Small-hole EDM runs on the same physics as any other sinker. A shaped electrode and the workpiece sit in a dielectric, usually deionized water or hydrocarbon oil, separated by a gap of a few hundredths of a millimeter. The generator charges that gap until the dielectric breaks down and a discharge channel forms. Temperature inside the channel reaches several thousand degrees, melting and partly vaporizing a tiny volume of metal on both sides.

Then the pulse stops. The channel collapses, the molten debris is flushed out with the dielectric, and the gap recovers its insulation. One cycle lasts microseconds and removes a crater a few micrometers deep. A spindle or servo axis feeds the electrode down by that same amount so the next spark fires at the same gap. Thousands of cycles per second add up to a hole.

What matters for small holes is that the electrode never touches the work. There is no chipping, no drill wander from a flexible bit, and almost no mechanical load on the part. Cutting force is close to zero. That is why a 0.6 mm hole can go through 50 HRC tool steel, or through a thin-wall tube that would deform the moment a twist drill pushed into it.

• 1
  Heat-affected layerA recast layer of a few micrometers forms on the wall; a low-energy finishing pass reduces it.
• 2
  Dielectric jobIt insulates the gap, cools the zone and carries debris away. It is not just a coolant.
• 3
  Gap is fixedThe electrode is always smaller than the hole by roughly twice the spark gap plus oversize.

For a 0.5 mm hole, the electrode is often 0.35–0.42 mm across. The difference is the frontal gap plus the side gap, and it changes with discharge energy. Run a roughing setting and the gap widens; switch to a finishing setting and the hole closes in. Machine operators compensate by shifting the offset, not by ordering a new electrode, which is why the same tool can hold a range of diameters.

Tungsten carbide and tungsten wire are the usual choices below 1 mm because they resist wear and stay straight. Brass and copper tungsten work well at 1–3 mm, where the electrode is stiffer and wear is easier to absorb. Wear shows up as a taper: the electrode tip erodes faster than the shank, so the entry of the hole ends up wider than the exit.

Electrode length is a practical ceiling. A 0.3 mm carbide rod 30 mm long will bow and wander under flush pressure, so deep small holes are usually drilled from both sides or run on a machine with a guided electrode. If a drawing calls for a 0.4 mm hole 20 mm deep in one pass, ask about the aspect ratio before promising the feature.

• 1
  Wear ratioTrack electrode consumption per hole; a drifting ratio means diameter drift on the next part.
• 2
  DressingRe-dress or replace the electrode on a fixed count, not when the hole looks wrong.
• 3
  Rotating electrodeSpinning the tool helps roundness and flushing in holes under 1 mm.

Debris that stays in the gap causes secondary discharges. Those sparks erode the wall, short the gap, and leave a hole that is bell-mouthed or out of round. Flushing is therefore the constraint that decides how deep a small hole can go, more than the generator or the electrode material.

Through-flushing from the electrode is the cleanest method when the electrode can be made hollow, which is common from about 0.8 mm upward. Below that, hollow electrodes are fragile, so shops use side flushing, a suction pull on the far side, or a jump cycle where the electrode lifts a few tenths of a millimeter to let fresh dielectric in. Each jump costs cycle time.

A rough rule from the shop floor: an aspect ratio of 5:1 is comfortable, 10:1 needs good flushing and a rotating electrode, and beyond 15:1 the process becomes slow and the taper harder to control. A 0.5 mm hole 8 mm deep is a normal job. The same diameter at 15 mm deep is a conversation about cost and risk, not a yes or no.

• 1
  Through-flushBest debris removal; needs a hollow electrode, usually Ø0.8 mm and up.
• 2
  Jump cycleElectrode retracts to refresh the gap; adds time but saves the wall.
• 3
  SuctionPull dielectric from the exit side when the electrode cannot be hollow.

EDM is slow compared with drilling. A 0.5 mm hole 3 mm deep in hardened steel can take a minute or two on a small-hole machine, while a carbide drill might do it in seconds. If the part is soft, the hole is larger than 1 mm, and the depth is modest, drilling or milling wins on cost almost every time.

Material matters too. EDM needs the work to conduct. Plastics, most ceramics and glass are out unless a conductive coating or a starter layer is added. Aluminum conducts but melts easily and produces sticky debris, so parameters have to be softened and flushing improved. Copper and brass cut fast but wear electrodes quickly.

Holes also stop being round once you go very small. Below about 0.3 mm, the achievable entry roundness and wall finish get harder to hold, and inspection itself becomes the bottleneck because you need a vision system or a high-magnification optical comparator to measure what you made. If a drawing specifies Ø0.2 mm with a tight roundness callout, expect a feasibility discussion before a price.

• 1
  Conductive onlyNon-conductive parts need a coating or a different process.
• 2
  Slow by natureSmall-hole EDM removes material by spark, not by a cutting edge.
• 3
  Start holeOften machined by EDM after a pilot or center drill, not instead of one.

A dedicated small-hole EDM has a fine-feed spindle, a rotating collet, and a pulse generator that can hold low energy without stalling. That last part is the hard one. At very low discharge energy the gap is narrow and the servo has to respond in microseconds, so a general-purpose sinker may not hold a stable cut at 0.3 mm even with a good electrode. The generator and the servo loop are matched to the job.

Positioning matters as much as the spark. A hole that must sit within ±0.005 mm of a datum needs a machine with a stable thermal environment and a probe or edge finder that repeats. Once the part is clamped, the electrode has to find the surface, not guess it. Some shops measure the electrode itself before the cut, because wear changes the effective diameter.

Automation is where repeat work gets cheap. A tool changer that swaps electrodes by diameter, plus a program that steps through rough and finish settings, lets one operator run a batch of parts overnight. On a single prototype hole, that setup is pure overhead and the price reflects it.

• 1
  Pulse controlLow-energy, high-frequency output is what makes sub-millimeter holes stable.
• 2
  Spindle runoutA few micrometers of runout shows up directly as hole eccentricity.
• 3
  Thermal stabilityLong unattended runs drift if the shop temperature moves.
