  Step by step: qualifying a CNC custom parts supplier

A ±0.005 mm number on a website means little on its own. The real question is which machine holds it, on what material, at what size. A 5-axis centre with a Ø400 mm rotary table behaves differently from a 3-axis mill cutting a 4,000 mm frame. Ask the shop to name the machine and the travel envelope for your part.

Thermal drift, tool runout and fixture stiffness all push a cut off nominal. On aluminium 6061-T6, a well-fixtured 5-axis pass can hold ±0.005 mm across a 200 mm feature. Stretch that feature to 1,500 mm and the same shop will likely ask for ±0.02 mm. That is normal. A supplier who never adjusts the number is guessing.

Surface finish follows the same logic. Ra 0.8–1.6 μm is a standard machined finish. Ra 0.2–0.8 μm needs a finer stepover, a sharper tool and often a second operation. Put both the tolerance and the finish on the drawing. If the shop returns a quote without commenting on either, the quote is not real yet.

• 1
  Name the featureTolerance applies to a specific dimension, not the whole part.
• 2
  Check the envelope4,000 × 400 × 150 mm is the largest documented travel here.
• 3
  Separate finishRa 0.2–0.8 μm usually means an extra finishing pass.

Quotes often collapse everything into one number: 10 days. That hides the three clocks that actually matter. Clock one is the quote and DFM review. Clock two is production start. Clock three is shipping. A shop that quotes in 12 hours and starts cutting within 24 hours is running a different operation than one that quotes in a week.

Parts shipping in 3–5 days is realistic for a clean prototype job with stock material on the shelf. It is not realistic for titanium TC4 with a hardcoat anodize, because the finishing step sits outside the machine shop. Plan the finishing route before you commit to a date.

Ask about late delivery history. A shop tracking its own on-time rate and reporting a late-delivery probability below 2% is measuring something. A shop that answers with a promise and no data is not. Historical numbers are a better guide than optimism.

• 1
  Quote clock12 hours including free DFM analysis.
• 2
  Start clockProduction can start within 24 hours of approval.
• 3
  Ship clock3–5 days for standard jobs, longer with outside finishing.

Minimum order quantity is a tell. A shop with no MOQ is set up for prototypes and low-volume runs, from one part to 10,000+ parts. A shop with a high MOQ is set up for production and will price your single prototype high on purpose. Neither is wrong. Mixing them up wastes weeks.

For prototypes, the cost driver is programming and setup, not material. One part can cost more than ten because the setup is paid once. Ask how the shop amortizes setup across a 10-piece and a 1,000-piece order. The answer shows whether the quote was built or copied.

Material choice moves the price more than most buyers expect. Aluminium 6061 and 6082 machine fast and are cheap. Inconel, titanium TC4 and 17-4PH stainless cut slowly, wear tools and need lower feed rates. If a quote for Inconel comes back close to aluminium, ask what alloy was actually priced.

• 1
  No MOQOne prototype and a 10,000-part run use the same process route.
• 2
  Setup dominatesAt low volume, programming and fixturing outweigh material cost.
• 3
  Alloy mattersInconel and titanium cut far slower than 6061 aluminium.

ISO 9001:2015 is the baseline. It says the shop has a documented quality system. It does not say the shop can hold your tolerance. IATF 16949:2016 matters if your part goes into an automotive or EV program, because it adds traceability and change-control requirements. ISO 13485:2016 does the same for medical devices.

ISO 27001:2022 covers information security. That sounds distant from machining, but it matters when you upload CAD files and process documents. A shop holding it has controls around who can access your drawings and how long they are kept. For defense-adjacent or IP-sensitive work, that is a real filter.

Check the certificate scope, not just the logo. A valid ISO 13485 certificate that excludes CNC milling does not help you. Ask for the certificate number and the scope statement. Any competent quality manager will send both within a day.

• 1
  ISO 9001:2015Baseline quality system for general industrial parts.
• 2
  IATF 16949:2016Required for most automotive and EV production parts.
• 3
  ISO 13485:2016Medical device supply, adds validation and traceability.
• 4
  ISO 27001:2022Information security around your drawings and files.

A shop listing five aluminium grades and nothing else is a general job shop. A shop carrying 6061, 7075, 17-4PH, Inconel, TC4 titanium and PEEK is serving aerospace, medical and energy work. The material list is a shortcut to the industries a supplier actually supports.

Finishing is where schedules break. Anodizing, electroless nickel, powder coating and laser marking are usually outside processes. A shop that manages them in-house or through qualified partners controls the date. A shop that hands you a phone number does not. Laser marking has a practical floor too: minimum character height around 1.5 mm.

For robot arms, EV brackets and aerospace housings, the combination of 5-axis capacity, material range and finishing control is what keeps a program on schedule. None of those three works alone.

• 1
  Aluminium6061, 7075, 2024, 6082 and ADC12 cover most brackets and housings.
• 2
  Stainless and steel303, 316L, 17-4PH, 4140 and tool steel for wear and corrosion.
• 3
  High-temp alloysInconel and TC4 titanium for aerospace and energy.
• 4
  FinishingAnodizing, plating, powder coat, bead blast and laser marking.
