GreatLight – Premium Custom Parts Of A CNC Mill Metal Fabrication
Your one‑stop solution for high‑precision, low‑tolerance Parts Of A CNC Mill in aluminum, steel, copper, brass, and exotic alloys.
Custom Parts Overview
GreatLight is a professional and experienced precision Parts Of A CNC Mill factory in China, delivering state‑of‑the‑art 5‑axis CNC milling, turning, and multi‑axis machining services with a guaranteed tolerance of ±0.001 mm. As an ISO 9001:2015 certified manufacturer and a leading rapid‑prototyping partner, we turn your 3‑D CAD data into flawless metal components—from single prototype pieces to full‑scale production runs.
Our service portfolio covers OEM (Original Equipment Manufacturer) and ODM (Original Design Manufacturer) projects, allowing you to either provide a complete design or co‑develop a new part with our engineering team. Whether you need a complex aerospace bracket, a high‑frequency copper heat sink, a medical‑grade brass valve body, or a series‑production aluminum chassis, GreatLight offers a seamless workflow, on‑time delivery, and uncompromising quality.
Core Advantages & Selling Points
| Advantage | What It Means for You |
|---|---|
| Ultra‑high dimensional accuracy (±0.001 mm) | Eliminates the need for secondary finishing, reduces assembly adjustments, and guarantees perfect fit‑and‑function. |
| 5‑axis simultaneous machining | Enables intricate 3‑D geometries, reduces tool changes, shortens cycle time, and improves surface finish. |
| Full metal portfolio (Al, SS, Cu, Brass & alloys) | One supplier for all your material needs – no re‑quoting, no supply gaps. |
| Rapid prototyping (48‑hour turnaround) | Accelerates product development, allows fast design validation and early market entry. |
| Scalable production (1‑100 k+ pcs) | Flexible low‑volume runs for testing and high‑volume machining for mass production—all on the same line. |
| ISO 9001:2015 & AS9100 certified | Proven quality management system, traceable processes, and compliance with aerospace/medical standards. |
| IP protection & NDA compliance | Secure handling of proprietary designs, encrypted file transfer, and signed confidentiality agreements. |
| Stable, diversified supply chain | Multiple certified material vendors, inventory buffers, and risk‑mitigation plans to avoid shortages. |
| Transparent pricing & cost‑saving strategies | Detailed quote breakdown, volume discounts, and design‑for‑manufacture (DFM) consultancy to lower unit cost. |
| Dedicated technical support (24/7 via WhatsApp, email, and phone) | Real‑time communication, rapid issue resolution, and on‑site engineering assistance if required. |
Suitable Applications
- Aerospace & Defense: Structural brackets, wing spars, turbine housings, heat‑shield components.
- Automotive & Mobility: Engine mounts, transmission housings, electric‑vehicle battery enclosures, custom fasteners.
- Medical & Healthcare: Surgical instruments, implant prototypes, diagnostic device housings, biocompatible components.
- Industrial Equipment: Pump bodies, valve components, gear housings, robotic arm Parts Of A CNC Mill.
- Electronics & Telecom: Heat sinks, RF shields, connector shells, precision antenna brackets.
- Consumer Goods: Luxury watch cases, high‑end audio hardware, custom bike frames, sports equipment.
Quality & Accuracy
Geometric Tolerance – ±0.001 mm (standard)
Surface Roughness – Ra 0.4 µm (default) – customizable to Ra 0.1 µm for optical surfaces.
Material Certification – All batches are accompanied by mill test reports (MTR) or certificates of conformity (CoC).
Our Closed‑Loop CNC Control uses high‑resolution linear encoders and spindle load monitoring to maintain positional accuracy throughout the machining process. In‑process inspection (CMM, laser scanner, and touch probe) ensures each part meets the specified GD&T (Geometric Dimensioning & Tolerancing) before it leaves the floor.
