Centering machine – full name is centering CNC lathe. It can also be called moving spindle box CNC automatic lathe, economical turn-mill machine tool or slitting lathe. It is a precision processing equipment that can simultaneously carry out turning, milling, drilling, reaming, tapping, engraving and other complex processing. It is mainly used for batch processing of precision hardware and special-shaped non-standard parts such as shafts. .

This machine tool originates from Germany and Switzerland. At first, it was mainly used for precision processing of military equipment. With the continuous development and expansion of the industrialization process and the urgent market demand, it has been gradually used around the world. processing of civilian products; development of similar machine tools in Japan and South Korea. Before China, it was mainly used in the early military industry. With the development needs after the war, it was gradually widely used in the manufacturing industry. Later, Taiwan, China introduced this technology and independently developed this type of equipment for different processing needs.

The manufacturing of basic machines in China started late. Due to closed technology and policy restrictions, before the 1990s, China’s core machinery mainly relied on imports to meet processing needs. With the continuous development of automation and strong market demand, the Chinese market has become a large market. A number of powerful CNC machine tool manufacturers produce this series of machine tools in coastal Guangdong, Jiangsu, Nanjing, Shandong, Liaoning and inland Xi’an. They have obtained good applications in the market and filled the national gap.

CNC lathes have made a qualitative leap in processing efficiency and precision compared to CNC lathes. Through the use of a biaxial tool arrangement, the processing cycle time is significantly reduced by shortening the tool exchange time between the tool row and the opposing tool. table, multiple tools can be table overlap function, effective axis movement overlap function of threading chip and direct spindle indexing function during secondary processing can shorten idle time. The chip cutter tool is always processed at the clamping position between the spindle and the workpiece, ensuring consistent processing accuracy. At present, the maximum processing diameter of the centering machine on the market is 32mm, which has great advantages in the precision shaft processing market. This series of machine tools can be equipped with an automatic feeding device to realize fully automated production of a single machine tool, thereby reducing labor costs and product defect rates. It is very suitable for mass production of precision shaft parts.

Features and Benefits:

1) Shorten the product manufacturing process chain and improve production efficiency. The combined processing of turning and milling can complete all or most of the processing steps in a single facility, thereby greatly shortening the product manufacturing process chain. This not only reduces the production auxiliary time caused by changes in the installation of accessories, but also reduces the manufacturing cycle of tooling accessories and waiting time, which can greatly improve production efficiency. .

2) Reduce the number of clamping times and improve processing accuracy. Reducing the number of card installations avoids the accumulation of errors caused by positioning reference conversion. At the same time, most composite turning and milling processing equipment has online detection functions, which can realize on-site detection and precise control of key data in the manufacturing process, thereby improving accuracy processing of the product.

3) Reduce floor space and production costs. Although the single unit price of composite turning and milling equipment is relatively high, due to the shortening of the manufacturing process chain and the reduction of the equipment required for the product, as well as the reduction in the number of accessories, workshop floor space and equipment maintenance costs, it can effectively reduce the overall fixed asset investment, production operations and management costs.

Design features:

Since the structure of the centering machine is different from that of the traditional CNC lathe, the processing efficiency and precision of the centering machine are higher than that of the CNC lathe. The centering machine uses a biaxial arrangement of tools. This design significantly saves processing cycle time. By shortening the tool exchange time between the tool arrangement and the opposite tool station, it realizes the overlap of multiple tool stations and the effective overlap of the thread axis movement. chips, the direct spindle indexing function during secondary processing shortens the actual no-load travel time.

In the machining process of the clamping part of the spindle and the workpiece, the chip tool has always played a very important role, which provides a strong guarantee of consistent machining accuracy. Regarding the core machine market, 32mm is its maximum processing diameter, which gives the core machine a great advantage in the precision shaft processing market. This series of machine tools can also be equipped with an automatic feeding device to realize fully automated production of a single machine tool, thereby reducing labor costs and defective products during the production process. production, and can be used to produce large quantities of precision shaft parts.

