Product Overview – Aerospace Parts CNC Machining Manufacturing for Drones
GreatLight is a professional & experienced precision CNC machining factory in China, providing precision 5‑axis CNC machining & lathe services with tolerance of 0.001 mm. As a leader in CNC machining and one of the best rapid‑prototyping companies from China, GreatLight CNC Machining Center is an ISO 9001:2015 certified manufacturer and an excellent choice for custom metal and plastic parts. Our Aerospace Parts CNC Machining Manufacturing for unmanned aerial vehicles (UAVs) combine ultra‑high strength, lightweight design, and ultra‑precise dimensional control, delivering the performance that modern drone manufacturers demand.
Why Choose GreatLight’s Aerospace Parts CNC Machining Manufacturing for Drones?
| Key Advantage | What It Means for Your Drone Program |
|---|---|
| Tolerance ±0.001 mm | Guarantees flawless assembly, reduced vibration, and longer service life. |
| 5‑Axis Machining | Enables complex geometries (e.g., aerodynamic fairings, hollow spars) in a single setup, eliminating costly post‑processing. |
| Material Portfolio | From Aerospace Parts CNC Machining Manufacturing aluminum alloys (7075‑T6, 2024‑T3) to titanium (Ti‑6Al‑4V) and high‑performance polymers (PEEK, Ultem). |
| Rapid Turn‑around | Prototype in 3‑5 days, production batch in 7‑14 days, thanks to in‑house CNC fleet and streamlined workflow. |
| Full Traceability | Every part carries material certificates, machining logs, and inspection reports. |
| IP Protection | NDAs, data encryption, and secure production zones protect your designs. |
| Supply‑Chain Resilience | Dual‑source raw‑material contracts, safety‑stock inventory, and logistics partners in Europe, North America, and Asia. |
Main Features of Our Drone CNC Parts
- Ultra‑Lightweight Architecture – Optimized wall‑thickness and internal ribbing reduce weight without compromising stiffness.
- High‑Strength Alloys – Use of 7075‑T6 aluminum (yield strength ≈ 503 MPa) and Ti‑6Al‑4V (yield strength ≈ 880 MPa) for load‑bearing components.
- Complex 3‑D Surfaces – 5‑axis contouring creates aero‑dynamic surfaces that lower drag and improve flight efficiency.
- Integrated Functional Features – Machined mounting holes, threaded inserts, cable‑routing channels, and heat‑sink fins are incorporated directly in the part.
- Surface Finish Options – From Ra 0.4 µm (mirror polish) to Ra 3.2 µm (functional finish) and optional anodizing, passivation, or PVD coating.
- Quality‑First Inspection – CMM (Coordinate Measuring Machine) verification, laser scanning, and non‑destructive testing (NDT) for critical Aerospace Parts CNC Machining Manufacturing.
Suitable Applications
- Quadcopters & Hexacopters – Motor mounts, arm brackets, battery enclosures, and landing‑gear components.
- Fixed‑Wing UAVs – Wing spars, fuselage skins, control‑surface hinges, and payload bays.
- Hybrid VTOL Platforms – Transition mechanisms, high‑stress joints, and custom‑shaped ducts.
- High‑Altitude Long‑Endurance (HALE) Drones – Lightweight structural skins and precision‑machined antenna mounts.
- Commercial & Military Payload Pods – Sensor housings, camera gimbals, and stealth‑shaped fairings.
Quality & Accuracy – The GreatLight Promise
GreatLight’s CNC machining process is built on a four‑layer quality architecture:
- Design Validation – CAD models undergo finite‑element analysis (FEA) and manufacturability checks before any toolpath is generated.
- Toolpath Optimization – Proprietary CAM software creates high‑efficiency, low‑vibration toolpaths, automatically compensating for tool wear and material deflection.
- In‑Process Monitoring – Real‑time spindle load, temperature, and vibration sensors feed into a closed‑loop control system, guaranteeing the ±0.001 mm tolerance throughout the batch.
- Final Inspection – Every part is measured on a Zeiss CMM with a repeatability of ±0.0005 mm. Critical dimensions are cross‑checked with laser‑scan data and a statistical process control (SPC) chart is generated for each lot.
All inspection data, including measurement reports and certification PDFs, are uploaded to a secure customer portal within 24 hours of completion.
