OEM prototyping means the shop builds exactly what your file says. ODM prototyping means the supplier also owns part of the design decision. They may add a fillet where your corner will crack, thicken a boss so it survives the first drop test, or move a datum so the part can be held in a vise. The output is still your part. The difference is a marked-up model coming back with the quote.

That distinction changes what you should ask for. With an OEM shop, you specify and they comply. With an ODM partner, you hand over design intent and they propose geometry. Ask what they will change and why. A supplier who returns your file untouched is either very confident or not reading it closely.

The practical benefit shows up at the second revision. If the supplier already understands the assembly, they can suggest a gating change, a draft angle for a later cast, or a wall thickness that will survive injection molding. You avoid finding out at tooling that a 0.8 mm wall was never going to fill.

• 1
  Send intent, not just geometryNote which faces are cosmetic, which are datum, and where the part mates.
• 2
  Ask for the DFM markupA one-page annotated model is worth more than a paragraph of comments.
• 3
  Name the production process earlyA prototype designed for casting should not be optimized only for 3-axis milling.

Round-the-clock running is often sold as speed. The engineering reason to care is thermal. A machine that stops overnight cools, and the first parts of the morning shift come off a spindle that is still expanding. Continuous running keeps the spindle, ballscrews and fixturing at a steady temperature, so the tenth part holds the same dimension as the first.

This matters most on tight-tolerance features. On a 4,000 mm part, a few degrees of thermal drift moves the far end more than the tolerance band. A shop that runs through the night with in-machine probing and automated tool setting can hold ±0.005 mm on features that a day-shift-only shop would need to re-cut.

The second effect is queue behavior. When machines run 24/7, your job does not wait for a morning start. Production can begin within 24 hours of PO, and parts typically ship in 3–5 days. That is a scheduling fact, not a marketing promise, and it depends on the shop having the material in stock and the fixtures already proven.

• 1
  Ask how they handle thermal driftIn-machine probing and scheduled warm-up cycles are the usual answers.
• 2
  Check the night-shift staffing modelLights-out running needs tool monitoring, or a broken cutter ruins the batch.
• 3
  Confirm material is on the floorA 24/7 schedule means nothing if the 7075 block arrives on day three.

Most real prototypes are not one process. A typical assembly might need a 5-axis machined aluminum frame, a 3D-printed nylon latch, a sheet metal bracket, and a vacuum-cast cover with a color match. If four vendors make those four parts, you own the interface tolerances and the schedule risk.

Keeping the processes in one building removes the shipping time between operations and, more importantly, removes the argument about whose dimension is wrong. When the machined frame and the cast cover are made by the same team, the fit is their problem to solve before shipment, not yours to discover on the bench.

GreatLight runs a 7,600 m² campus in Dongguan with 127 high-precision CNC machines, including 16 simultaneous 5-axis machining centers, 12 four-axis mills, 27 three-axis machines and 16 mill-turn centers, alongside sheet metal, 3D printing, die casting, vacuum casting and surface finishing. One PO can cover the whole prototype build.

• 1
  Count your handoffsEvery vendor boundary is a place where tolerance and timing can be lost.
• 2
  Ask for the process planWhich operation runs first, and what datum carries through the sequence.
• 3
  Check finishing in houseAnodizing and powder coating affect fit; subcontracting them adds days.

Material selection for a prototype is not the same as for production. You may want 6061-T6 because it machines cleanly and holds a thread, or 7075 when the part is a stressed bracket and you need the strength now. Stainless 17-4PH in the H900 condition is common for medical and aerospace hardware where corrosion and yield both matter.

Finish changes dimensions. Hardcoat anodizing builds roughly half the coating thickness per surface, so a Ø10.00 mm bore can close up. Electroless nickel adds a more uniform layer and reaches into blind features better than anodizing. Powder coating is thicker and can bridge a tight gap, so mask mating faces or plan clearance.

For elastomer and cover parts, vacuum casting in polyurethane gives you a production-like surface without tooling. For brackets and enclosures, sheet metal is usually faster and cheaper than machining from billet. The right answer depends on which property you are testing: fit, stiffness, thermal path, or appearance.

• 1
  State the finish before quotingCoating thickness can consume your tolerance band on bores and shafts.
• 2
  Match the alloy to the test6061 for general work, 7075 for stress, 316L for corrosion and cleanability.
• 3
  Plan masking earlyThreads, datum faces and electrical contacts usually need to stay bare.

A certificate on a website tells you the company passed an audit. It does not tell you your part was made inside the audited scope. Ask which site and which processes the certificate covers, and whether the certificate is current. For automotive work, IATF 16949:2016 is the relevant one. For medical devices, ISO 13485:2016.

Inspection is the part you can verify directly. A shop that inspects 100% before shipment and can send dimensional reports gives you data for the design review instead of a pass or fail. Raw material certificates, in-process checks and a final inspection record form a chain you can trace if a dimension is questioned later.

Ask what happens when a dimension is out. The useful answer describes containment: the parts are held, the operator and setup are identified, and the cause is corrected before the next run. A vague answer usually means the shop found out about the problem from you.

• 1
  Verify scope, not just the logoConfirm the certificate covers the process and the plant making your part.
• 2
  Request the inspection reportEven a first-article report on key dimensions is worth having.
• 3
  Ask about nonconformance handlingA defined containment process is a better signal than a zero-defect claim.

Quoting speed is a proxy for how the shop works. If a quote and a DFM analysis come back within 12 hours, someone read the model and thought about the process. If it takes four days, the shop is likely batch-processing RFQs and your revision will wait in the same queue.

MOQ is the other term that shapes prototype economics. A no-minimum policy lets you order one piece, measure it, and change the design without paying for parts you will scrap. That matters most in the first two revisions, when the design is still moving. From one prototype to 10,000+ part runs is the range to look for.

Confidentiality should be settled before files move. A supplier that offers an NDA on request and treats uploads as confidential is normal for ODM work, because you are handing over design intent, not just a drawing. If the NDA discussion is awkward, that is information about the relationship.

• 1
  Time the quoteA 12-hour turnaround on quote and DFM sets the pace for every revision after.
• 2
  Confirm no MOQ in writingPrototype pricing should not carry a hidden batch minimum.
• 3
  Sign the NDA before the model goes outDesign intent is more sensitive than the finished drawing.