Daguang focuses on providing solutions such as precision CNC machining services (3-axis, 4-axis, 5-axis machining), CNC milling, 3D printing and rapid prototyping services.

Image WeChat_20240301095125.png

CNC Knowledge: There are many thread codes such as NPT, PT, PF, G and ZG. Can you indicate them clearly?

BSPT and BSP – British Specification Taper Threads

NPT – US Specification Taper Thread

PT – Former JIS standard taper thread from Japan, equivalent to ISO R, Rc

DIN2999 – European pipe threads, mainly German

NPT

NPT is the American standard general purpose taper thread.

Among them, N means American (American) National Standard, P means PIPE pipe, T means TAPER cone, and the tooth profile angle is 60°.

This type of pipe thread is commonly used in North America or is often used in ANSI specifications. National standards can be found in GB/T12716-1991

I should note: NPT teeth must be used when running to ANSI specifications!

TP

PT thread is an imperial taper thread with a thread angle of 55°, most commonly used for sealing. It is mainly used in European and Commonwealth countries. In fact, the Japanese JIS standard in Taiwan also follows the imperial standard, and China also uses the imperial thread. Belongs to the Whitworth sons family. The national standard can be found in GB/T7306-2000.

British pipe threads are fine threads. Since the thread depth of coarse threads is large, it will greatly reduce the strength of the cut outer diameter pipe.

Additionally, NIPPLE is often used in small diameter pipes. The purpose is that the wall thickness of the purchased NIPPLE is relatively thick, which can guarantee the strength of the tapping part. At the same time, the main pipeline does not require thickness. pipe walls. This is to reduce costs.

The PF thread is a parallel pipe thread.

We have to be careful: PT teeth, etc. must be used when developing JIS specifications!

Photo WeChat_20240301095128.jpg

G

G is a 55 degree unthreaded sealing pipe thread, which belongs to the Whitworth thread family. Marked G represents a cylindrical thread. National standard can be found in GB/T7307-2001

G is the general name for pipe threads (Guan). The 55 and 60 degree divisions are functional and commonly referred to as pipe circles. That is, the thread is machined from a cylindrical surface.

ZG

ZG is commonly called pipe cone, that is, the thread is processed from a conical surface. General water pipe joints are like this. The old national standard is marked Rc.

Metric threads are expressed by pitch, and American and British threads are expressed by the number of threads per inch. This is their biggest difference. Metric threads have a 60 degree equilateral profile, British threads have a 55 degree isosceles profile and American threads have a 55 degree isosceles profile. 60 degrees.

Metric threads use metric units, while American and British threads use imperial units.

Pipe threads are mainly used to connect pipes. Internal and external threads are closely matched and there are two types: straight pipes and tapered pipes. Nominal diameter refers to the diameter of the connected pipe. Obviously, the main diameter of the thread is greater than the nominal diameter. 1/4, 1/2 and 1/8 are the nominal thread diameters in inches.


Identifying uniform inch threads

Inch thread size is usually expressed by the number of threads per inch of length on the thread, called “number of threads per inch”, which is exactly the inverse of the thread pitch. For example, a thread with 8 threads per inch has a pitch of 1/8 inch.

Unified inch system threads are widely used in inch system countries. This type of thread is divided into three series: UNC coarse thread series, UNF fine thread series, UNFF extra fine thread series and UN fixed pitch series.

Marking method: thread diameter – number of threads per inch, serial code – precision level

Example: Coarse tooth set 3/8-16 UNC-2A

Fine Tooth Series 3/8—24 UNF—2A

Extra Fine Tooth Series 3/8—32 UNFF—2A

Fixed Pitch Series 3/8—20 UN—2A

The first number 3/8 represents the outside diameter of the thread in inches. To convert to metric mm, multiply by 25.4, or 3/8×25.4=9.525 mm; , and 20 is the number of teeth per inch (the number of teeth in a length of 25.4 mm); the text codes after the third digit, UNC, UNF, UNFF, UN, are the serial codes and the last two digits, 2A, are the precision level.

