Metal carries heat away in the chip. Plastic does not. In a typical aluminum cut, most of the generated heat leaves with the swarf, and the tool stays cool enough to run dry. Cut POM or ABS the same way and the heat stays in the workpiece. The material softens right at the cutting edge, the chip welds back onto the surface, and you get a smeared finish that no amount of polishing will fix cleanly.

The second difference is elasticity. Aluminum deflects a few micrometres under a 200 N cut. Unfilled PP or LDPE deflects visibly, then springs back after the tool passes. That springback is why a nominal 10.00 mm slot can measure 9.92 mm on a good machine with a sharp cutter. The tool did not wear out. The material moved.

The third difference is thermal expansion. A 100 mm POM part grows roughly 0.1 mm over a 10 °C temperature swing. That is 20 times the tolerance band we hold on metal parts. If the shop measures the part while it is still warm from the cut, the reading is meaningless. Measuring after a cool-down is not optional for plastic work.

So when you compare suppliers for cnc plastic processing, do not ask only about machine accuracy. Ask how they control heat, how they fixture soft material, and how long the part rests before final inspection. Those three answers separate a shop that machines plastic from one that happens to own a CNC.

• 1
  Heat stays in the partAir blast and shallow radial engagement beat heavy flood coolant on most thermoplastics.
• 2
  Springback is realExpect 0.02–0.08 mm of elastic recovery on thin walls in unfilled PP and HDPE.
• 3
  Measure coldLet parts stabilize to room temperature before final inspection, especially on POM and PA.

A general-purpose aluminum end mill will cut plastic, but it leaves a rougher finish and creates more heat than a tool designed for the job. Plastic tooling usually means two flutes, a high helix or a straight flute for chip evacuation, a large rake angle, and a polished flute surface. The polished flute matters. A rough flute drags on the soft chip, and that friction raises the cutting temperature more than the cut itself.

Coatings are mostly unnecessary. TiAlN and AlTiN are designed for hot, abrasive metal cutting. On plastic they add surface roughness and can hold heat at the edge. Uncoated carbide is usually the right choice. The exception is abrasive composites like carbon fibre, where a diamond coating earns its cost by extending tool life several times over.

For spindle speed, the safe range for most unfilled thermoplastics on a 6 mm cutter is 8,000–15,000 rpm with a chipload of 0.05–0.15 mm per tooth. That keeps the chip thick enough to carry heat away without rubbing. Feeding too slowly is the more common mistake, not feeding too fast. A light chip load turns the edge into a polishing tool and heat builds fast.

Depth of cut depends on rigidity. On a stable setup with a 10 mm cutter, 0.5–1.0 mm radial engagement and up to 1× diameter axial depth works well. On thin-wall parts or soft PP, drop radial engagement to 10–15% of the tool diameter and use a high-feed strategy. You trade cycle time for dimensional control, which is usually the right trade on plastic.

• 1
  Two flutes, polishedStraight or high-helix geometry clears gummy chips and reduces rubbing.
• 2
  Skip the coatingUncoated carbide for thermoplastics; diamond only for abrasive composites.
• 3
  Feed, do not rub0.05–0.15 mm per tooth on a 6 mm tool keeps the edge cutting rather than burnishing.

Clamping is where most plastic parts get ruined. A vise tightened to the same torque you would use on steel will leave compression marks, bow the part, and sometimes crack it at a corner. Soft jaws machined to the part profile spread the load. Vacuum fixtures are better still for flat plates, because they apply uniform pressure across the whole face instead of at two points.

Internal stress is the second trap. Extruded or injection-molded plastic stock carries residual stress from the original forming process. When you remove material from one side, the part relieves that stress and bows. The fix is to rough, then let the part rest, then finish. On tight-tolerance work we rough to within 0.5 mm, anneal or rest the part, and take the final passes after stress has moved.

Thin walls need support, not force. A 1.5 mm wall in ABS will deflect under a 50 N side load from a standard clamp. Support it with a machined nest, use light radial cuts, and consider leaving tabs that hold the part until the last operation. Cutting the part free too early lets it move during the finish pass, and the error only shows up at inspection.

