A robot battery enclosure sheet metal prototype looks simple on a print: a few bends, a lid, some mounting holes. On the robot it behaves differently. The pack sits in the torso, base, or a swing arm, so acceleration, braking, and impact loads pass through the enclosure walls into the frame. That means the sheet is not just a cover. It is a load path.

The shape follows from that. Typical parts combine a formed tray, a lid or top plate, flanges for bolting, captive inserts, a gasket channel, and openings for connectors, vents, or cable pass-throughs. Some designs add louvers, heatsink pads, or machined busbar plates. Each feature adds a tolerance stack, and the stack decides whether the pack seals and whether the robot assembles without shimming.

Rigidity matters more than strength in most prototypes. A 1.5 mm wall in 5052 at 20 °C flexes under hand pressure; the same wall with two formed ribs and a bolted lid becomes stiff enough for vibration testing. Designers usually learn this in the first prototype, which is exactly what a prototype is for.

EMI is the second job. Robots carry motor drives, radios, and sensors close to the pack. An aluminum enclosure with continuous seams and a bonded or gasketed lid gives measurable attenuation. A painted steel box with gaps at every flange does not.

• 1
  Load pathTreat the enclosure as a frame member and check bolt patterns, not just wall thickness.
• 2
  Sealing facesGasket channels need flatness, not just a groove; plan the machining step early.
• 3
  Service accessCell replacement and fuse access drive the lid split more than looks do.

Most teams compare three routes: sheet metal, CNC-machined billet, and 3D printing. Machining a full enclosure from a solid block gives excellent tolerance and wall thickness control, but it removes most of the material, costs more per part, and cannot reproduce the formed ribs and stiffness of the production design. It is the right call for a small, dense, high-value housing, not for a 300 mm pack tray.

3D printing is fast and cheap for form checks, connector placement, and fit trials. It is not representative for drop, vibration, or thermal work unless you print in a filled engineering polymer, and even then the modulus and creep behavior differ from sheet. Use it for the first fit, then move on.

Sheet metal hits a middle point that matches most robot programs. You get production-like material properties, real weld behavior, real EMI attenuation, and a design that can carry into a production tool. The trade-off is that forming has its own rules: bend radii, springback, and weld distortion. Those rules are predictable, and the rest of this page covers them.

The practical decision rule: use sheet metal when the enclosure is a structural or semi-structural panel with a pack inside; use machining when the housing is small, sealed to IP67 or better, and dominated by precision bores.

5052 aluminum is the default for robot pack enclosures. It bends to tight radii without cracking, welds cleanly, resists salt spray reasonably well, and costs less than 6061. Formability and weldability beat strength here because the enclosure is stiffened by geometry, not by alloy. If you are building the first functional tray, start with 5052 in 1.5 mm or 2.0 mm.

6061-T6 is stiffer and machines better, which matters when the enclosure includes machined bosses, threaded holes, or a thermal interface face. The trade-off is bend radius: 6061-T6 cracks at tight radii and usually needs a bend radius of at least one material thickness, sometimes more, plus bend lines placed away from heat-affected zones. Annealed 6061 forms well but needs post-weld aging to recover strength.

Cold-rolled steel and stainless steel 304 or 316L come in when the pack sits near a chemical source, outdoors, or in food and medical environments. CRS is cheap and stiff but needs plating or powder coating. Stainless resists corrosion without coating, costs more, and is harder to form and machine. 316L is the marine and washdown choice.

Weight budget decides more often than cost. A 2.0 mm aluminum tray with two formed ribs is often lighter and stiffer than a 1.2 mm steel tray with a welded frame. Run the section stiffness, not just the alloy yield strength.

• 1
  5052Default pick for formed trays and welded lids; best formability and weld quality.
• 2
  6061-T6Use where machined features dominate; respect bend radius and heat-affected zones.
• 3
  CRS and 304/316LChoose for corrosion or washdown; budget extra weight and finishing cost.

Weld distortion is the first thing that goes wrong. Local heating expands metal, the surrounding cold material resists, and the part bows as it cools. Flat sealing faces then leak and bolt holes stop lining up. The fix is process control: stitch welds in short runs, balanced weld sequences that alternate sides, fixture clamping during cooling, and heat sinking near thin sections. For a 300 mm tray in 2.0 mm 5052, a realistic post-weld flatness band is 0.2–0.5 mm across the gasket face before any machining.