Examples of representation of bolts in inches:

LH 2N 5/8 x 3 – 13 UNC-2A

(1) LH is a left-hand thread (RH is a right-hand thread and can be omitted).

(2) 2N double thread.

(3) 5/8″ thread, 5/8″ outside diameter.

(4)3 bolts length 3”.

(5) 13 threads have 13 threads per inch.

(6) Coarse thread to UNC unified standard thread.

(7) Level 2 fit, external thread (3: tight fit; 2: medium fit; 1: loose fit) A: External thread (can be omitted) B: Internal thread.

Converting a 55° cylindrical pipe thread

The 55° barrel thread belongs to the inch series, but is widely used in metric and inch countries. It is used to connect pipe joints and pipes for the transportation of liquids, gases and for cable installation. However, the codes of different countries are different. , so you need to press Foreign codes in the table (comparison table) are converted to Chinese codes. The 55° cylindrical pipe thread codes from different countries are now listed in the table below.

Country code

China G

Japan G, PF

British BSP, BSPP

FranceG

Germany R (internal thread), K (external thread)

Former Soviet Union G, TPУБ

ISO Price

Converting a 55° Tapered Pipe Thread

A 55° tapered pipe thread means that the thread profile angle is 55° and the thread has a taper of 1:16. This series of yarns is widely used around the world. Its code names vary from country to country, as shown in the table below. Convert the foreign code names in the table to Chinese code names.

Country code

China ZG, R (external thread)

British BSPT, R (external thread), Rc (internal thread)

France G (external thread), R (external thread)

Germany R (external thread)

Japan PT, R

ISO R (external thread), Rc (internal thread)

Converting a 60° Tapered Pipe Thread

60° Taper Pipe Thread refers to a pipe thread with a profile angle of 60° and a thread taper of 1:16. This series of threads is used in the machine tool industry of my country, the United States and the former Soviet Union. Its code name used to be K in our country, then Z, and now it is changed to NPT. See the wire code comparison chart below.

Country code

China Z (old) NPT (new)

United States NPT

Soviet B

Transformation of 55° trapezoidal thread

Trapezoidal thread refers to a metric trapezoidal thread with a profile angle of 30°. This series of threads is relatively uniform at home and abroad, and their codes are also quite consistent. Wire codes are shown in the table below.

Country code

China T (old) Tr (new)

ISO TR

Germany TR

Former Soviet Union TR

Thread type


According to the different uses of threads, they can be divided into:

1. International Metric Thread System:

The thread adopted by my country’s CNS national standard. The top of the tooth is flat and easy to turn, while the bottom of the tooth is arc-shaped to increase thread strength. The thread angle is 60 degrees, and the specification is expressed in M. Metric threads can be divided into two types: coarse thread and fine thread. The representation is as follows: M8x1.25. (M: code, 8: nominal diameter, 1.25: pitch).

2. American standard thread:

Both the top and root of the wire are flat and have better strength. The thread angle is also 60 degrees and the specification is expressed as threads per inch. This type of wire can be divided into three levels: coarse wire (NC); extra fine wire (NEF); The representation is such as 1/2-10NC. (1/2: outer diameter; 10: number of teeth per inch; NC code).

3. Unified thread:

Formulated jointly by the United States, the United Kingdom and Canada, it is the commonly used British common thread.

The thread angle is also 60 degrees and the specification is expressed as threads per inch. This type of wire can be divided into coarse wire (UNC), fine wire (UNF) and extra fine wire (UNEF). The representation is such as 1/2-10UNC. (1/2: outer diameter; 10: number of teeth per inch; UNC code)

4. V-shaped thread (Sharp V Thread):

Both the top and roots are sharp, not very durable and little used. The thread angle is 60 degrees.