Parameter Table – Typical Drone Component Specs
| Parameter | Typical Range | Units | Notes |
|---|---|---|---|
| Length (overall) | 30 – 250 | mm | Customizable per design |
| Width (overall) | 20 – 180 | mm | |
| Height (overall) | 5 – 80 | mm | |
| Wall Thickness | 0.8 – 4.0 | mm | Minimum 0.8 mm for 7075‑T6 |
| Weight (per part) | 5 – 120 | g | Dependent on material & geometry |
| Surface Roughness (Ra) | 0.4 – 3.2 | µm | Finish selectable |
| Tolerance (dimensional) | ±0.001 | mm | 5‑axis capability |
| Hole Position Tolerance | ±0.005 | mm | For threaded inserts |
| Thread Pitch Accuracy | ±0.02 | mm | M2‑M12 standard threads |
| Material Hardness (HV) | 150 – 350 | HV | Varies by alloy |
| Operating Temperature | –55 °C – +150 °C | °C | Material specific |
All values are indicative; exact numbers are defined during the quoting stage based on your CAD files.
Material Properties Table
| Material | Typical Application | Yield Strength | Ultimate Tensile Strength | Density | Hardness (HV) | Key Benefits |
|---|---|---|---|---|---|---|
| Aluminum 7075‑T6 | Main structural brackets, motor mounts | 503 MPa | 572 MPa | 2.81 g/cm³ | 150 HV | Highest strength‑to‑weight among aluminum alloys, excellent fatigue resistance. |
| Aluminum 2024‑T3 | Wing skins, payload frames | 324 MPa | 470 MPa | 2.78 g/cm³ | 140 HV | Good weldability, high fracture toughness. |
| Titanium Ti‑6Al‑4V | High‑stress joints, landing‑gear inserts | 880 MPa | 950 MPa | 4.43 g/cm³ | 340 HV | Superior strength, corrosion resistance, high temperature capability. |
| Carbon‑Fiber Reinforced PEEK | Sensor housings, high‑temp enclosures | 110 MPa* | 140 MPa* | 1.30 g/cm³ | 170 HV | Lightweight, high heat resistance, chemical inertness. |
| Ultem (PEI) | Electrical isolation components | 150 MPa* | 170 MPa* | 1.27 g/cm³ | 180 HV | Flame‑retardant, high dielectric strength. |
| Stainless Steel 316L | Corrosion‑exposed fittings, marine drones | 290 MPa | 580 MPa | 7.99 g/cm³ | 200 HV | Excellent corrosion resistance, biocompatibility. |
*Values for polymer composites are typical for unfilled material; reinforced grades can exceed these numbers.
Machining Instructions – From Design to Finished Part
- File Submission – Provide 3‑D CAD files in STEP, IGES, or SolidWorks format. Include a drawing sheet with GD&T, material selection, and surface‑finish requirements.
- Design Review – Our engineering team performs a Design for Manufacturability (DFM) analysis, flags under‑cuts, thin walls, or unsupported features, and suggests reinforcement ribs if needed.
- CAM Programming – Using Mastercam® and HyperMILL®, a 5‑axis toolpath is generated. Tool selection (e.g., carbide ball‑nose 0.8 mm for fine details, solid carbide end‑mill 3 mm for roughing) is optimized for material and part geometry.
- Fixture Design – Custom fixturing is designed in‑house to secure the part while allowing full 5‑axis access. Fixtures are fabricated from hardened steel or aluminum, depending on batch size.
- Machining – Aerospace Parts are machined on Haas VF‑5/2‑axis, DMG MORI DMU‑50 5‑axis, or Mazak Integrex series machines. Coolant flow, spindle speed, and feed rates are logged automatically.
- Deburring & Cleaning – Automated vibratory deburring followed by ultrasonic cleaning removes burrs and cutting fluids.
- Heat Treatment (if required) – For aluminum, a T6 tempering process (solution heat‑treat at 480 °C, quench, age at 120 °C) is available. For titanium, a standard anneal at 650 °C is offered.
- Surface Finishing – Options include anodizing (clear, bronze, black), passivation for stainless steel, or PVD coating for wear resistance.
- Inspection – CMM measurement, laser scanning (for complex surfaces), and NDT (ultrasonic or dye‑penetrant) for critical safety Aerospace Parts.
- Packaging & Shipping – Aerospace Parts are packed in anti‑static, moisture‑controlled bags with foam inserts and labeled with lot numbers, material certificates, and inspection reports.
Custom Guide – Tailoring Aerospace Parts to Your Drone Program
- Geometric Customization – Request hollow interiors, internal channels for wiring, or weight‑reduction lattices. Our generative design team can propose lattice structures that meet strength targets while cutting weight up to 30 %.
- Material Substitution – Switch from aluminum to titanium for high‑stress zones without redesigning the entire part. Material substitution fees are transparent and calculated per kilogram of material change.
- Finish & Coating Options – Choose from matte black anodizing for stealth drones, conductive silver plating for EMI shielding, or ceramic coating for high‑temperature exhaust ducts.
