Can A CNC Machine Cut Metal?

CNC Metal Cutting Explained: Your Complete FAQ Guide

This comprehensive FAQ addresses common questions about CNC machining for metal fabrication. Whether you’re a prototype designer, workshop manager, or manufacturing engineer, you’ll find clear answers to technical and operational challenges. We cover material compatibility, tool selection, troubleshooting, and optimization – all grounded in industry standards like ISO 13399 and practical shop-floor experience.

Core Metal Cutting Capabilities

### What metals can CNC machines cut?

A1. Yes, CNC machines expertly cut steel, aluminum, brass, titanium, and specialty alloys (e.g., Inconel) using milling, turning, or laser operations.

A2. Performance depends on machine rigidity, spindle power, and cooling. While routers handle soft metals like aluminum, cutting hardened steel requires industrial-grade CNC mills (15+ HP spindle). Laser CNCs excel on thin sheets via vaporization, but struggle with reflective metals like copper without specialized optics.

A3. Confirm your material’s hardness (Rockwell C scale) and match it to your machine’s specifications. Refer to our metal machinability chart (link here) for recommended feeds/speeds.

### Can a CNC router cut metal like a mill?

A1. Yes, but only for light-duty, thin (<⅜”) non-ferrous metals such as aluminum or brass under controlled conditions.

A2. Routers lack the structural rigidity, torque, and coolant systems of dedicated CNC mills. Vibration during steel cutting causes premature tool wear and dimensional inaccuracy. Industrial mills use box-way construction and flood coolant for chip ejection — critical for ferrous metals.

A3. For metal thicker than ¼”, use a CNC mill. If using a router:

• Reduce depth of cut to ≤1mm
• Employ climb milling to minimize chatter
• Apply lubricant manually every 2–3 minutes (Insert tool wear comparison diagram here)

Machine Setup and Optimization

### How do I prevent tool breakage when cutting hard metals?

A1. Prevent breakage by optimizing feed rates, using coolant effectively, and selecting coated tools (e.g., TiAlN for steel).

A2. Common causes of breakage:

• Excessive chip load (force per tooth) from incorrect feed/speed calculations
• Workpiece vibration from inadequate fixturing
• Thermal stress from insufficient cooling in metals like titanium

Reference ANSI/ASME B94.55M for chip load formulas.

A3.

1. Calculate feeds/speeds using chip load = feed rate / (RPM × number of flutes)
2. Secure parts with step clamps or vacuum plates
3. Use through-tool coolant when slotting deep pockets (Refer to clamping force guideline here)

### Why is my cut surface rough or burnt?

A1. Roughness stems from dull tools, improper speeds, or inadequate chip clearance; burning indicates excessive friction/heat.

A2. Aluminum smears when chips weld to tools (built-up edge). Stainless steel work-hardens if federate is too slow. Burnt edges in plasma/laser cutting arise from incorrect gas pressure or focus.

(Insert chip formation comparison infographic here)

Material-Specific Challenges

### Can CNC cut stainless steel cleanly?

A1. Absolutely—with carbide tools, high-pressure coolant, and optimized parameters.

A2. Stainless steel’s high toughness and low thermal conductivity require:

• Constant feed to prevent work-hardening
• Sharp tools with high helix angles (≥45°)
• Coolant concentrations ≥10% for thermal management

A3. Follow this protocol for 304 stainless:

1. RPM: 280–320 SFM (e.g., ½” tool: 2,150–2,450 RPM)
2. Feed: 0.003–0.005” per tooth
3. Depth of cut: ≤ tool diameter × 1.5

### How thick of metal can a CNC plasma cutter handle?

A1. Industrial plasma systems cut up to 150mm (6”) thick steel, though clean cuts under 50mm are economical.

A2. Capacity depends on amperage:

• 50A systems: ≤12mm
• 100A systems: ≤25mm
• Hypertherm XPR300 (300A): 75mm+

Oxygen plasma produces smoother edges on steel >25mm vs. air plasma. Torch height consistency is critical.

A3. For >20mm steel:

• Use high-definition plasma
• Set standoff distance to 1.5–3mm
• Program lead-ins/outs to prevent edge defects

Maintenance and Troubleshooting

### Why does my CNC vibrate during metal cuts?

A1. Machine vibration (“chatter”) arises from imbalanced tools, worn ball screws, or insufficient rigidity.

A2. Causes hierarchically:

• Primary: Tool runout >0.005”/125μm
• Secondary: Loose workpiece fixturing
• Tertiary: Structural resonance (avoid 90% of spindle max RPM)

Use FFT analyzers to diagnose frequency sources.

A3. Action steps:

1. Measure tool runout with dial indicator; replace collet if >0.003”
2. Check axis preload force (refer to maintenance manual)
3. Adjust RPM by ±10% to escape resonant frequencies

### How often should I replace cutting tools?

A1. Monitor condition hourly; typical tool life for steel:

• HSS: 60–90 minutes
• Carbide: 5–8 hours
• Ceramic: 10–15 hours

A2. Tool failure modes dictate replacement:

• Flank wear >0.012” = replacement
• Edge chipping = immediate discard
• Built-up edge = hone/recoating option

Track via program count or Bluetooth tool sensors.

A3. Implement preventive regimen:

• Log hours/tool digitally
• Check wear every 40 parts
• Recoat tools at 60% wear lifespan (See guidance on modular tooling)

Advanced Applications

### Can CNC machines cut hardened tool steel (HRc50+)?

A1. Yes, via hard milling (using CBN/PCD tools) or EDM processes, not conventional milling.

A2. Limitations:

• High-speed steel tools fail past HRc45
• Hard milling requires:

  • Spherical end mills (reduced cutting pressure)
  • Trochoidal paths
  • Thermal control ≤80°C to avoid tempering

Wire EDM achieves ±0.0002” tolerances in HRc62 steel with non-contact precision.

A3. Recommendation: For small features on hardened dies, out-source to EDM specialists. For prototyping, use thermal-treated D2 steel at HRc30 for machinability.

Summary and Next Steps

CNC metal cutting combines machine capability, tool science, and parameter mastery. For most jobs:

1. Machines matter – Routers ≠ mills for steel
2. Coolant strategy defeats heat
3. Tool costs drop with proper feeds/speeds

Need hands-on assistance? Download our Metal Cutting Cheat Sheet with industry-approved parameters for 37 alloys.

[Summary by Senior Engineer]

Core: CNC broadly handles metals via force/heat management.

Solution Key: Match machine rigidity, tool substrate, and cooling to material properties.

Prevention Priority: Monitor tool wear hourly — thermal damage occurs before failure.
