A CNC routing machine holds a rotating cutter in a spindle and moves that cutter through the workpiece along a path defined in G-code. The G-code comes from CAM software, which reads your CAD model and converts each surface into a series of linear and arc moves. Nothing is guided by hand. Every position is a coordinate.

The cutting action is edge milling, not grinding. A two-flute or three-flute router bit shears material away as the flute passes the cut. Chip load per tooth sets the real feed rate: too light a chip rubs the edge and burns the tool, too heavy a chip stalls the spindle. On aluminum, a starting range of 0.05–0.15 mm per tooth keeps the cut stable.

Spindle speed and feed rate must move together. Doubling spindle speed without doubling feed leaves the same chip load but adds heat, because the tool spends the same time per tooth at higher surface speed. For wood and plastic, high RPM with a single-flute cutter clears chips fast. For steel, low RPM and a rigid setup matter more than spindle horsepower.

Rigidity decides accuracy. The gantry, linear rails and table all flex under cutting force. A light gantry can hold ±0.1 mm on a 1,200 mm panel; a heavy gantry with a moving table holds ±0.005 mm on smaller parts. That is why the same machine name can mean two different capability levels. Ask for the actual travel and the measured tolerance, not the brochure number.

The most common layout is a fixed gantry with a moving table. The part sits still while the table travels under the spindle. This design is stiff and handles long parts well. A 4,000 × 400 × 150 mm travel machine in this class cuts full-length extrusions and long panels without repositioning. It is also the layout most often fitted with a rotary table for 4-axis work.

A moving-gantry layout keeps the part stationary and moves the bridge. It is cheaper per square meter of cutting area and common on large sheet routers. The trade-off is that long gantries deflect more, so deep cuts in steel are not realistic. Use it for wood, plastic, composite and thin aluminum sheet where the cut depth stays under about 6 mm.

Nested routers and pod-and-rail machines handle full 1,220 × 2,440 mm sheets. They are built for throughput, not for tight tolerance. Expect ±0.2 mm across a full sheet after thermal drift. If your part needs ±0.05 mm, cut it on a smaller, stiffer machine and accept the smaller envelope.

Adding a fourth axis lets the spindle index around a part. A Ø400 mm rotary table covers most cylindrical and prismatic parts that need features on multiple faces. A fifth axis adds tilt and lets the tool reach undercuts in one setup. Fewer setups mean fewer datum shifts, which is often worth more than raw speed.

Routers excel on sheet and plate stock. Aluminum 6061, 5052 and 5083 cut cleanly with a two-flute carbide bit at 12,000–18,000 RPM. Plastics such as ABS, PC, PMMA and POM cut even faster. Wood, MDF and carbon fibre panels are the original router materials; dust extraction is mandatory for carbon because the dust conducts and damages motors.

Stainless and steel are possible but slower. A router with a 4,000 mm travel and a 9 kW spindle can take light passes in 304 or 1018, usually 0.5–1.5 mm axial depth. Heat builds fast, so coolant or chilled air is not optional. Tool life drops sharply compared with a dedicated milling center.

Titanium and Inconel are a poor fit for most routers. These alloys need low surface speed, high pressure coolant and a very stiff spindle. The long gantry that gives a router its reach also lets it chatter. If your part is titanium, route the blank to size and move it to a 5-axis mill for the features that matter.

Composites sit in the middle. Carbon fibre and glass-filled panels cut well with diamond-coated tooling, but the abrasive dust wears carbide quickly. Expect to change tools more often than on aluminum. Sealing the cut edges with a post-process matters for parts that see moisture, because exposed fibre wicks water.

Tolerance on a routed part comes from three sources: machine geometry, thermal drift and workholding. Machine geometry is fixed at build. Thermal drift grows through the day as the spindle and drives warm up. Workholding is the one you control on the shop floor, and it is the most common cause of a part that measures wrong.

Vacuum tables hold flat sheet well but let thin panels bow between passes. A 1.5 mm aluminum panel will lift under a heavy cut and spring back, leaving a tapered edge. Tab-and-slot fixturing plus a light finish pass removes that error. On thicker plate, mechanical clamps give a more repeatable datum.

Thermal drift on a large router can reach 0.05–0.1 mm over an 8-hour shift. That sounds small until your feature has a ±0.02 mm callout. The fix is to rough in the morning, let the machine stabilize, then take finish passes after a warm-up cycle. Shops that run lights-out often probe the fixture before each batch.

A capable shop can hold ±0.005 mm on small routed features when the machine is warm, the fixture is rigid and the tool is fresh. That is the floor, not the everyday number. Across a full 1,200 mm panel, plan for ±0.05 mm and design clearance accordingly.
