressure, fluid type and filtration for traceable medical work.

A supplier claiming ±0.005 mm across a whole PEEK part is describing a best case, not a default. On a 20 mm bore in a stable fixture, that tolerance is reachable. On a 300 mm thin-wall housing, it is not, because thermal drift and stress release move the part after the cut.

The practical approach is to quote tolerance per feature. Diameters held in a collet or a soft jaw can be tight. Long unsupported walls, thin flanges and features far from the fixture need more room. If a drawing applies one blanket tolerance to every dimension, expect either a high price or a hard conversation later.

Surface finish follows the same logic. As-machined PEEK usually lands between Ra 1.6 and 3.2 μm. Careful finishing with sharp tooling and controlled feed can reach Ra 0.8–1.6 μm. Below that, you are polishing, and polishing PEEK risks embedding media in the surface.

If the part needs a specific finish for sealing, sliding contact or optical reasons, say so on the drawing. 'Good finish' is not a specification. Give a number and a measurement method.

• 1
  Tight where supportedBores and short features can hold ±0.005 mm in good fixturing.
• 2
  Looser where unsupportedLong walls and thin flanges need realistic limits.
• 3
  Ra 0.8–1.6 μmAchievable with sharp tooling and light finishing passes.
• 4
  Name the methodState whether finish is checked by profilometer or comparison sample.

Start with the DFM response. A supplier that returns only a price has not looked at the part. A useful response flags thin walls, deep pockets, tolerance conflicts and grade questions. At GreatLight, quotation and free DFM analysis come back within 12 hours, and production can start within 24 hours after approval.

Check the machine list against the part geometry. A 4,000 mm maximum processing size covers long housings and manifolds. Simultaneous 5-axis work suits complex medical and aerospace shapes that would otherwise need several setups. More setups on PEEK means more chances for stress movement and surface damage.

Confirm the quality system matches your industry. ISO 9001:2015 covers general process control. IATF 16949:2016 applies to automotive and EV programs. ISO 13485:2016 is the medical device standard. ISO 27001:2022 covers information security, which matters if you send proprietary drawings and CAD files.

Finally, agree on inspection before the first chip is cut. Ask which features are measured, on what instrument, and what documentation ships with the parts. Reports are available on request, and 100% inspection before shipment is the standard here, not an upgrade.

• 1
  DFM before priceA real review catches problems that a quote alone hides.
• 2
  Match the machine to the shapeFewer setups mean less stress movement and less handling damage.
• 3
  Match the certificate to the industryMedical, automotive and general industrial work need different systems.
• 4
  Agree inspection up frontDecide the measured features and the report format before production.

Machined PEEK is usually a low-volume answer. You machine it when the part is too complex for molding, when the volume does not justify a tool, or when you need parts before a mold is ready. Runs from a single prototype to 10,000+ pieces are normal here, with no minimum order quantity.

Lead time depends on stock availability and how much process control the part needs. Standard flow is a quote and DFM analysis within 12 hours, production start within 24 hours, and parts shipping in 3–5 days. Parts with tight tolerances, special grades or cleanroom handling take longer, and a supplier should tell you that at quote time.

Confidentiality is a real concern when drawings carry implant geometry, fuel system details or semiconductor tooling. Uploads are handled as secure and confidential, and an NDA is available on request before you send files.

Put the grade, anneal state, tolerance per feature, finish value and inspection requirement on the purchase order. Everything a supplier needs to quote accurately belongs there. Missing details usually come back as assumptions, and assumptions on PEEK are expensive.

• 1
  No minimum orderOne prototype or a 10,000-piece run both fit the same process.
• 2
  12-hour quoteDFM analysis comes with the quotation, not after it.
• 3
  3–5 day shippingTypical for standard parts once production starts.
• 4
  NDA on requestSign before sending sensitive drawings or CAD files.
