Materials explainer

Biodiesel Waste Filament: How It Is Made and When to Print It

Crude glycerin is the main byproduct of biodiesel production, and it is the feedstock behind this filament family. This page covers how the resin is purified, how the filament is compounded and extruded, what the printed parts actually measure, and where the material stops making sense. Written for engineers who have to pick a polymer and defend the choice.

Get Instant Quote Talk to an Engineer

Glycerin feedstockRenewable carbonExtrusion windowEnd-of-life options

Biodiesel waste filament spool used for 3D printing

On this page

Where biodiesel waste filament starts

Transesterification turns vegetable oil or animal fat into biodiesel. For every 10 kg of biodiesel, roughly 1 kg of crude glycerin drops out as a bottom stream. That glycerol-rich phase is the starting point for biodiesel waste filament. It arrives dark, wet and loaded with methanol, soap, salts and residual fatty acid methyl esters.

Crude glycerin is not a polymer. It is a small three-carbon molecule with three hydroxyl groups, which makes it a plasticizer and a chain terminator rather than a backbone. The value in the waste stream is the carbon skeleton and the reactivity, not any inherent strength.

So the first job in any serious process is purification. Neutralize free fatty acids with acid or base, split the soap layer, then distill or vacuum-flash off methanol and water. Glycerol content typically climbs from 40–60 percent in the raw stream to above 95 percent after two passes.

What you keep after purification is a clear, viscous liquid. It still holds trace salts and color bodies, and those traces matter later. A few hundred ppm of sodium or sulfate will show up as voids and discoloration in the extruded strand.

1
Raw streamDark, alkaline, 40–60 percent glycerol with methanol and soap.
2
Purified glycerolAbove 95 percent glycerol, water-clear, low salt content.
3
Rejected fractionSoap, salts and heavy ends go back to the biodiesel plant.

Chemistry

How glycerol becomes a printable polymer

Glycerol alone will not print. It needs to be built into a longer chain. Two routes dominate. The first reacts glycerol with a diacid such as succinic or adipic acid to form a polyester. The second converts glycerol to a cyclic carbonate and then into a polyurethane or polycarbonate-type backbone.

Both routes are step-growth polycondensation. You heat the monomers, strip water or methanol as the reaction proceeds, and stop when the molecular weight reaches the target. Number-average molecular weight for a usable FDM resin usually lands between 20,000 and 60,000 g/mol.

Molecular weight is the single biggest lever on print behavior. Low molecular weight gives a brittle strand that snaps in the extruder. Very high molecular weight raises melt viscosity until the nozzle cannot keep up at normal flow rates.

Most commercial grades are copolymers or blends. Glycerol-based polyester is often compounded with PLA, PBS or a small amount of chain extender. The blend sets the melting point, the stiffness and the price, and it also decides whether the part will biodegrade in an industrial compost stream.

1
Polyester routeGlycerol plus diacid, water stripped, 20,000–60,000 g/mol.
2
Carbonate routeGlycerol carbonate, then urethane or carbonate linkages.
3
Blend routeCopolymer with PLA or PBS to tune melt and stiffness.

Extrusion

Compounding and extrusion into 1.75 mm strand

Purified glycerol resin is dried to below 300 ppm moisture before it sees heat. Polyester backbones hydrolyze fast, and a wet pellet will lose molecular weight inside the barrel within minutes. Dry it in a desiccant dryer at 60–80 °C for 4–6 hours.

Compounding runs on a twin-screw extruder with a gentle screw profile. Barrel zones sit around 150–190 °C depending on the comonomer. Additives go in through a side feeder: nucleating agent for faster crystallization, antioxidant to survive the second heat history, and color masterbatch if needed.

The melt is strand-pelletized, then re-extruded into filament. Diameter tolerance for 1.75 mm filament is normally held at ±0.03 mm, with ovality under 0.02 mm. That tolerance is what keeps your flow rate stable across a spool.

Cooling is the step people underestimate. A glycerol-based polyester crystallizes slowly. Cool the strand too fast in a water bath and you freeze in an amorphous skin that later warps in the printer. Slow the quench and you get a more uniform, if slightly opaque, strand.

1
Dry to under 300 ppm60–80 °C desiccant dry, 4–6 hours, before any melt step.
2
Barrel zones150–190 °C, gentle screw, side-fed additives.
3
Diameter tolerance±0.03 mm on 1.75 mm, ovality under 0.02 mm.

Printing

Print settings and what the part measures

Nozzle temperature for most glycerol-polyester grades sits between 190 and 220 °C. Below 190 °C the layers bond poorly and you can pull the part apart by hand. Above 220 °C the polymer starts to degrade and you get stringing plus a sweet, acrid smell.

