China CNC Machining Manufacturing Tips for Precision Parts

• 1
  Key takeaways
• 2
  Verify tolerance claims feature by feature
• 3
  Pin the material grade and demand traceability
• 4
  Specify surface finish as a number and a process
• 5
  Match the process plan to part geometry
• 6
  Build the inspection plan before the PO
• 7
  Step by step: releasing a precision part to a China CNC shop
• 8
  What to verify and how

A shop that advertises ±0.005 mm is telling you what its best machine can do on a good day, not what your part will measure. General tolerances on a drawing usually sit around ±0.1 mm for milled features. Tight bands belong only on the two or three dimensions that actually drive function, such as a bearing bore or a mating shoulder.

The first thing to check is which dimensions carry the tight callout. On a 200 mm aluminum bracket, holding ±0.005 mm across the full length is a different problem from holding it on a 12 mm bore. Thermal drift alone moves aluminum about 0.023 mm per degree Celsius over 200 mm. If the shop does not mention temperature-controlled inspection, the number on the quote is marketing.

Ask for the measurement method, not just the result. A CMM report with the probe diameter, stylus length, and alignment datums tells you whether the number means anything. A caliper reading on a 0.005 mm band is noise. For bores under Ø10 mm, pin gauges or an air gauge are more repeatable than touch probing.

One useful test: send a part with one deliberately tight feature and five loose ones. See whether the shop flags the cost driver in DFM feedback or just quotes the whole part as tight. The second response tells you the quote was not engineered.

• 1
  General milling±0.1 mm is normal and cheap.
• 2
  Tight bandsLimit to functional features only.
• 3
  Thermal riskAluminum moves 0.023 mm per °C over 200 mm.
• 4
  ProofCMM report with datums and probe details.

Material substitution is the quietest failure mode in China CNC machining manufacturing tips discussions. Your drawing says 6061-T6. The shop stocks 6061-T4 because it machines easier and costs less, then skips the aging step. Yield strength drops from roughly 276 MPa to about 145 MPa. The part passes dimensional inspection and fails in service.

Write the grade and temper as separate requirements. 6061-T6 is not the same as 6061. For stainless, 304 and 304L differ in carbon content, which matters after welding. 316L and 17-4PH are not interchangeable on a marine bracket. If the alloy family is loose in your drawing, expect a loose answer.

Require the mill certificate with heat number on the first article and on any production run above a few hundred pieces. Cross-check the heat number against the material test report. For aerospace and medical work, the traceability chain should run from the raw bar to the finished part serial number.

Some shops keep standard stock of 6061, 7075, 304, 316L, and Ti-6Al-4V. That shortens lead time and lowers the risk of a substitution. If your alloy is unusual, such as Inconel or AZ31B, confirm stock before you commit to a schedule.

• 1
  Temper matters6061-T6 vs T4 changes yield strength by about 130 MPa.
• 2
  CertificatesMill cert with heat number on the first article.
• 3
  ChainRaw bar to part serial for regulated industries.

The word anodized covers a wide range. Clear anodizing builds roughly 5–10 μm of oxide. Hardcoat runs 25–50 μm and changes the dimension on a press fit. If your bore tolerance is ±0.01 mm, a 40 μm coating eats the whole allowance on a radius. Specify the finish thickness, not just the finish name.

As-machined aluminum typically lands at Ra 1.6–3.2 μm. A good CNC shop can reach Ra 0.8–1.6 μm on a milled face without extra operations. Ra 0.2–0.8 μm needs a finer step-over, sharper tooling, or a secondary polish, and it costs time. Put the Ra value on the specific face that needs it.

Color matching is a separate problem. Anodizing dye lots vary. If two parts must match visually, run them in the same batch and accept the batch color, not a Pantone number. Laser marking has a minimum character height of about 1.5 mm, so keep part numbers readable at that size.

Masking decisions drive cost more than the finish itself. Every masked area is manual labor. If you can move a threaded hole out of the anodize zone by design, do it.

• 1
  Hardcoat25–50 μm buildup, plan the allowance.
• 2
  Standard milledRa 1.6–3.2 μm as-machined.
• 3
  Fine finishRa 0.2–0.8 μm costs extra time.
• 4
  MarkingMinimum character height 1.5 mm.

A part with features on five faces needs either multiple setups or a 5-axis machine. Each extra setup adds a datum shift. On a ±0.02 mm part, three setups can eat the tolerance before the first chip. If the geometry allows it, one 5-axis setup is the cheaper path to accuracy.

Long parts change the rule. A 4,000 mm rail on a machine with 4,000 × 400 × 150 mm travel needs a plan for sag and clamping. Deep pockets on a thin wall deflect under cutting force, so the shop should rough, stress-relieve if needed, then finish with light passes. Ask how they plan the roughing and finishing split.

Material removal rate is not the goal on precision work. A 0.5 mm finishing pass at moderate feed leaves a better surface than a heavy pass followed by a spring pass. If the shop quotes the fastest cycle time, check whether the finish callouts survive.

For prototypes, a 3-axis machine with the right fixture often beats a 5-axis machine with a rushed setup. The choice is about datums, not machine prestige.

• 1
  SetupsEach one adds datum shift.
• 2
  Thin wallsRough, relieve, then light finish passes.
• 3
  Long partsPlan clamping and sag control.

Inspection is where a good quote and a bad quote separate. A shop that inspects 100% of parts before shipment and gives you reports on request is a different supplier from one that samples the first article and ships the rest. Write down which dimensions get measured, with what instrument, and at what frequency.

First article inspection should cover every dimension on the drawing plus the material cert and finish thickness. In-process checks belong on the features that tend to drift, such as a bore that wears the tool. Final inspection confirms the critical dimensions and the visual standard.

For regulated work, the inspection plan feeds the quality record. ISO 9001:2015 covers the general system. IATF 16949:2016 adds automotive traceability and PPAP-style discipline. ISO 13485:2016 covers medical devices. ISO 27001:2022 covers information security, which matters when you upload proprietary CAD.

Ask for the gauge calibration interval. A CMM that has not been calibrated in two years will still print a report. The report is only as good as the calibration sticker.

• 1
  First articleAll dimensions plus certs.
• 2
  In-processFeatures that drift with tool wear.
• 3
  FinalCritical dims and visual standard.