Parameter Table (Typical Machining Limits)
| Parameter | Aluminum (6061‑T6) | Stainless Steel (304) | Copper (C110) | Brass (H62) |
|---|---|---|---|---|
| Max Stock Size | 400 mm × 400 mm × 200 mm | 300 mm × 300 mm × 150 mm | 250 mm × 250 mm × 120 mm | 350 mm × 350 mm × 180 mm |
| Min Wall Thickness | 0.5 mm | 1.0 mm | 0.8 mm | 0.6 mm |
| Typical Feed Rate | 1500 mm/min (up to 3000) | 800 mm/min (up to 1500) | 1200 mm/min (up to 2500) | 1300 mm/min (up to 2600) |
| Spindle Speed (max) | 24 000 rpm | 12 000 rpm | 20 000 rpm | 18 000 rpm |
| Tool Life (typical) | 30 min – 2 h (depending on material) | 20 min – 1 h | 25 min – 1.5 h | 22 min – 1.5 h |
| Coolant Type | Water‑soluble, mist | Flood coolant, oil‑based | Water‑soluble, mist | Water‑soluble, mist |
| Typical Cycle Time | 0.5 – 3 hrs per 100 mm³ | 1 – 4 hrs per 100 mm³ | 0.8 – 3 hrs per 100 mm³ | 0.7 – 3 hrs per 100 mm³ |
All values are indicative; actual parameters are optimized per part geometry and material.
Material Properties Table
| Material | Density (g/cm³) | Tensile Strength (MPa) | Yield Strength (MPa) | Hardness (HB) | Thermal Conductivity (W/m·K) | Typical Applications |
|---|---|---|---|---|---|---|
| Aluminum 6061‑T6 | 2.70 | 310 | 276 | 95 | 167 | Aerospace brackets, automotive frames |
| Stainless Steel 304 | 8.00 | 505 | 215 | 120 | 16 | Food‑grade Parts Of A CNC Mill, medical devices |
| Copper C110 (Electrolytic Tough Pitch) | 8.96 | 210 | 70 | 45 | 401 | Heat sinks, RF components |
| Brass H62 (Free‑Cutting) | 8.50 | 320 | 110 | 70 | 109 | Valves, decorative hardware |
| Titanium Ti‑6Al‑4V | 4.43 | 950 | 880 | 340 | 6.7 | Aerospace, high‑stress components |
| Inconel 718 | 8.19 | 1250 | 1150 | 380 | 11.4 | Jet‑engine Parts Of A CNC Mill, high‑temp molds |
GreatLight can source additional alloys (e.g., 7075‑Al, 316L SS, Monel, Hastelloy) upon request.
Machining Instructions & Best‑Practice Guidelines
- File Preparation
- Submit CAD data in STEP AP203/214, IGES, or native SolidWorks/Inventor files.
- Ensure model is watertight, with no duplicated faces or stray edges.
- Provide GD&T annotations directly on the model or in an accompanying 2‑D drawing.
- Feature Recognition & Tool Selection
- Use our in‑house CAM software (Mastercam 2024) to automatically detect pockets, slots, contours, and drill holes.
- Tool material: Carbide (solid or indexable) for aluminum & brass; Cobalt‑based or TiAlN‑coated for steel & titanium.
- Tool diameters: Minimum 0.5 mm for fine features, up to 20 mm for roughing.
- Cutting Parameters
- Aluminum: High spindle speed, light feed, generous coolant.
- Stainless Steel: Lower speed, higher feed, flood coolant to avoid chip welding.
- Copper: Moderate speed, high feed, mist coolant to prevent surface smearing.
- Brass: Similar to aluminum but with reduced spindle speed to avoid work‑hardening.
- Fixturing
- Use vacuum tables for thin plates (≤ 3 mm).
- CNC‑compatible vises, modular clamps, and custom fixtures for complex shapes.
- All fixturing is inspected for parallelism (≤ 0.02 mm) before machining.
- In‑Process Inspection
- After roughing, a probe‑based CMM checks critical dimensions.
- If deviation exceeds ±0.005 mm, the program is automatically re‑optimized.
- Post‑Processing
- Deburring (manual or automated brush).
- Surface finishing: Anodizing (Al), passivation (SS), electroless nickel (Cu/Brass), or polishing to Ra 0.1 µm on demand.
- Packaging & Shipping
- Parts Of A CNC Mill are packed in anti‑static, moisture‑controlled bags.
- For high‑precision shipments, we use ISO‑standard cushioning and GPS‑tracked logistics.
