Screw processing at the heavy scale: how big threads actually get cut
Large screws move the load in presses, mills and injection units. This page explains how screw processing at the heavy scale differs from ordinary thread turning, where the process breaks down, and how to judge whether a part belongs on a lathe or a thread mill.
What makes screw processing at the heavy scale different
A screw on a heavy machine tool is not a fastener. It is a power transmission element. A ball screw on a 4,000 mm travel gantry, a lead screw on a press ram, or an extruder screw in an injection unit all convert rotary motion into linear force, often at several tonnes of thrust. That job description changes everything about how the thread is made.
The first difference is stiffness. On a Ø20 mm screw, a light finish pass removes the last few microns and the part barely deflects. On a Ø200 mm screw with a 3,000 mm unsupported length, the workpiece bends under its own weight and under cutting force. Cutting one side of the thread pushes the part away from the tool, so the thread flanks come out tapered along the length.
The second difference is heat. A heavy screw removes a large volume of metal. On a 6 mm pitch thread with a 4 mm depth of cut, the chip load per pass is measured in kilograms, not grams. If coolant cannot reach the cutting zone, the workpiece grows 0.01–0.03 mm per 100 mm of length before the finish pass even starts.
The third difference is handling. A 300 kg screw cannot be flipped between operations without a crane and a steady rest. Every setup change costs hours and adds a chance to lose concentricity between centers.
Turning, milling or whirling: which method fits the screw
Single-point turning is still the default for external threads on heavy screws. It needs one rigid setup, a tool that can reach the thread root, and enough spindle torque to keep surface speed constant as the diameter drops. On a Ø300 mm part, a worn insert changes thread height by more than the tolerance band within a few passes.
Thread milling wins when the screw is too large to rotate, when the thread sits close to a shoulder, or when the part is a one-off that cannot justify a form tool. A 16 mm carbide thread mill on a five-axis center can cut an internal thread in a 400 mm bore that no tap will ever reach. The trade-off is cycle time. Milling a 3,000 mm thread removes the same material in many more passes.
Whirling and rolling sit at the production end. Thread rolling displaces material instead of cutting it, which raises fatigue strength because the grain flows along the thread root instead of being cut across it. It only works on ductile material below roughly 40 HRC and needs a blank diameter held within a tight band. Rolled threads on a hardened 4140 screw are not an option.
For a single heavy screw, turning plus thread milling for the root cleanup is usually the practical answer. For 500 identical screws, rolling or whirling pays back the tooling within the first batch.
Workholding, steady rests and the deflection budget
A long screw behaves like a beam. Support it at two points and the middle sags. Support it at three and the sag drops by roughly a factor of eight. That is why a steady rest is not optional on screws longer than about 10 times their diameter. On a 4,000 mm screw, two steady rests plus the chuck and tailstock give four support points.
The steady rest itself introduces error. Each jaw contact is a potential high spot, and if the jaws are preloaded too hard they push the part off center. We set jaws to light contact and check runout at each rest before the first cut. A 0.02 mm runout at the rest becomes a 0.02 mm thread eccentricity at the finished part.
Between centers is the other common route, and it is better for concentricity because the centers define the axis. It is worse for stiffness, because the tailstock only supports one end. For screws with a large length-to-diameter ratio, we combine both: centers for the axis, rests for the stiffness.
Temperature matters during setup too. A screw that measures 3,000.00 mm at 20 °C will measure about 3,000.36 mm at 30 °C in steel. If the shop warms up between roughing and finishing, the pitch measurement drifts with it.
Pitch accuracy, lead error and what the drawing really needs
Lead error accumulates. A 0.01 mm error per revolution is invisible on a 50 mm screw and becomes 0.6 mm over 60 revolutions on a 3,000 mm screw. That is why long screws are specified by cumulative lead error over a defined length, not by a single pitch tolerance.
Lead error comes from three places: thermal growth, machine axis error and tool wear. Machine compensation handles the second. The first and third have to be managed by the process. Rough between centers, cool the part, then finish. Measure at the same temperature the part will see in service if that number matters.
Thread form error is a separate budget. A 60° thread with a 2° flank error still assembles, but it contacts on one flank only. Under load that flank carries roughly double the designed stress. For a screw that sees reversing load, that is where the fatigue crack starts.
Surface finish follows the same logic. A turned thread at Ra 1.6–3.2 μm is fine for a lead screw that runs slowly. A ball screw raceway or a high-speed screw needs Ra 0.2–0.8 μm after grinding or hard turning, because the rolling elements follow every tool mark.
Method selection by screw size and volume
Use this as a first filter, not a final process plan.
| Condition | Single-point turning | Thread milling | Rolling or whirling |
|---|---|---|---|
| Diameter above Ø150 mm | Preferred | Workable with large tool | Not practical |
| Length above 2,000 mm | Needs rests plus centers | Limited by machine travel | Rarely available |
| Internal thread in deep bore | Reach is the limit | Preferred | Not applicable |
| Hardened material above 40 HRC | Hard turning or grinding | Carbide mill only | Not applicable |
| One-off prototype | Fastest route | Good for shoulders | Tooling cost too high |
| Volume above 500 pieces | Slow per part | Slow per part | Lowest cost per part |
| Thread close to a shoulder | Tool clearance problem | Preferred | Not applicable |
The practical split
For one large screw, turn it between centers with steady rests and finish the root by milling. For a repeating family of screws under Ø80 mm in ductile steel, roll the thread and stop cutting metal altogether.
Questions engineers ask before quoting a heavy screw
How long can a screw be before the process stops working?
Length alone is not the limit. The ratio of length to diameter is. Past roughly 20:1, deflection and chatter dominate and the process needs more support points, lower depth of cut and slower surface speed.
Our largest travel is 4,000 × 400 × 150 mm, so a 4,000 mm screw is inside the envelope. Whether it holds tolerance depends on the support plan, not on the machine size alone.
Can you cut an internal thread in a heavy housing?
Yes, by thread milling on a five-axis center or by single-point boring with an internal threading bar. Taps are not used above roughly Ø50 mm because the torque is not controllable and a broken tap scraps the part.
For threads deeper than three times the diameter, we bore a relief groove and mill the thread in passes to clear chips.
Does thread rolling really make a stronger screw?
It raises fatigue strength because the material grain follows the thread root instead of being cut across it, and the root is left in compression rather than tension.
It does not raise core strength and it does not work on hardened steel. Rolling also needs a blank diameter held tightly, so the pre-turn still has to be accurate.
What tolerance can we hold on pitch over a long screw?
We work to ±0.005 mm on features we can measure at temperature, but cumulative lead error over 3,000 mm is a different budget. It depends on thermal control during the finish pass and on how the part is measured afterward.
Send the drawing with the measuring length and the reference temperature and we will tell you what is realistic before quoting.
Which materials are hard to thread at large diameter?
Stainless 316 and 17-4PH work-harden, so a dwell in the cut hardens the surface and dulls the insert. Titanium and Inconel are worse: low thermal conductivity keeps heat in the tool edge.
Aluminium and free-machining brass at large diameter are the easy cases. 4140 and 4340 cut well in the annealed state and are usually finish-ground after heat treatment.
Do you inspect every heavy screw before shipment?
Yes. Raw material check, in-process monitoring and final inspection are standard, and inspection reports are available on request.
For long screws, we record lead error along the length and runout at each support point, not just at the ends.