- Functional Add‑Ons – Integrated threaded inserts (M2‑M12), captive nuts, or quick‑release pins can be machined directly into the part.
- Batch Size Flexibility – Prototyping runs as low as 1 piece, pilot production 10‑100 pieces, full‑scale production 500 + pieces. Pricing scales linearly with set‑up cost amortization.
Steps to Initiate a Custom Order
- Contact GreatLight CNC Machining Center via phone (+86 180 2756 7310 WhatsApp), email (rich@glcncmachining.com), or website (glcncmachining.com).
- Upload your CAD model and specify material, finish, and quantity.
- Receive a detailed quotation within 24 hours, including unit price, lead time, and tooling cost.
- Approve the quotation and sign the NDA.
- Kick‑off the project – engineering, tooling, and machining proceed under a dedicated project manager.
- Track progress live on our customer portal.
- Receive final Aerospace Parts CNC Machining Manufacturing, inspection reports, and certificates of conformity.
Price Advantage – Competitive Cost Structure
| Cost Component | GreatLight Strategy | Result for You |
|---|---|---|
| Tooling | In‑house tool grinding and backup libraries reduce external tool‑purchase fees. | Lower set‑up cost, especially for small batches. |
| Material Procurement | Dual‑sourced contracts with primary aluminum and titanium suppliers; bulk‑purchase discounts. | Material cost up to 15 % lower than market average. |
| Machine Utilization | 24/7 production lines with automated load‑and‑unload robots. | Faster cycle times, no overtime surcharge. |
| Labor | Skilled CNC operators with performance‑based incentives. | High productivity, consistent quality, no hidden labor fees. |
| Shipping | Partnerships with DHL, UPS, and regional freight forwarders; consolidated shipments. | Reduced logistics cost and door‑to‑door delivery options. |
| After‑Sales Support | Free first‑year warranty for dimensional drift, complimentary re‑machining if tolerance exceeds spec. | Peace of mind and reduced total cost of ownership. |
Overall, customers typically see 10‑20 % savings compared with European or North‑American machining houses, while receiving ISO 9001:2015 certified quality.
Delivery Cycle & On‑Time Performance
- Prototype (1‑10 pcs) – 3‑5 working days from design lock‑in to shipment.
- Pilot Production (10‑100 pcs) – 7‑10 working days, including optional heat treatment and coating.
- Full Production (≥500 pcs) – 14‑21 working days, with staggered shipments if required.
GreatLight maintains a 96 % on‑time delivery rate over the past three years, backed by:
- Real‑time Production Dashboard – Customers view live status (machining, inspection, packaging).
- Buffer Inventory – Critical raw material safety stock (minimum 30 days) prevents supply interruptions.
- Flexible Shift Scheduling – Ability to add an extra shift during peak demand without compromising quality.
Communication Efficiency & Technical Support
- Dedicated Project Manager (PM) – One point of contact from quotation to delivery.
- 24 h Email & WhatsApp Support – Response time ≤ 2 hours for technical queries.
- Virtual Review Sessions – Screen‑share CAD review, CAM simulation, and inspection data presentation using Zoom or Teams.
- Technical Documentation – Full CNC program (G‑code), tool list, fixturing drawings, and post‑process reports are shared in PDF/STEP format.
- After‑Sales Service – On‑site troubleshooting (if required) within 48 hours for customers in the Asia‑Pacific region; remote assistance worldwide.
Technical Capabilities & Equipment
| Capability | Equipment | Capacity / Precision |
|---|---|---|
| 5‑Axis Machining | DMG MORI DMU‑50, Mazak Integrex i‑200ST | 0.001 mm positional accuracy, 0.3 mm repeatability |
| High‑Speed 3‑Axis | Haas VF‑2/5, FANUC 0i‑MT | Up to 25 m/min spindle speed, 0.005 mm tolerance |
| Turning / Multi‑Task | DMG MORI CTX‑β 600V | 0.001 mm tolerance, live‑tool capability |
| Heat Treatment Furnace | Vacuum furnace (up to 800 °C) | Controlled cooling rates, uniform hardness |
| Surface Treatment | Anodizing line, PVD coating chamber, Passivation tank | Uniform coating thickness ±5 % |
| Inspection | Zeiss CMM, Hexagon Leica laser scanner, X‑ray NDT | Measurement uncertainty ±0.0005 mm |
| Additive Support | EOS M 290 (metal powder) for hybrid builds (optional) | Enables conformal lattice inserts for weight reduction |
Our engineers are proficient in SolidWorks, CATIA, NX, and ANSYS for simulation, ensuring that each part is not only machined accurately but also validated for structural performance under flight loads.