Bed temperature matters more than it does with PLA. Set 50–70 °C on a PEI sheet or 60 °C with glue stick on glass. First-layer adhesion is the usual failure point, and it usually traces back to a bed that is 10 °C too cold.

Print speed runs 40–70 mm/s on a 0.4 mm nozzle. Part cooling fan at 30–60 percent. Full fan blasting tends to cause layer delamination on taller parts because the interlayer temperature drops too far.

Dimensional results are predictable once the machine is dialed in. A calibrated FDM printer holds ±0.2 mm on a 100 mm feature, which is normal for the process and not a material problem. Wall thickness and hole size drift more than PLA, so always compensate in the slicer.

1
Nozzle190–220 °C on a 0.4 mm nozzle.
2
Bed50–70 °C, PEI or glue stick on glass.
3
Speed and fan40–70 mm/s, part cooling at 30–60 percent.

Limits

Mechanical limits and environmental caveats

Tensile strength for a glycerol-based polyester blend typically lands between 30 and 50 MPa, with a modulus in the 1.5–2.5 GPa range. That sits near PLA on stiffness but below it on peak strength, and well below ABS on impact.

Heat resistance is the real ceiling. Glass transition temperature for these blends is often 45–60 °C. A part left on a car dashboard in summer will sag. Do not use this material for anything that sees sustained heat above 50 °C.

Biodegradability claims need scrutiny. Most of these blends break down only in industrial composting at 55–60 °C with controlled humidity, not in a home compost bin and not in seawater. Ask the supplier which standard the claim references.

Moisture uptake after printing is moderate but real. Parts can absorb 0.5–1.5 percent water by weight over weeks in humid air. That swells dimensions slightly and softens the surface, so store finished parts dry if tolerance matters.

1
Tensile30–50 MPa, modulus 1.5–2.5 GPa.
2
Glass transition45–60 °C, so keep service temperature low.
3
Composting claimUsually industrial only, not home compost or marine.

Selection

Biodiesel waste filament against common FDM materials

Values are typical ranges for commercial grades, not guarantees for a specific spool.

Material	Nozzle temp	Tensile strength	Best fit
Biodiesel waste blend	190–220 °C	30–50 MPa	Low-heat parts, marketing-grade renewability
PLA	190–220 °C	50–70 MPa	Visual prototypes, stiff low-load brackets
PETG	230–250 °C	45–55 MPa	Functional parts needing some toughness
ABS	240–260 °C	35–50 MPa	Warm environments, post-processing with acetone
Nylon (PA)	250–270 °C	60–80 MPa	Living hinges, wear parts, impact loads

When to choose it and when to walk away

Pick biodiesel waste filament when the part is a low-load enclosure, a display model or a sustainability-tied prototype that stays below 50 °C. Choose PETG or nylon instead when the part takes impact, holds a thread, or sees heat above 60 °C. And if the part must hold ±0.05 mm or better in metal, print the concept in this filament and machine the production part in aluminium or stainless.

Get Instant Quote Talk to an Engineer

FAQs

Common questions

Does biodiesel waste filament smell while printing?

There is a faint sweet odor at the top of the temperature range, especially above 220 °C. It is much milder than ABS.

Below 210 °C most users notice nothing. Still vent the printer or use an enclosure with a carbon filter if the machine sits in an occupied room.

Can I print it on a stock printer without a heated bed?

It will stick to blue tape or a glue-stick-coated glass bed at room temperature, but the first layer is unreliable.

A heated bed at 50–70 °C raises first-layer success a lot. If your printer has no bed heater, use a brim of 5–8 mm and slow the first layer to 20 mm/s.

Is the finished part actually compostable?

The polyester backbone can biodegrade, but the rate depends on the blend and the environment.

Industrial composting at 55–60 °C with controlled humidity is the realistic route. A backyard compost pile rarely reaches those conditions, and seawater degradation is very slow.

How should I store the spool?

Sealed with desiccant, same as PLA or PETG. Target under 20 percent relative humidity inside the container.

If a spool sits out for weeks, dry it at 60 °C for 4 hours before printing. Wet filament shows up as popping sounds and a rough surface.

Can these parts be machined or tapped afterward?

Yes, with care. The material cuts cleanly at high spindle speed and low feed, but it heats up fast and can smear.

For tapped holes under M4, print undersize and tap with a sharp tap and cutting fluid. For anything load-bearing, we machine the part from aluminium or stainless instead.

Where does CNC machining fit if I already printed the part?

Printing validates form and fit. Machining validates function.

We commonly take a printed concept and turn it into an aluminium 6061-T6 or 17-4PH prototype held to ±0.005 mm, which is the step that proves the design before tooling.