Springback is the second. Every bend springs open slightly after the punch releases, and the amount depends on alloy, temper, thickness, and bend radius. In thin sheet the error is small per bend but accumulates across a chain of bends, and the last flange ends up off by a millimeter or more. Air bending with controlled angle compensation, or bottoming for tight angles, keeps formed angles inside ±0.5° on a good setup. Designers can also reduce risk by keeping bend radii consistent across the part.

Threaded inserts in thin sheet are the third. A formed thread in 1.5 mm aluminum holds very little. Rivet nuts, welded bosses, or pressed clinch inserts carry the load, but each has a pull-out limit and a minimum edge distance. For anything that sees repeated service, use a machined boss or a thicker insert plate. That is a hybrid step: the sheet carries the shape, and a CNC-machined detail carries the thread.

These three risks interact. A welded tray with a machined insert plate needs the plate welded after the tray is stress-relieved, or the weld pulls the plate out of position. Sequence the operations on the process plan, not on the shop floor.

Sheet metal is the wrong answer when the enclosure must hold a precision bore, a sealing face for a pressure test, or an O-ring gland that survives repeated cycling. Formed parts hold general dimensions well, but a bore that must stay round to ±0.02 mm and share an axis with a mating part belongs on a machined component.

Thermal interfaces are another boundary. A pack that dumps heat through a cold plate needs a flat, machined mating face with controlled roughness. Sheet metal can provide the frame and the airflow path, and a CNC-machined plate provides the interface. We see this hybrid on most liquid-cooled robot packs.

Very small enclosures are also a poor fit. Below roughly 100 mm in two dimensions, the bend deductions and flange widths eat the usable volume, and a machined housing is often cheaper and stiffer. The break-even moves with quantity: at ten parts, machining wins; at a thousand, forming wins.

A hybrid build is not a compromise. It puts each feature where the process can hold it: formed sheet for structure and shielding, machined details for bores, threads, and thermal faces, and inserts for serviceable joints.

• 1
  Bores and glandsMachine them; formed holes do not hold roundness or coaxiality.
• 2
  Thermal facesUse a machined plate with a controlled finish for cold plate contact.
• 3
  Small housingsUnder about 100 mm, a machined body is often the simpler route.

The finish on a battery enclosure does two jobs: corrosion protection and grounding. For aluminum, anodizing builds a hard oxide layer that resists abrasion and handling damage. Clear or colored anodizing is an insulator, so any grounding path must be masked or provided by a separate conductive pad. Conductive anodizing and masked contact areas keep the chassis ground path intact.

Powder coating gives thicker coverage and better chemical resistance than anodizing, but it can chip at bolt interfaces and it insulates. Where a lid must ground to a tray, mask the contact ring or add a conductive gasket. Black oxide on steel is thin and offers limited corrosion protection on its own; it is usually a base for oil or paint.

Battery chemistry sets the limits. Vented lead-acid and some lithium chemistries can release electrolyte mist or vapor. Bare zinc plating and bare aluminum corrode quickly in that environment. Electrolyte also attacks some anodized colors. Choose a coating that resists the specific chemistry, and keep the vent path away from connectors and electronics.

Laser marking is worth planning early. Minimum character height of 1.5 mm keeps labels legible after coating. Mark serial numbers, warnings, and polarity on the enclosure itself so the pack does not depend on a sticker that peels off.

GreatLight runs sheet metal fabrication alongside 127 high-precision CNC machines, including 16 simultaneous 5-axis machining centers and a Ø400 mm rotary table. That mix matters for enclosures because formed parts and machined details are made under one roof. The tray is bent and welded, then the insert plates, thermal faces, and precision holes are machined on the same part without a second supplier in the loop.

The plant covers 7,600 m² across three wholly-owned plants with 150 technicians, and processes parts up to 4,000 mm. A robot pack tray is well inside that envelope, which leaves capacity for the mating frame and brackets in the same order. Prototype quantities start at one part, and the same process scales to 10,000+ part runs.

Quality follows the drawing. Machined features hold ±0.005 mm and finishes from Ra 0.2–0.8 μm where a thermal or sealing face needs it. Inspection covers raw material check, in-process monitoring, and final inspection, with reports on request. The company holds ISO 9001:2015, IATF 16949:2016, ISO 13485:2016, and ISO 27001:2022 certifications.

Quotation and DFM analysis come back within 12 hours. Production can start within 24 hours of approval, and parts typically ship in 3–5 days. Uploads are kept confidential, and an NDA is available on request.

• 1
  One roofForming, welding, and CNC machining of insert plates and thermal faces in the same build.
• 2
  Size rangeParts up to 4,000 mm, so tray, frame, and brackets can ship as one set.
• 3
  QuantitiesNo minimum order quantity, from one prototype to 10,000+ part runs.