Quality Control System & Certifications
- ISO 9001:2015 – Comprehensive quality management system covering design, production, and post‑sale.
- AS9100D (Aerospace) – Alignment with Aerospace Parts CNC Machining Manufacturing industry standards for traceability and risk management (currently under audit, expected certification Q3 2025).
- ISO 14001 – Environmental management to reduce waste and energy consumption.
- GD&T Compliance – All drawings follow ASME Y14.5‑2022; inspection data recorded accordingly.
- Statistical Process Control (SPC) – Real‑time monitoring of critical dimensions; control charts reviewed each shift.
- First‑Article Inspection (FAI) – Mandatory for every new part number; results stored in the QMS database.
Inspection Workflow
- Incoming Material Check – Mill‑test certificates verified; samples undergo chemical analysis (ICP‑OES).
- In‑Process Checks – Tool wear sensors trigger automatic tool change; dimensions measured after roughing and finishing passes.
- Final CMM Scan – Full 3‑D measurement; deviations flagged > 0.5 µm generate a corrective action.
- Report Generation – PDF report includes measurement tables, GD&T compliance, and a signed QC manager approval.
All data is archived for 10 years and can be accessed by the customer via a secure portal.
Confidentiality & Intellectual Property Protection
- Non‑Disclosure Agreement (NDA) – Signed before any file exchange; legal jurisdiction: Shenzhen, China.
- Data Encryption – Files transferred through SSL‑encrypted channels; stored on air‑gapped servers with limited access.
- Secure Production Zones – CNC machines for IP‑sensitive Aerospace Parts are isolated; only authorized personnel with badge access can enter.
- Document Control – All design files are watermarked with a unique customer identifier; printed drawings are destroyed after use.
- IP Ownership – All designs remain the sole property of the client; GreatLight retains no rights to replicate or sell the part.
Supply‑Chain Stability & Risk Management
| Risk Area | Mitigation Strategy |
|---|---|
| Raw‑Material Price Volatility | Long‑term contracts with tier‑1 suppliers; price‑capping clauses for key alloys (Al 7075, Ti‑6Al‑4V). |
| Logistics Disruptions | Multi‑modal shipping options (air, sea, rail); regional distribution centers in Europe (Rotterdam) and North America (Los Angeles). |
| Equipment Downtime | Redundant CNC lines for each major operation; preventive maintenance schedule (monthly overhaul). |
| Regulatory Changes | Dedicated compliance team monitors export controls (EAR, ITAR) and updates SOPs accordingly. |
| Pandemic/Force‑Majeure | On‑site staff health protocols, remote monitoring capability, and a 30‑day safety stock for critical raw materials. |
Our Supply‑Chain Dashboard provides real‑time visibility of inventory levels, supplier lead times, and logistics status, allowing proactive adjustments before a disruption reaches the production floor.
Summarizing the Value Proposition
GreatLight’s Aerospace Parts CNC Machining Manufacturing for drones are engineered, manufactured, and delivered with a level of precision and reliability that meets the stringent demands of modern UAV platforms. By leveraging:
- State‑of‑the‑art 5‑axis machining (±0.001 mm tolerance)
- A broad material library (high‑strength aluminum, titanium, advanced polymers)
- Rapid prototyping and scalable production (days to weeks)
- Robust quality assurance (CMM, SPC, ISO/AS9100 certification)
- Full IP protection and transparent communication
customers gain a competitive edge—lighter, stronger, and more aerodynamically optimized drone components—while enjoying cost savings, on‑time delivery, and a single‑point contact throughout the entire product lifecycle.
How to Get Started
- Reach Out – Call +86 180 2756 7310 (WhatsApp) or email rich@glcncmachining.com.
- Share Your Design – Upload the CAD model, specify material, finish, and quantity.
- Receive Quote & NDA – Detailed cost breakdown and confidentiality agreement within 24 hours.
- Kick‑off Project – Our engineering team refines the design, runs simulations, and prepares the CNC program.
- Track & Review – Access live production data, inspection reports, and certificate downloads via the portal.
- Receive Finished Aerospace Parts – Packaged with full documentation, ready for integration into your drone assembly line.
GreatLight is ready to turn your innovative drone concepts into high‑performance reality. Let us be the trusted partner that delivers precision, speed, and peace of mind—every time.
Contact Information
GreatLight CNC Machining Center
Phone (WhatsApp): +86 180 2756 7310
Email: rich@glcncmachining.com
Website: glcncmachining.com
We look forward to machining the future of Aerospace Parts CNC Machining Manufacturing together.