5. Whitworth Subject:

Thread adopted by British National Standard. The thread angle is 55 degrees, represented by the symbol “W”.

Suitable for manufacturing by rolling. The representation is like W1/2-10. (1/2: outer diameter; 10: number of teeth per inch; W code).

6. Joint wire:

This is the standard thread specified by the German DIN standard. Suitable for connecting bulbs and rubber tubes. The symbol is “Rd”.

7. Pipe thread:

Threads used to prevent leaks are often used to connect gas or liquid pipe fittings. The thread angle is 55 degrees, which can be divided into straight pipe thread named “PS, NPS” and inclined pipe thread named “NPT”. Its taper is 1:16, or 3/4 inch per foot.

8. Square wire:

The transmission efficiency is high, second only to the ball thread, but its disadvantage is that it cannot be adjusted with a nut after wear. Generally used for vise screw and crane thread.

9. Trapezoidal thread:

Also known as Acme thread. The transmission efficiency is slightly lower than that of square thread, but it can be adjusted with a nut after wear. The metric system thread angle is 30 degrees and the imperial system thread angle is 29 degrees. Generally used for the lead screw of lathes. The symbol is “Tr”.

10. Zigzag thread (buttress thread):

Also known as rhombic wire, it is only suitable for one-way transmission. Such as screw jacks, pressurizers, etc. The symbol is “Bu”.

11. Ball wire:

It is the wire with the best transmission efficiency. It is difficult to manufacture and extremely expensive. It is used in precision machines. Like the lead screw of CNC machine tools.

Daguang focuses on providing solutions such as precision CNC machining services (3-axis, 4-axis, 5-axis machining), CNC milling, 3D printing and rapid prototyping services.

CNC Knowledge: The optimal speed for turning external threads on a lathe

When CNC lathes process threads, due to changes in the transmission chain, in principle, the speed should only be able to ensure that the tool moves one step along the main feed axis (mainly l Z axis) each time the spindle rotates, and should not be restricted. However, when CNC lathes process threads, they will be affected by the following aspects:

1) The pitch (feed) value commanded in the thread processing block is equivalent to the feed speed F expressed as feed quantity (mm/r). If the machine tool spindle speed is selected too high, the converted feedrate is speed (). mm/min) must greatly exceed the normal value;

2) At the start/end of its movement, the tool will be constrained by the high/low frequency of the servo motor system and the interpolation speed of the CNC device because the high/low frequency characteristics cannot meet the processing needs , etc. ., the main feed can “advance” and “lag” produced by the movement cause the pitch of some threads to not meet the requirements;

3) Thread turning should be achieved through the spindle synchronous operation function, that is, thread turning requires a spindle pulse generator (encoder).

When the spindle speed is selected too high, the positioning pulse sent by the encoder (i.e. a reference pulse signal sent every time the spindle rotates once) may be caused by “overshoot” (especially when the quality of the encoder is unstable). . Causes the threads of the part to distort randomly.

Therefore, when turning threads, determining the spindle speed should follow the following principles:

1) Subject to ensuring production efficiency and normal cutting, it is advisable to choose a lower spindle speed;

2) When the input length δ1 and cutting length δ2 (as shown in the figure) in the thread processing program section are considered sufficient, that is, when the feed distance of the thread exceeds the thread length specified in the drawing, a suitably greater spindle speed may be selected;

3) When the allowable operating speed specified by the encoder exceeds the maximum spindle speed specified by the machine tool, you can choose as high a spindle speed as possible;

4) Normally, the spindle speed (n thread) when turning threads should be determined according to the calculation formula specified in the manual of the machine tool or CNC system. The calculation formula is mainly:

n vis≤nallow/L(r/min) where nallow—the maximum working speed allowed by the encoder (r/min);

L—The pitch (or pitch, mm) of the thread of the part.
