A cutting laser is a heat source, not a blade. The resonator produces a single-wavelength beam, and a lens or mirror head focuses it to a spot roughly 0.1–0.3 mm across. Power density at that spot reaches the 10^6 W/cm² range. At that level steel does not need to be oxidized to cut; it simply melts. The assist gas then blows the molten pool down through the kerf and out the bottom.

The older CO2 generation used a 10.6 μm wavelength and a gas-filled tube. The beam reflected off mirrors and was hard to deliver through a fiber. The current generation uses a ytterbium-doped fiber or disk source at about 1.07 μm. That wavelength travels through a flexible delivery fiber, which is why the cutting head can move on a gantry without an optical arm.

Three variables decide whether the cut is clean. Focus position sets where the narrowest part of the beam sits relative to the top surface. Cutting speed sets how long the metal stays under the spot. Assist gas pressure and type set how fast the molten material leaves. Change any one and the dross on the underside tells you what happened.

The practical result of the new generation is not just higher power. Wall-plug efficiency moved from roughly 10 percent on CO2 to 30 percent or more on fiber. Power per unit of floor space went up, and maintenance dropped because there is no resonator gas to refill and no turbomolecular pump to service.

Focus position is the first dial to understand. Set the focus slightly below the surface for mild steel with oxygen. Set it slightly above the surface for stainless with nitrogen. Move focus the wrong way and you get a wide kerf with heavy dross on thin material, or an incomplete cut on thick plate.

Assist gas is the second dial. Oxygen reacts with iron and adds chemical energy to the cut, so it moves fast through mild steel but leaves an oxidized edge. Nitrogen is inert, so it produces a clean, weldable edge on stainless and aluminum, at the cost of higher gas consumption and slower speed. Compressed air sits between them and works on thin gauge where edge chemistry does not matter.

Nozzle diameter and standoff matter more than most operators expect. A 1.5 mm nozzle at 0.8 mm standoff behaves differently from a 2.0 mm nozzle at 1.2 mm. Larger standoff gives the gas jet room to expand and lose coherence, which shows up as dross on the bottom edge and a wider heat-affected zone.

Cutting speed has a narrow window. Too slow and the kerf widens, the heat-affected zone grows, and the bottom edge self-ignites into dross. Too fast and the beam does not fully penetrate, leaving a rough fracture line instead of a cut face. The correct speed is the fastest one that still produces a clean bottom edge.

Kerf width sets a hard floor on feature size. If the kerf is 0.2 mm, you cannot cut a useful 0.3 mm slot, and you should not design a hole smaller than roughly the material thickness. A 2 mm hole in 6 mm stainless will come out tapered, and the pierce will leave a heat mark on the top face. Drill it or mill it instead.

The heat-affected zone is the second boundary. Laser cutting is a thermal process, so the cut edge cools fast and hardens. On 4130 or 4140 steel that can mean a locally hardened edge that cracks during forming. If the part will be bent after cutting, either stress-relieve it or move the bend line away from the cut edge.

Copper and brass are the third boundary. At 1.07 μm, these alloys reflect most of the beam and conduct heat away quickly. Cutting 3 mm copper on a standard fiber machine is possible only with high power and a tight focus, and the result is often slow. If the part is a busbar, expect the shop to quote it as a special job.

The fourth boundary is geometry. Laser cutting produces a 2D profile with a near-vertical cut face. A counterbore, a thread, a chamfer, or an internal pocket cannot come off the laser. Those features need a second operation, and if there are many of them, the part should start on a CNC machine instead.

In a mixed shop, laser cutting and CNC machining are not competitors. The laser produces the flat blank and the outer profile; the mill then adds the holes, pockets, and threads that need tolerance. This sequence is common for brackets, mounting plates, and enclosure panels where the outer shape is simple but the hole pattern is tight.

Tolerance is where the handoff matters. Laser cutting on thin sheet typically holds ±0.1 mm on the profile, and that is generous enough for most brackets. If a hole pattern needs ±0.005 mm, the laser cannot hold it. Drill and ream it on a CNC machine after the blank is cut.

Deburring is the hidden cost. Laser-cut edges have a small recast layer and sometimes a hard dross bead on the underside. On stainless and aluminum, a light bead blast or vibratory tumble removes it. On parts that will be anodized, the cut edge should be deburred first or the anodize will show a dark line along the cut face.

At GreatLight, laser-cut blanks feed the same quality system as machined parts. Incoming sheet is checked against the mill certificate, the blank is measured after cutting, and the finished part gets a final inspection before shipment. Reports are available on request.
