Hygienic parts are a cleaning problem before they are a machining problem. Every surface that touches product has to shed residue, survive caustic washes and hold its shape after thousands of thermal cycles. That is the reason buyers come to us with a drawing and a wash-down spec rather than a tolerance alone. The cut geometry drives the result more than the machine model does.

On a food line, the parts that justify milling are the ones with compound angles, o-ring grooves, or a bore that must line up with a mating face. A filler valve body is a good example. So is a rotary cutter hub. These are not large parts, but a tenth of a millimeter of mismatch shows up as leakage or metal-to-metal contact. Five-axis work lets us reach the seat and the flange in one setup, which keeps the datum honest.

Parts that do not justify milling are flat covers, simple brackets and anything whose function is structural. A press brake and a laser will make those faster and cheaper. We say so when a customer sends a drawing that should have gone to sheet metal. It saves them money and it saves us a rework argument later.

The dividing line is usually function. If a surface seals, guides or meters product, it earns a machined finish. If it only holds two other parts together, it does not.

Austenitic stainless is the default for wet contact. Grades 304 and 316L cover most pump housings, valve bodies and filler nozzles. Grade 316L resists chloride pitting better, which matters on CIP lines running caustic and acid in sequence. Grade 303 machines faster but its sulfur content makes it a poor choice for product contact. Use it for internal brackets instead.

Aluminum has a narrower role. Grade 6061-T6 works well for frames, guards and non-contact hardware, especially when weight matters on a moving gantry. Bare aluminum will not survive a caustic wash. If the part sees wash-down, hardcoat anodizing gives a surface that resists both abrasion and mild chemistry. Even then, keep aluminum away from acidic product.

Engineering plastics fill the rest. PEEK and POM are common for guides, star wheels and low-load bushings. They do not corrode, they run quietly, and they can be machined to a fine finish. The trade-off is thermal growth and creep under load, so we check the fit at operating temperature, not at 20 °C.

Titanium and Inconel show up in high-wear applications such as homogenizer valves. They are expensive and slow to cut, so they need a real justification. Wear rate on an abrasive slurry is usually that justification.

• 1
  Wet contact304 or 316L stainless, electropolished where product sticks
• 2
  Dry structure6061-T6 aluminum or 304 sheet, anodized if washed
• 3
  Low-load wear partsPOM, PEEK or 17-4PH depending on load and temperature

A general machining tolerance of ±0.05 mm covers most food equipment features. When a feature seals or meters, the callout tightens. We hold ±0.005 mm on critical bores and shaft fits when the drawing asks for it. Going tighter than that rarely helps a food machine, because thermal expansion during CIP moves the parts more than the tolerance does.

Surface finish is the number that decides cleanability. An as-machined Ra 1.6–3.2 μm surface traps product in its tool marks. A finish of Ra 0.8–1.6 μm is a practical target for most contact faces. Where biofilm is a known risk, such as in dairy or brewing, we polish to Ra 0.2–0.8 μm and follow with electropolishing on stainless. That removes the peaks without changing the geometry.

Roughness and geometry interact. A sharp internal corner at a port will hold residue no matter how smooth the walls are. We radius those corners at 1 mm or more and blend them into the bore. This is a design change, not a machining trick, and it is worth making before the first cut.

Cost climbs quickly once you push past Ra 0.8 μm. Hand polishing on a complex five-axis surface can take longer than the milling itself. Specify the finish the cleaning process needs, then stop.

Dead pockets are the most common defect we see in food drawings. A blind hole with a flat bottom collects product and resists rinsing. Drill it through, or add a relief radius so the wash fluid reaches the bottom. The same logic applies to threaded holes in contact zones. A through-tapped hole drains; a blind one does not.

Drainage matters on any horizontal surface. Slope flat tops by 1° to 3° toward an edge so liquid runs off instead of pooling. On large housings we sometimes machine a shallow groove to channel flow to the outlet. It costs one extra toolpath and removes a sanitation finding.

Faying surfaces and crevices are harder to fix. Two parts bolted face to face create a gap that no rinse reaches. Where the joint is unavoidable, use a gasket that fills the gap fully, or seal the edge with a weld that is ground flush. A visible seam is easier to clean than a hidden one.

Fasteners deserve a mention. Exposed threads on the product side should be avoided. Use a smooth shank or a cap so there is nothing for residue to cling to. These are small changes, but they decide whether the equipment passes a swab test.

A food machine often needs a paper trail as much as it needs a good part. We check raw material certificates before cutting, monitor dimensions in process, and inspect 100% before shipment. Reports are available on request, including dimensional results and material traceability. Buyers who carry ISO 9001 or IATF 16949 obligations usually ask for both.

For contact parts, the inspection plan should name the features that matter. A bore diameter, a seal groove depth and a surface roughness value are the usual three. Everything else is secondary, and inspecting it adds cost without adding safety. We write the plan with the customer so the first article review is short.

First article inspection is worth the day it takes. On a new valve body, it catches a datum error before a production run is committed. We send the report with photos of the critical features and a note on any deviation we had to hold.

Certifications cover the process, not the part. ISO 9001:2015, IATF 16949:2016, ISO 13485:2016 and ISO 27001:2022 are in place at our Dongguan and Singapore facilities. They tell you how we control the work. The inspection report tells you what this specific part measured.