Deburring deserves planning too. Plastic burrs are often thin films rather than hard edges. A hand scraper tears them and leaves a white stress mark. A sharp carbide chamfer tool running at high speed and low feed gives a cleaner edge. On transparent parts like PMMA, flame or vapor polishing after machining removes fine tool marks that mechanical polishing cannot reach.

• 1
  Spread the loadSoft jaws or vacuum fixtures, never point contact on a thin wall.
• 2
  Rough, rest, finishLeave 0.5 mm for a final pass after the part has relaxed.
• 3
  Plan the deburrSharp carbide tools, and vapor polishing for clear plastics.

Tolerance on plastic is a negotiation between the drawing and the material. On a rigid, filled plastic like PEEK or glass-filled PA, a capable shop can hold ±0.005 mm on critical features and inspect it reliably. On unfilled PP, HDPE, or thin LDPE parts, ±0.05 mm is realistic and ±0.1 mm is comfortable. A quote that promises metal-level tolerance on soft unfilled stock without any note about material should raise a flag.

Surface finish follows the same logic. As-machined plastic typically lands at Ra 1.6–3.2 μm. With a sharp tool, a fine chipload, and a clean final pass, Ra 0.8–1.6 μm is achievable on POM, ABS, and PC. Below Ra 0.8 μm you are usually polishing, not cutting, and the cost per part climbs quickly. For optical parts in PMMA or PC, specify the finish as a visual standard, not just a number, because cutting marks scatter light differently than a Ra value suggests.

Feature size matters as much as tolerance. Holes below Ø1.5 mm in soft plastic tend to close up after drilling because the material relaxes around the tool. Slots narrower than 2 mm deflect and chatter. If your design has features that small, ask the shop to quote them as a separate operation and confirm they can inspect them with a vision system or optical comparator.

Every dimension you tighten adds inspection time. A drawing with 40 critical dimensions on a plastic part is not the same job as one with 6. We inspect 100% of parts before shipment, and reports are available on request. But if you can mark only the dimensions that matter for function, the quote gets sharper and the lead time shrinks.

• 1
  Match tolerance to material±0.005 mm on filled PEEK; ±0.05 mm on unfilled PP is honest.
• 2
  Ra 0.8–1.6 μm is the sweet spotAchievable with a clean final pass, without extra polishing cost.
• 3
  Mark critical dimensionsFewer specified tolerances mean faster inspection and a sharper quote.

Plastic parts rarely need a mold, which is why cnc plastic processing fits prototypes and bridge production so well. There is no minimum order quantity here. One prototype and a 10,000-part run both go through the same process; only the setup amortization changes. That makes plastic machining a reasonable choice when you need 50 parts next week but are not ready to commit to tooling.

Cost on a plastic part is driven by three things: material price, cycle time, and inspection. PEEK and carbon fibre stock cost far more per kilogram than ABS or POM, and abrasive materials wear tools faster. Cycle time rises when you use light passes to control heat and deflection. Inspection time rises with every tight tolerance on the drawing. If your budget is tight, the fastest lever is usually reducing the number of critical dimensions, not switching suppliers.

Lead time depends on material availability and finish. Standard stock like ABS, POM, and PC is usually on hand, and parts can ship in 3–5 days after drawing approval. Exotic grades may need to be ordered. Vapor polishing or annealing adds a day or two. Ask for the timeline broken into material, machining, finish, and inspection so you can see where the days actually go.

One more cost factor: rework. A plastic part that fails inspection often cannot be re-machined because there is no material left to remove. That is why the first-article inspection matters more on plastic than on metal. Catching a fixturing problem on part one is far cheaper than scrapping a batch of PEEK components.

• 1
  No tooling, no MOQOne part to 10,000+ runs on the same process.
• 2
  Material dominates costPEEK stock can cost 10× more than POM per kilogram.
• 3
  First article saves batchesPlastic parts rarely rework; catch fixture errors early.