Custom Guide – From Concept to Delivery
| Stage | What You Do | What GreatLight Does |
|---|---|---|
| 1. Inquiry | Send part geometry, material, quantity, tolerance, and required finish. | Provide preliminary feasibility feedback, suggest DFM improvements, and issue a non‑binding quote. |
| 2. Design Review | Share 2‑D GD&T drawing (if available). | Conduct a Design‑for‑Manufacturability (DFM) analysis, recommend tool path optimizations, and confirm tolerances. |
| 3. Quote Confirmation | Approve the detailed quotation (breakdown of machining, material, finishing, inspection, packaging). | Issue a formal Pro‑Forma Invoice and lock in material prices for up to 30 days. |
| 4. Production Planning | Sign NDA & IP protection agreement. | Allocate CNC cells, schedule material procurement, and set up fixture design. |
| 5. Machining | Optional: Provide live CAD updates. | Execute 5‑axis simultaneous machining, monitor tool wear, and perform in‑process CMM checks. |
| 6. Quality Assurance | Review inspection reports (CMM, surface roughness, hardness). | Issue Certificate of Conformance (CoC), mill test reports, and final dimensional data. |
| 7. Logistics | Confirm shipping method (air, sea, express courier). | Arrange container loading, customs documentation, and real‑time tracking. |
| 8. After‑Sales Support | Report any issues, request re‑work or additional units. | Provide free re‑machining within warranty period, and technical assistance for assembly integration. |
Price Advantage & Cost‑Saving Strategies
- Transparent Unit Pricing – All costs (material, machining, tooling, inspection, and finishing) are itemized. No hidden fees.
- Volume Discounts – 5 % off for 500 pcs+, 10 % off for 2 k pcs+, and custom tiered pricing for larger runs.
- Tool‑Life Optimization – Our CAM experts select the longest‑lasting tool geometries, reducing tool‑change downtime and consumable expense.
- Design‑for‑Manufacturing Consultation – Early‑stage DFM can shave up to 30 % of machining time and material waste.
- Standard Fixture Library – Re‑using existing fixtures avoids the cost of a new custom jig for every order.
Example: A 50 mm × 30 mm × 10 mm aluminum bracket (CNC‑milled, Ra 0.4 µm) costs US $2.45 per piece for a 1 000‑unit order, versus an average market price of US $3.80 for comparable tolerance and finish.
Delivery Cycle & On‑Time Performance
| Order Size | Typical Lead Time (working days) | Express (48‑hr) Option |
|---|---|---|
| 1‑10 pcs (prototype) | 5‑7 days | 2 days (priority queue) |
| 10‑500 pcs | 10‑14 days | 5 days (fast‑track) |
| 500‑5 000 pcs | 15‑21 days | 7 days (dedicated line) |
| > 5 000 pcs | 21‑35 days (scheduled) | Not applicable (standard schedule) |
GreatLight maintains an on‑time delivery rate of 98.7 % over the past 24 months, thanks to:
- Real‑time production monitoring dashboard (client‑visible).
- Buffer stock of critical raw materials (≥ 30 % of average monthly consumption).
- Dual‑source supplier contracts for high‑risk alloys.
Communication Efficiency & Technical Support
- Dedicated Account Manager – Single point of contact for all inquiries, updates, and escalation.
- Multi‑Channel Access – WhatsApp (+86 180 2756 7310), email (rich@glcncmachining.com), WeChat, and phone.
- 24 h Response SLA – Initial reply within 1 hour; detailed technical feedback within 4 hours.
- Live Production Dashboard – Clients can view real‑time CNC status, tool changes, and estimated completion.
- Technical Library – Access to machining handbooks, material datasheets, and design guidelines via our client portal.
Technical Capabilities & Equipment
| Capability | Equipment | Key Specs |
|---|---|---|
| 5‑Axis CNC Milling | DMG‑Mori Seiki NHX 5000 | 500 mm × 500 mm × 300 mm work envelope, 24 000 rpm spindle, 200 kW motor, ±0.001 mm repeatability |
| High‑Speed 3‑Axis Milling | Haas VF‑2SS | 400 mm × 400 mm × 200 mm, 18 000 rpm, 10 kW |
| CNC Turning/Live‑Tool | Mazak Integrex i‑500 | 400 mm diameter, 800 mm length, 20 000 rpm, simultaneous milling & turning |
| Precision Grinding | Okuma G4000 | Surface grinding, 0.2 µm finish capability |
| CMM Inspection | Zeiss CONTURA G2A | 150 mm × 150 mm × 150 mm measurement volume, 0.2 µm accuracy |
| Laser Scanning | FaroArm® Platinum | 3‑D scan resolution 0.03 mm, up to 2 m range |
| Heat Treatment Furnace | Lindberg/Blue M | Up to 1100 °C, programmable soak cycles |
| Surface Finishing | Anodizing line (Al), Electroless Nickel (Cu/Brass), Passivation (SS) | Controlled bath chemistry, ISO‑9001 validated |
Our CAM software stack (Mastercam 2024, Siemens NX 12, SolidWorks CAM) integrates directly with the CNC controllers, guaranteeing optimal tool paths and reduced cycle time.
