GA CNC prototyping starts with a 3D model, not a mold. A CAM programmer pulls toolpaths from the STEP or IGES file, posts them to a machine, and a cutter removes material along those paths. Nothing is cast, pressed or printed, so the first part carries the same geometry as the tenth. That is the whole reason a machined prototype can be measured and trusted before any tooling money is spent.

The speed comes from skipping tooling. There is no electrode to burn, no mold base to order, no cooling layout to design. A prototype that would take weeks to cut steel for can be machined in days because the only setup work is fixturing and tool selection. This is also why design changes are cheap at this stage: edit the model, re-post the toolpath, cut again.

The precision comes from machine geometry and measurement, not from operator feel. A simultaneous 5-axis center holds the tool at a fixed angle to a contoured surface, so the cutter stays in its sweet spot instead of rubbing. On our machines the working tolerance is ±0.005 mm (±0.0002 in) on features that are reachable and stable. Features that are deep, thin or unsupported will move, and no machine can fix that.

Both claims depend on one thing: the part has to be machinable. A wall of 0.3 mm, a 12:1 deep pocket or an internal channel with no tool entry is not a speed problem. It is a geometry problem, and the fix belongs in the CAD file, not in the quote.

• 1
  File in, part outSTEP, IGES, STL, DWG, DXF or Parasolid all work as a starting point.
• 2
  No tooling costChanging the model between runs costs programming time only.
• 3
  Repeatable geometryThe tenth part matches the first because the path is identical.
• 4
  Machinability firstTool access decides the outcome more than machine count does.

Most of the calendar time on a prototype is not cutting. It is quoting, programming, fixturing and inspection. We return a quotation and a free DFM analysis within 12 hours, and production can start within 24 hours of the order, because those two steps are handled by the same engineer who will program the part. Splitting them across shifts is what makes other quotes slow.

Cutting time itself scales with material removal, not with part count. A 6061 bracket with light stock removal might run 20 minutes per cycle. The same bracket in 17-4PH stainless runs far longer at a third of the feed rate, and tool life drops. This is why the material choice on the drawing changes the delivery date more than the quantity does.

Setup count is the other lever. A part that can be reached from two sides on a 5-axis center needs two setups. A part that must be flipped four times needs four, and every flip adds alignment error and queue time. If your design can be reached in fewer orientations, say so in the RFQ notes, because it directly shortens the schedule.

Parts ship in 3–5 days once cutting starts. Historical late-delivery probability on these jobs is below 2%. We do not promise a date before the DFM review, because a part that needs redesign cannot honestly be scheduled.

• 1
  Quote and DFMWithin 12 hours, with specific notes on thin walls and tool access.
• 2
  Production startWithin 24 hours of order confirmation.
• 3
  Setup countFewer orientations means less alignment error and shorter lead time.
• 4
  Material effectHard alloys cut slower and wear tools faster than aluminium.

GA CNC prototyping is the right tool when the part must behave like the production part. If a housing has to survive a drop test, hold a bearing bore, or carry a thread under torque, only a machined part gives you an honest answer. Printed plastic can show you shape. It cannot show you how a 6061 or 316L version will deflect under load.

When the requirement is form and fit only, machining is often the expensive answer. A fit-check bracket in POM or ABS may cost less as a printed or vacuum-cast part, and you can iterate faster. The judgment call is simple: does the prototype have to carry a load, seal a fluid, or be inspected to a tolerance? If no, do not pay for metal.

Machining and casting are not competing on the same part. A die-cast housing needs a mold, and a mold needs a settled geometry. The practical order is machined prototype first, then vacuum casting or die casting once the design stops moving. Machining a handful of units to validate the design is normal; machining 10,000 units of a casting is not.

For metal prototypes in the 1 to 500 piece range, machining usually wins on total cost once you count tooling and the risk of a wrong tool. Below that it wins clearly. Above a few thousand pieces, casting takes over and the machined prototype becomes the reference sample for the foundry.

• 1
  Machine itLoad-bearing, sealing, threaded or tolerance-inspected parts.
• 2
  Print itForm and fit checks where stiffness and finish do not matter.
• 3
  Cast it laterOnce geometry is frozen and volume justifies a tool.

Corner radii are the first thing to check. An internal corner cut by an end mill carries the tool radius, so a 2 mm corner in the model becomes a 3 mm radius in metal if that is the smallest cutter that can reach the floor. Design the radius you can live with rather than discovering it at first article. External corners are free; internal ones are not.

Wall thickness follows the same logic. Thin floors vibrate under the cutter, and vibration shows up as chatter marks and a loose tolerance. For aluminium, walls under 0.8 mm need light finishing passes and often a support structure. For stainless and titanium, keep walls above 1.5 mm unless the part is short and fully supported.

Tapped holes and thread depth need clearance at the bottom. A blind M4 hole needs roughly 4 mm of thread plus a tap drill point, so specify a depth that leaves room. Threads can also be milled rather than tapped on a 5-axis center, which is how we handle threads near a contoured face where a tap cannot start square.

Surface finish is a cost dial. As-machined Ra 1.6–3.2 μm is standard. Ra 0.8–1.6 μm needs a finishing pass and adds cycle time. Ra 0.2–0.8 μm is a lapping or polishing operation and should only be specified on the faces that function, such as a seal land or a sliding bore.

• 1
  Internal cornersMatch the radius to the smallest cutter that can reach the floor.
• 2
  Thin wallsUnder 0.8 mm in aluminium needs light passes and support.
• 3
  Blind threadsLeave drill point clearance below the usable thread.
• 4
  Finish calloutsSpecify fine Ra only where the surface actually functions.
