Machine hour rate is the number most buyers ask about first, and it is also the least useful on its own. A 3-axis mill at a low hourly rate can cost more per part than a 5-axis center at a higher rate, because the 5-axis machine finishes the part in one setup. The rate only tells you what an hour costs. Cycle time tells you how many hours you are buying.

Cycle time comes from the geometry. Deep pockets, thin walls, interrupted cuts and hard material all add minutes. Aluminum 6061 cuts fast and forgives a light fixture. Inconel or Ti-6Al-4V cuts slowly and needs a rigid setup, so the same feature can take three to five times longer. If a quote looks high, ask which feature drives the time.

Setup and fixturing are charged once per batch, not once per part. On a 10-piece order, setup can be 40 percent of the price. On a 5,000-piece order, it nearly disappears. This is why the same drawing gets very different unit prices at two quantities, and why comparing quotes at different batch sizes tells you nothing.

Tooling, inspection and finishing sit on top. A custom form tool, a CMM report on every part, or a hardcoat anodize all add cost. None of them are padding. Ask for the line items and you can usually find one or two you do not need on this revision.

• 1
  Machine hour ratePrice of one spindle hour, including operator and overhead.
• 2
  Cycle timeCutting minutes per part, driven by geometry and material.
• 3
  Setup amortizationOne-time cost divided by batch size.
• 4
  Secondary operationsHeat treat, plating, anodize, laser marking.

A usable quote separates material, machining, setup, finishing and inspection. If everything arrives as one lump sum, you cannot tell whether the shop is expensive or whether your part is simply hard to cut. Push back and ask for the split. Most shops will provide it, and the answer usually explains the gap between two quotes.

Material is quoted by weight plus a cut charge. The price you see online is a mill price for a full bar or plate. A shop buying 3 kg from a service center pays a premium, and small quantities of titanium or Inconel carry a bigger premium than aluminum. If your material is exotic, expect the material line to be a real share of the total, not a rounding error.

Machining is quoted in minutes. Ask for an estimated cycle time per part and the rate applied to it. A shop quoting 12 minutes at a high rate may still beat a shop quoting 30 minutes at a low rate. When you have both numbers, the comparison becomes arithmetic instead of trust.

Setup, programming and inspection are quoted per order. These lines do not shrink when quantity grows, so they are the first place to look when a low-volume quote feels heavy. For a one-off prototype, fixture design can legitimately cost more than the cutting.

Three-axis work is the cheapest per hour and should be the default for prismatic parts. Plates, brackets, housings and covers with features on one or two faces run well on a 3-axis machine, especially when quantities are high and the fixture can be dedicated. If your part fits this description, paying for 5-axis time is waste.

Four-axis adds a rotary table, so you can machine around a cylindrical part without re-fixturing. Shafts, flanges and parts with features on four sides are good candidates. The saving is real: every re-fixture costs setup time and adds a chance of losing datum. On a part with four machined faces, a 4-axis run often beats two 3-axis ops.

Five-axis earns its rate when the part has compound angles, deep cavities, or features that a straight tool cannot reach. Medical implants, impellers, aerospace structural parts and complex molds are typical. The gain is not only reach. Shorter, stiffer tools cut faster and leave a better finish, so a 5-axis cycle can be shorter than the 3-axis version despite the higher hourly rate.

Undercuts, organic surfaces and five-sided parts are where 5-axis wins. Simple flat parts are where it loses. Match the machine to the geometry, not to the shop's brochure.

Every decimal place you tighten adds cost. A general machining tolerance of ±0.1 mm is cheap and suits most brackets. Moving to ±0.025 mm requires better fixturing, temperature awareness and more frequent in-process checks. At ±0.005 mm you are paying for a controlled process, not just a good machine.

Surface finish behaves the same way. As-machined Ra 1.6–3.2 μm is the baseline. A Ra 0.8–1.6 μm finish usually needs a finishing pass with a smaller stepover, which adds cycle time. Ra 0.2–0.8 μm often means a separate operation, sometimes on a different machine. Specify the finish the function needs, not the best number on the drawing.

Inspection is the quiet cost. A first-article report on a new part is normal and useful. Full dimensional reports on every part in a 5,000-piece run are expensive and usually unnecessary if the process is stable. Ask what is measured, how often, and whether the report is on paper or in a digital file.

One practical rule: tolerance and finish should be driven by the mating part and the function. Loose numbers on non-critical faces reduce cycle time without hurting the assembly.

Outsourcing wins when demand is uncertain, when the part mix changes often, or when the required process is outside your current capability. A contract shop with 127 machines can move your job to the right spindle without you buying a second machine for one program. You pay for capacity only when you use it.

Outsourcing also wins on certification-heavy work. If your part needs IATF 16949 or ISO 13485 traceability and your own shop is not audited for it, the paperwork alone can take months. A qualified supplier already holds the certificates and the process controls. That removes a schedule risk you cannot easily absorb.

Buying makes sense when a part is high volume, stable, and central to your product. If you machine the same geometry every week for years, the capex amortizes and you control the schedule. Below that threshold, the machine sits idle between jobs and the hourly cost you calculated on paper never materializes.

A hybrid route is common and often best: keep simple, high-volume parts in-house and send complex or low-volume work out. The decision is per part, not per company.
