  Printed versus machined radio mount: when each one wins

The radio is a sealed box of a few hundred grams. The mount does three jobs at once: it holds that box in a fixed position, it isolates the electronics from vibration coming through the frame, and it keeps the antenna connectors from carrying any load. When a bracket fails at a competition, it is rarely the material. It is the geometry.

Match-day loads are not gentle. A bumper hit sends a short, sharp acceleration through the frame, and the mount sees that load multiplied by the mass of the radio sitting on the end of it. The bracket also gets grabbed by pit crew, zip-tied to a belly pan, and stuffed next to a battery. Design for the grab, not just the hit.

The last job is the one teams forget. Cable strain relief belongs to the mount, not to the connector. If the radio can move 1 mm while the antenna cable stays fixed, that movement lands on a solder joint. A printed bracket with a tie-down loop solves a problem that no amount of filament tuning can fix later.

• 1
  Fixed positionThe radio must not shift under vibration or it will rub through its own harness.
• 2
  Vibration isolationShock loads and motor buzz both travel through rigid frame members.
• 3
  Zero load on connectorsAntenna and power joints should never see bending from bracket flex.

Filament choice sets the ceiling on what the bracket can do. PLA is stiff and cheap, but it creeps under sustained bolt preload and turns brittle in a cold venue. PETG is tougher and prints easily, yet it flexes more than most teams expect, so a tall bracket can wobble. Neither is wrong for a mock-up. Both are wrong for a part that holds a radio through a playoff run.

PA12 nylon, especially carbon-fiber filled grades, is the usual answer. It has good impact resistance, holds a thread reasonably well, and keeps stiffness at the temperatures a robot sees. The trade is moisture: nylon absorbs water from the air and grows slightly. Print it dry and store it dry, or your bolt holes will move between events.

TPU has one good use here, and it is not structural. A thin TPU pad or grommet between the radio case and the bracket damps high-frequency buzz that comes off drivetrain motors. Keep it as an isolator, not as the load-bearing body.

Metal printing is available and rarely justified for this part. Aluminum or titanium printed brackets cost far more per unit, and the radio does not need that strength. If you truly need metal stiffness in a small envelope, machined 6061-T6 is cheaper, tighter and available in days.

• 1
  PA12-CFBest default: stiff, impact tolerant, holds threads.
• 2
  PETGFine for prototypes and light brackets; flexes under load.
• 3
  TPUUse as a damping pad only, never as the main body.
• 4
  Machined 6061-T6Choose when stiffness and thread strength matter more than weight.

FDM parts are weak between layers. That single fact drives most of the design rules. A bracket printed flat on the bed has its layer lines running across the height, so a side load tries to peel the layers apart. Orient the part so the primary load runs along the extrusion direction, and the same material carries far more.

Ribs do the heavy lifting. A 3 mm rib standing 8 to 10 mm tall adds stiffness to a flat panel with almost no weight. Put ribs on the tension side of a bending panel, not the compression side, and taper them into the base so the load spreads instead of concentrating at a sharp corner.

Sharp internal corners are crack starters. Give every inside corner a fillet of at least 1.5 mm, and 3 mm where the bracket meets the chassis face. Bolt bosses need a wall thickness of at least 3 mm around the hole, plus a boss diameter of roughly 2.5 times the screw diameter, or the boss splits when you torque it.

Threads printed directly into plastic are a gamble. Use heat-set inserts for anything you will assemble more than twice, or design a through-hole with a nut pocket so the fastener clamps the plastic instead of cutting into it.

• 1
  Layer directionRun the main load along the extrusion path, not across layers.
• 2
  Rib height3 mm ribs, 8-10 mm tall, tapered into the base.
• 3
  FilletsMinimum 1.5 mm internal; 3 mm at the chassis joint.
• 4
  Boss sizingWall at least 3 mm; boss diameter about 2.5 × screw diameter.

Layer height is a trade between surface finish and strength. For a bracket, 0.2 mm layers are a good middle ground. Going to 0.1 mm doubles the print time and buys appearance, not strength. Walls matter more than infill: four to five perimeters at 0.4 mm give a shell that carries most of the bending load.

Infill above about 40 percent adds weight faster than it adds stiffness. A gyroid or cubic pattern at 30 to 40 percent, combined with thick walls and ribs, gives a stiffer part than 80 percent infill with thin walls. That is where the weight budget should go.

Bolt torque is where printed brackets actually die. A typical M3 screw in a heat-set insert in PA12 will strip somewhere past 0.6 N·m. Hand-tight plus a quarter turn is usually enough. Use a washer under the head so the load spreads and the plastic does not sink.

Clearance holes should run 0.2 to 0.3 mm over the nominal screw diameter. Print a test coupon first if the part is going on a robot you cannot rebuild quickly, especially on a machine with a worn nozzle.

The most common failure is a split bolt boss. It happens when the boss wall is too thin, the screw is over-torqued, or the layer lines run around the hole instead of along the boss axis. Thicken the wall to 3 mm minimum, add a fillet at the base, and switch to heat-set inserts.

The second is a cracked chassis flange. This is usually a sharp corner plus a load path that tries to peel layers apart. Reorient the part or add a gusset. A 2 mm gusset along the flange often fixes a failure that a thicker wall will not.

The third is a loosened mount after a few matches. The bracket is intact but the radio has shifted. That points at vibration, not strength. Add a TPU pad under the radio, check that the fasteners have washers, and consider a thread-locking compound on metal-to-metal joints.

The last one is antenna damage with no visible bracket damage. The connector saw bending because the cable was routed tight against a moving part. Strain relief is a design feature; route the cable with a service loop and tie it to the mount, not to the frame.

Printing is the right call for one-off brackets, complex internal ribs, and anything that will be redesigned three times before the first event. Setup cost is near zero, and a redesign costs a new file, not a new fixture.

Printing stops being the right call when the part is thin, flat and repeated. A flat plate with a few holes is faster and cheaper in sheet metal or on a 3-axis mill. The same goes for any bracket that must hold a thread under repeated assembly.

There is also a stiffness ceiling. If the radio must stay within a tight position band under shock, printed plastic will deflect more than aluminum at the same envelope. A machined 6061-T6 bracket at 4 to 5 mm wall thickness will be stiffer than any practical print.

For teams that want both, a hybrid works well. Print the complex geometry, then use a machined aluminum insert for the bolt bosses and the chassis interface. The insert takes the thread load; the print takes the shape.

• 1
  PrintOne-offs, organic ribs, parts still under redesign.
• 2
  MachineThin plates, repeated assembly, tight position tolerance.
• 3
  HybridPrinted body with a machined insert at the bolt interface.
