The short answer is uneven shrinkage. The first layer goes down at roughly the temperature of the nozzle, and every layer above it cools toward room temperature. Printing at 250 °C and cooling to 25 °C removes about 225 °C of thermal energy from the part. The polymer or metal tries to contract. It cannot, because the layer underneath is already partly solid and the one above is bonded to it.

That contraction has to go somewhere. Most of it is absorbed as internal stress inside the part. When the part is thin and flat, the stress finds a release at the free edge, and the edge curls. A right angle on a base plate is the worst case because the corner has the least material to resist the pull.

So when engineers ask how to prevent 3D printing angles from being held, they are really asking how to manage shrinkage. Three variables set the size of the problem: the temperature swing from extrusion to ambient, the stiffness of the material below its glass transition, and how much of the part is bonded to the plate.

A 100 mm long ABS bar printed on a 110 °C bed still sees a 150 °C drop. That is enough to move the free end by a millimeter or more if nothing constrains it. Scale the same part to 300 mm and the movement triples. This is why small brackets print clean and large flat panels do not.

Amorphous polymers such as ABS, ASA and PC shrink a lot and have a wide softening range, so they keep moving long after the nozzle leaves. Semi-crystalline materials like PA and POM shrink even more in total, but they freeze faster because crystallization locks the chain network. PLA is the mildest case: low shrinkage, low bed temperature, and it still warps if the plate is dirty.

Metal powder bed processes behave differently. DMLS and SLM melt a tiny pool with a laser, and that pool cools at rates near 10⁶ K/s. The top of the melt track contracts against the solid layer beneath it, which leaves tensile residual stress in the part and compression in the base plate. Long thin walls and sharp corners are where that stress shows up first.

The practical consequence: the same geometry that warps in ABS is usually fine in PLA, and the same geometry that survives in ABS may still peel in Ti-6Al-4V. Material choice is the first decision, not the last.

Fillers change the picture again. Carbon fibre and glass fibre raise stiffness and cut the coefficient of thermal expansion, so a 30 percent glass-filled PA12 part resists corner lift far better than unfilled PA12. It also costs more and wears nozzles faster.

Adhesion is the cheapest lever. A clean plate matters more than any slicer value. Wipe PEI or glass with isopropyl alcohol before every print, and use a brim of 5 to 10 mm on parts with sharp corners. A brim costs a few seconds of print time and spreads the peel force over a longer line.

Drop the first layer speed to 15–20 mm/s and raise the first layer height to 0.25–0.3 mm on a 0.4 mm nozzle. That gives the polymer time to wet the plate and presses it flat. Keep the part cooling fan off for the first three layers.

Enclose the printer for anything above 60 °C bed temperature. A steady 45–60 °C chamber cuts the thermal gradient across the part and is the single biggest change for ABS and ASA. A cardboard box over an open printer is not elegant, but it works.

If corners still lift, add a 0.2–0.4 mm sacrificial pad under each corner, or move the part to a location away from the door and the fan. Air movement of 0.5 m/s across a large part is enough to start a curl.

The strongest fix is to stop fighting the geometry. A 3 mm fillet at the base of a wall replaces a sharp stress riser with a gradual transition. Printed corners with a radius of 2–5 mm lift far less than true 90° corners because the peel front has to travel around a curve instead of starting at a point.

Chamfer the bottom edge of large flat parts by 0.5–1 mm. This removes the thin feather edge that curls first and gives the nozzle a wider footprint on the plate. It also makes part removal easier without a scraper.

Orientation matters as much as shape. Tilting a flat panel 10–15° about its long axis reduces the contact area and the peel length. In metal AM, rotating a part 45° in the build plane changes the scan vector direction relative to the long edge and lowers residual stress at the corners.

Avoid large unsupported flat areas. If a face must be flat, break it with ribs or a raised boss. Ribs add stiffness without adding much mass, and they interrupt the continuous shrink line that drives a curl.

Metal parts are not glued to a plate; they are welded to a build plate through supports and anchors. Corner lift in DMLS usually means the anchors were too weak or too few. Place anchors every 5–10 mm along a long edge, and make them thicker than the supports carrying the part.

Scan strategy controls stress build-up. Island or stripe scanning with a 67° rotation between layers spreads heat more evenly than a long raster. Preheating the plate to 100–200 °C for Ti-6Al-4V and up to 200 °C for aluminium reduces the temperature drop per layer.

Post-build stress relief is standard, not optional. Parts are cut from the plate, then heat treated per the alloy specification to relax residual stress before finish machining. Without that step the part can move during CNC finishing and lose the tolerance you paid for.

At GreatLight we run metal and polymer printing alongside 127 CNC machines, so a printed preform can go straight into 5-axis finishing at ±0.005 mm when the printed surface is not good enough. That combination is often cheaper than printing to final tolerance.

Some parts should not be printed. A 400 × 400 mm flat plate with a 3 mm wall will lift in almost any polymer, no matter how the settings are tuned. The shrink force scales with length, and adhesion scales with area. Past a certain size, the plate loses.

Thin, long, high-aspect parts with a sharp base corner are the classic failure case. If the part is also a functional prototype that must hold ±0.05 mm, printing is the wrong process. Milling from 6061 or 304 stock removes the shrink problem entirely.

There is a middle zone where printing still wins: complex internal channels, lattice structures, or low-volume brackets with a few critical faces. Print the body, then machine the two or three faces that carry the tolerance. This hybrid route avoids both a long lead time and a warped part.

Judge the part on its longest unsupported dimension, not its total size. Under roughly 80 mm, most materials behave. Above 150 mm, expect to add anchors, brims, or a design change. Between those numbers, test one part before you commit to a run.
