A custom milling and turning order is not one operation. It is a queue of operations that have to touch the same part in the right order. Quoting is step one. Programming, material pull, first-article setup, roughing, finishing, secondary work and inspection all sit behind it.

Speed comes from overlapping those steps, not from spinning the spindle harder. On a simple bracket, three setups run back to back and the part ships. On a housing with a turned bore and milled faces on five sides, the milling and turning cells can be programmed at the same time. That overlap is where days disappear.

The word custom also sets a boundary. If a part already exists as a standard bushing or plate, buying stock is faster than machining it. Custom work earns its lead time when geometry, tolerance or material is not available off the shelf.

• 1
  One part, several operationsSetup count drives cycle time more than spindle speed.
• 2
  Overlap beats hustleParallel programming and fixturing remove days, not minutes.

You cannot schedule a job on a machine that is already booked. A shop with one 5-axis center and thirty three-axis mills will quote 5-axis work slowly, because the bottleneck is one spindle. Capacity spread matters more than the total machine count on the brochure.

GreatLight runs 127 high-precision CNC machines: 16 simultaneous 5-axis centers, 12 four-axis mills, 27 three-axis machines and 16 mill-turn centers. The mill-turn group is the useful one for custom turning work. A mill-turn center completes a turned diameter and a milled flat in one setup, so a part that would need two fixtures on separate machines only needs one.

Size sets the second boundary. Maximum processing size is 4,000 mm, with travels of 4,000 × 400 × 150 mm for long parts and 750 × 1,150 × 550 mm or 600 × 600 × 600 mm for the medium envelope. A part that fits the small envelope at 500 × 500 × 450 mm can be nested with others and run in a shorter window.

• 1
  Mill-turn removes a setupTurned and milled features on one spindle, one datum.
• 2
  Pick the envelope firstOversized parts wait for a specific machine, not for material.

Most of the schedule is decided at the drawing stage. A deep pocket with a 2 mm corner radius forces a small cutter, light passes and long cycle time. Open the corner to 6 mm and the same pocket runs with a stiffer tool. Nothing about the function changes.

Thin walls behave the same way. Below roughly 1 mm on aluminum, the part deflects under cutting force and the operator has to slow down or add support. Above that, roughing and finishing can run at normal feeds. If the wall is not structural, thickening it is the cheapest schedule fix available.

Tolerances are the third lever. Holding ±0.005 mm on a critical bore is routine on a good machine, but applying that callout to every dimension on the print forces in-process checks that add hours. Put the tight tolerance where it does work. Let the rest sit at general tolerance.

Undercuts are the honest exception. A feature that cannot be reached from any single tool direction needs either a 5-axis setup or an extra fixture. Sometimes the drawing can be changed. Sometimes it cannot, and the part pays for it.

• 1
  Corner radiusBigger radius means a stiffer cutter and shorter cycle.
• 2
  Wall thicknessUnder 1 mm in aluminum slows everything down.
• 3
  Tolerance scopeTight callouts only where they are measured.
• 4
  UndercutsEither 5-axis or an extra fixture. No shortcut.

Soft jaws and custom fixtures are built before the first good part exists. That build time is real and it does not shrink because the order is urgent. It shrinks when the part has a flat face, a clean datum and enough stock to hold.

A part with no natural clamping surface forces the shop to make a fixture just to hold it while making the fixture. That loop costs a day. Adding a clamping boss or a flat pad to the blank, removed in the last operation, breaks the loop cheaply.

Datum strategy matters too. If the drawing dimensions everything from a turned bore, the turning operation has to run first, and the mill waits. If the drawing allows a milled face as the primary datum, the two cells can start at the same time. The part geometry is identical. The schedule is not.

• 1
  Give it something to holdA flat pad or boss can cut a full day of fixture work.
• 2
  Choose a datum that frees both cellsA shared datum lets turning and milling start together.

Aluminum 6061 and 6061-T6 machine quickly and hold tolerance well. They are the default for quick-turn work, and most of the schedule risk on an aluminum part comes from geometry, not from the metal. 7075 and 2024 are stronger but gummier, so feeds drop and cycle time rises.

Stainless 303 and 304 behave differently. 303 is free-machining and predictable. 304 work-hardens at the cut, so a light pass with a dull tool makes the next pass harder. Operators compensate with heavier chiploads and more coolant. That is a known cost, not a surprise.

Titanium TC4 (Ti-6Al-4V) and Inconel sit at the slow end. Low thermal conductivity pushes heat into the tool, so cutting speeds fall sharply and tool changes become frequent. These parts are still machinable to ±0.005 mm, but the schedule reflects the physics.

Plastics are the opposite case. POM and ABS cut fast, but they move with temperature and clamp pressure. PEEK holds better at temperature but costs more per blank. On a plastic part, the tight tolerance is often better placed on a metal insert.

• 1
  Aluminum 6061Fast, stable, the default for quick turn.
• 2
  Stainless 304Work-hardens. Heavier chipload, more coolant.
• 3
  TC4 and InconelHeat stays in the tool. Speeds drop.
• 4
  POM and ABSCut fast, but move with heat and clamping.

Finishing is a separate queue with its own time. As-machined surfaces land at Ra 1.6–3.2 μm. A high-finish callout of Ra 0.8–1.6 μm is common on sealing faces and bearing bores. Fine finishing at Ra 0.2–0.8 μm needs a dedicated pass and a tool in good condition.

Anodizing, plating, powder coating and black oxide are handled in-house, which removes the shipping leg that usually adds two days. Clear, color and hardcoat anodizing all change the part dimension slightly. Hardcoat builds more than clear, so a bore dimensioned before coating must account for it on the drawing.

Bead blasting and tumbling are fast and rarely drive the schedule. Polishing and brushing are manual and scale with part count. Laser marking is quick, but character height has a floor of 1.5 mm; a 1 mm logo will not read cleanly and will need a rethink.

The practical point: decide the finish before the first chip. A finish change after machining can mean re-machining a dimension or a second handling trip.

• 1
  Ra 0.2–0.8 μmFine pass, fresh tool, slower feed.
• 2
  Hardcoat anodizingBuilds dimension. Design the allowance in.
• 3
  Laser markingMinimum character height 1.5 mm.

Inspection on a critical part is not a final gate. It runs in three places: raw material check on arrival, in-process monitoring during machining, and final inspection before shipment. Every part is inspected before it leaves.

That structure is what makes a 99.99% qualification rate meaningful. On a first article, the operator measures the feature that sets the datum and adjusts the offset before running the rest. Catching a drift at part two is cheap. Catching it at part two hundred is not.

Reports are available on request. For aerospace, automotive and medical work, the certification set matters: ISO 9001:2015, IATF 16949:2016, ISO 13485:2016 and ISO 27001:2022. A shop without the relevant certificate adds an audit step you have to run yourself.

If your part has a functional dimension, say so at quoting. It will be measured in-process instead of at the end, and that change rarely costs time.

• 1
  Three inspection pointsIncoming material, in-process, final.
• 2
  Reports on requestAsk at quoting, not after shipment.
