A sleeved card is not a card. You measure a card at 63 × 88 mm, you measure a double-sleeved card at roughly 67 × 92 mm, and you measure a stack of 100 of them at about 73 mm tall. Those three numbers plus clearance drive every other dimension in the part.

The usual failure is designing to the card and not to the sleeve. A box drawn at 64 mm internal width will hold a fresh single-sleeved deck and will jam once the sleeves take on moisture and the inner sleeve adds its own edge. Internal width of 70–72 mm and internal depth of 95–98 mm covers most double-sleeve setups.

Height is the number people get wrong most often. A 100-card double-sleeved stack measures 72–75 mm depending on sleeve brand and how hard you compress it. Plan for 80 mm of internal height, then add a 3–5 mm gap above the stack so the lid does not crush the top card.

If you also want a side compartment for tokens and dice, subtract that volume from the card channel rather than adding it to the outside. Keeping the outer footprint near 85 × 110 mm keeps the box inside most deck carrier pockets.

For FDM in PLA or PETG, a 2.0 mm wall is the practical floor for a box that gets carried. At 1.2 mm the walls flex enough that the lid fit changes after a few weeks of use. At 3.0 mm you add mass and print time without a real gain in stiffness.

Stiffness comes from geometry more than thickness. A 0.8 mm rib every 20 mm along the long walls raises the section modulus far more than doubling the wall. Ribs also hide layer lines on the outside face, which matters if the box is a display piece.

Print orientation decides strength. Laying the box on its long side puts layer lines perpendicular to the bending load, so the walls resist the squeeze of a full deck. Printing it upright is faster and needs less support, but the layer bonds run across the thin wall and split under load.

Nozzle size sets the detail ceiling. A 0.4 mm nozzle holds 0.2 mm layer height and clean 1.5 mm text. A 0.6 mm nozzle prints the same box in about half the time with slightly rounded corners on small features.

A printed lid needs clearance, and the clearance has to come from somewhere. On a well-tuned FDM printer, a 0.25–0.35 mm gap per side gives a lid that slides without rattling. Below 0.20 mm the two parts weld together at the seams. Above 0.5 mm the lid feels loose.

The gap is not constant across the part. Corners print slightly oversized because the nozzle slows down and over-extrudes. Holes print undersized by roughly half the nozzle diameter. If you model a 3 mm pin for a 3 mm hole, it will not fit.

Magnetic lids solve most of this. Two Ø6 × 3 mm neodymium magnets recessed 0.4 mm below the surface hold a lid with 0.4 mm clearance and no friction fit at all. Print the pockets 0.15 mm oversize and glue the magnets after the print, not during.

If you need a repeatable fit across many boxes, print a test coupon first. A 40 mm long rail with three clearance steps takes 12 minutes and tells you the real number for that printer, that filament and that day.

PLA is the default for a display box. It prints sharp, holds 0.2 mm detail and costs little. It also creeps under sustained load and softens near 60 °C, so a box left in a car will warp and the lid fit will change.

PETG is the better choice for a box that travels. It takes more impact before it cracks, tolerates higher temperatures and bonds well between layers. It strings more and prints slower, and it scratches to a dull finish rather than a gloss.

ABS and ASA give the best heat resistance of the common filaments and can be vapor smoothed for a molded look. They warp on large flat parts, so the box needs a closed chamber and a brim. ASA also holds up to UV if the box lives on a shelf near a window.

TPU is worth considering for the lid gasket only. A 1.5 mm TPU lip under the lid keeps dust out and adds a small amount of preload. Printing the whole box in TPU makes it too floppy to protect the deck.

FDM layer lines are 0.1–0.3 mm tall and you cannot print them away. Sanding a box flat takes time and rounds the edges you just modeled. Filler primer plus 400 and 800 grit gets a paintable surface, and it adds 0.1–0.2 mm to every face, which changes the lid fit.

Embossed text works better than engraved text on a printed box. Raised letters 0.6 mm tall and 1.5 mm wide survive handling; engraved letters fill with dust and disappear under a dark filament. Keep the minimum character height at 1.5 mm.

Inlays are the cleanest way to add color. Model a 1.6 mm deep pocket, pause the print at the right layer, and drop in a contrasting filament patch. The result is flush and does not need paint.

If the box is a gift or a product, resin printing gives a smooth surface at 0.05 mm layers, but only in small sizes. A full Commander box does not fit most resin build volumes, so resin suits the lid plate or a token tray instead.

Printing makes sense for one to fifty boxes, for designs that change often, and for anything with internal channels or lattice that a mill cannot reach. It also makes sense when the buyer wants to print it themselves.

A machined box makes sense when the part has to survive years of handling, when the lid must seat the same way on the 500th open, or when the box is a branded item with tight cosmetic requirements. Aluminum 6061 and 6061-T6 are the usual picks, with 304 or 316 stainless when corrosion matters.

The tolerance difference is the real one. FDM holds roughly ±0.2 mm on a good day and changes with humidity and filament batch. CNC machining holds ±0.005 mm and repeats it across a production run, so a magnetic lid and a hinge pin behave identically on every unit.

Surface finish follows the same split. Printed parts land near Ra 1.6–3.2 μm before finishing. Machined aluminum reaches Ra 0.8–1.6 μm as a standard finish and Ra 0.2–0.8 μm when the application needs it, then takes anodizing, laser engraving or bead blasting.

There is no minimum order quantity on the machining side, so a single prototype box is a normal job. Upload the STEP file and the DFM notes come back with the quote.
