A 3 axis CNC machine moves the tool in X, Y and Z only. The workpiece stays clamped in one orientation. That single setup is the whole story of the process, and it explains both the cost advantage and the geometric limits.

For an ODM program, the value is repeatability on flat-ish, prismatic geometry. Housings, brackets, plates, heat sinks, fixture bodies and manifold blocks all sit comfortably in this category. Cycle time is short because there is no rotary repositioning and no re-fixturing error to chase.

The limit appears the moment a feature sits on a face that the spindle cannot reach without the part moving. Undercuts, radial holes on a cylindrical boss, and contoured surfaces that wrap past 90° need either a fourth axis, a fifth axis, or a second setup on a different machine.

A second setup is not automatically bad. It costs a fixture, an extra op, and one more datum transfer. On a 200-piece run that overhead is usually acceptable. On a 20,000-piece run it is a permanent tax on every part.

The practical rule: if more than about 30% of the features need a second orientation, move the part to a 4 axis or 5 axis platform. If only a handful do, keep it on 3 axis and design a clean second-op fixture.

• 1
  Good fitPrismatic parts with features reachable from one direction
• 2
  Marginal fitTwo or three features on a side face, low annual volume
• 3
  Poor fitOrganic contours, undercuts, radial patterns around a bore

A hub that only owns 3 axis mills will outsource anything with a curved surface. That is fine for one prototype and painful at 5,000 parts, because you inherit two quality systems and two delivery schedules.

GreatLight runs 27 three-axis machines alongside 16 simultaneous 5-axis centers, 12 four-axis mills and 16 mill-turn centers. The mix matters more than the total count. It means a part can start on 3 axis, move to 4 axis when the geometry tightens, and still be inspected against one drawing revision.

Table travel also sets a hard ceiling. The largest platform here reaches 4,000 mm, with common envelopes at 750 × 1,150 × 550 mm and 600 × 600 × 600 mm. Anything above that needs a different process route, not a bigger quote.

Ask for the machine list with travel envelopes and spindle speeds before you send a model. A supplier who cannot produce that list in a day is probably brokering the work.

• 1
  27 three-axis machinesVolume prismatic work, flatness-critical plates
• 2
  16 five-axis centersContoured or multi-face parts in one setup
• 3
  16 mill-turn centersShafts and parts that mix turning with milling
• 4
  4,000 mm max sizeLarge frames and long extrusions

The machining is often the easy part. The export side is where ODM programs stall: material certificates, inspection reports, plating certificates, country-of-origin declarations, and the drawing revision control that ties them together.

A workable export hub issues a first article inspection report against the drawing you released, not against an internal print. It keeps raw material certificates traceable to the heat number. It records in-process measurements, and it holds final inspection data for the shipment.

Certification is a system, not a wall plaque. ISO 9001:2015 covers general quality management. IATF 16949:2016 adds automotive traceability and PPAP discipline. ISO 13485:2016 addresses medical device process control. ISO 27001:2022 covers information security, which matters when your CAD files and BOMs sit on a supplier server.

Ask which certificate applies to your part number and who audits it. A supplier holding four certificates but no in-house measurement lab is still sending you a promise, not evidence.

• 1
  FAI reportDimensional results against your released drawing revision
• 2
  Material certsTraceable to mill heat number
• 3
  In-process recordsSPC data or sampling log per operation
• 4
  Final inspection100% inspection before shipment, reports on request

Any supplier can print ±0.005 mm on a website. The question is what instrument proves it, at what temperature, and on which feature.

A ±0.005 mm callout on a 300 mm aluminium plate is a different problem from the same callout on a 20 mm bore. Thermal expansion alone moves aluminium roughly 0.023 mm per 100 mm over a 10 °C swing. If the shop floor swings more than that, the number is aspirational.

Surface finish follows the same logic. Ra 0.8–1.6 μm is a normal machined finish and easy to hold. Ra 0.2–0.8 μm needs sharp tooling, light finishing passes and a stable spindle. Chasing it on a deep pocket wall usually costs more than the function is worth.

When you receive a quote, look for the inspection method, not just the tolerance. CMM, optical comparator, micrometer and gauge pin all measure different things. A quote that names none of them is a quote you will argue about later.

• 1
  Tight tolerance±0.005 mm on critical features, confirmed by CMM
• 2
  General tolerance±0.05 mm is enough for most housings
• 3
  Fine finishRa 0.2–0.8 μm only where sealing or sliding
• 4
  As machinedRa 1.6–3.2 μm for brackets and covers

The hub model concentrates capability, which is good, and concentrates dependency, which is the risk. If one plant handles your machining, finishing, inspection and packing, a single disruption touches everything.

Distance is the other cost. A part that fails final inspection in Dongguan is 12 time zones away from your engineering team. A supplier with 100% inspection before shipment and reports on request catches most problems locally, but you still need a documented path for a rework decision.

Confidentiality belongs in the same conversation. Tooling geometry, draft angles and wall thickness often carry more design intent than the visible surfaces. Uploads should be secure, and an NDA should be available before you send the model.

None of this argues against using an export hub. It argues for choosing one whose process chain you can actually see, and for writing the inspection and rework rules into the purchase order instead of assuming them.

• 1
  Single point of failureOne plant, one schedule, one disruption
• 2
  Time zone gapRework decisions need a named owner on your side
• 3
  Design leakageNDA before model release, secure upload
• 4
  Revision driftConfirm the drawing revision in every PO