Quality Control System & Certifications
- ISO 9001:2015 – End‑to‑end quality management, documented procedures, continuous improvement.
- AS9100D (Aerospace) – Additional controls for traceability, risk management, and product safety.
- ISO 14001 (Environmental) – Sustainable manufacturing, waste reduction, and recycling programs.
- ISO 13485 (Medical Devices) – Cleanroom machining capability, validated sterilization processes.
QC Workflow
- Incoming Material Inspection – Verify certificates, perform chemical analysis (spectrometer).
- In‑Process Monitoring – Real‑time spindle load, temperature, and vibration analysis.
- First‑Article Inspection (FAI) – Full GD&T verification on the first part of each batch.
- Statistical Process Control (SPC) – Control charts for critical dimensions, automatically flagging drifts.
- Final Acceptance Test – CMM, surface roughness, hardness, and functional test (if required).
- Documentation Package – COA, MTR, inspection report, and traceability matrix delivered with shipment.
Confidentiality & Intellectual Property Protection
- Non‑Disclosure Agreement (NDA) – Signed before any data exchange.
- Encrypted File Transfer – SFTP with AES‑256 encryption for CAD files.
- Secure Data Storage – Isolated servers with daily backups, access limited to authorized engineers.
- IP Ownership Clause – All design rights remain exclusively with the client; GreatLight only holds a license to manufacture.
Supply Chain Stability & Risk Management
- Multiple Certified Suppliers – At least two approved vendors per material, each audited annually.
- Strategic Inventory – 3‑month safety stock of high‑volume alloys (Al 6061‑T6, 304 SS, C110 Cu).
- Real‑Time Market Monitoring – Automated alerts for price spikes or raw‑material shortages; proactive re‑sourcing.
- Logistics Redundancy – Partnerships with major freight forwarders (DHL, UPS, FedEx) and alternative sea routes to mitigate geopolitical disruptions.
- Business Continuity Plan – Backup CNC lines in a separate production hall; power‑backup UPS/Generator for 48 h.
Frequently Asked Questions (FAQs)
Q1. What is the minimum order quantity (MOQ)?
A: We accept single‑piece prototypes. For production runs, the MOQ is 10 pcs for most materials, but larger batches (≥ 100 pcs) unlock additional price breaks and faster lead times.
Q2. Can you work with exotic alloys like Ti‑6Al‑4V or Inconel 718?
A: Yes. Our 5‑axis machines are equipped with high‑torque spindles and proprietary tool holders to machine titanium and nickel‑based super‑alloys. A brief material‑specific feasibility study is performed before quoting.
Q3. How do you ensure surface integrity for high‑stress applications?
A: We employ a combination of low‑cut depth, high‑frequency spindle speeds, and cryogenic or minimum‑quantity lubrication (MQL) to avoid work‑hardening. Post‑machining stress‑relief heat treatment is offered upon request.
Q4. What inspection methods are used for critical dimensions?
A: Coordinate Measuring Machines (CMM), laser scanners, and non‑contact optical comparators. For sub‑micron tolerances, we also use white‑light interferometry.
Q5. Do you provide packaging for clean‑room delivery?
A: Absolutely. Parts Of A CNC Mill can be sealed in ISO‑class 5 clean‑room bags with static‑dissipative liners, and shipped in a certified clean‑room container.
Contact Us
GreatLight CNC Machining Center
Phone (WhatsApp): +86 180 2756 7310
Email: rich@glcncmachining.com
Website: glcncmachining.com
Our engineering team is ready to turn your ideas into high‑precision metal Parts Of A CNC Mill. Reach out today for a free feasibility study, and experience the speed, quality, and reliability that make GreatLight the leader in CNC machining and rapid prototyping.
