The first question is not how fast a supplier can cut, it is whether the shop owns the right machine for your part. A bracket with holes on four faces is a three-axis job. A housing with compound-angle ports and a curved sealing face needs five-axis work, or it needs two or three setups that each add tolerance stack-up. Ask which machine the quote is based on. If the answer is vague, the price is a guess.

Turning is a different constraint. Long shafts, bearing seats and threaded bosses are usually faster on a mill-turn center because the part never leaves the spindle. GreatLight runs 16 mill-turn centers alongside 16 simultaneous 5-axis machining centers, 12 four-axis mills and 27 three-axis machines, out of 127 CNC machines in total. That spread matters: a shop with only three-axis capacity will quote your five-axis part anyway, then farm it out.

Size sets the ceiling. Our largest travel is 4,000 × 400 × 150 mm for long parts, with 750 × 1,150 × 550 mm and 600 × 600 × 600 mm envelopes for mid-size work, and 500 × 500 × 450 mm for compact parts. A Ø400 mm rotary table covers round features that would otherwise need a second operation. If your part sits near the edge of a machine envelope, say so in the RFQ. Fixture clearance is where fast jobs turn slow.

Materials change the answer too. Aluminium 6061-T6 and 7075 cut cleanly at high feed rates. 17-4PH stainless and Ti-6Al-4V need lower speeds, more coolant and sharper tooling, so the same geometry can take two to three times longer. A supplier who quotes titanium at aluminium cycle times has either misread the drawing or plans to surprise you later.

• 1
  Send the 3D model and a 2D drawing with tolerancesSTEP plus PDF marked with datums and critical features.
• 2
  State the function of tight featuresA bearing seat and a cosmetic edge do not need the same tolerance.
• 3
  Flag hard materials at RFQ stageTitanium, Inconel and hardened tool steel change cycle time and tool life.

When suppliers quote fast custom CNC milling turning services, the number that matters is not shipping speed but elapsed time from PO to first article. Break it into four parts: programming and DFM, material procurement, machine time, and finishing plus inspection. A shop can only compress the parts it controls.

Programming is usually the first hidden delay. If a supplier needs two days to build toolpaths before the machine is booked, a three-day promise is really five. We return a quotation and a free DFM analysis within 12 hours, and production can start within 24 hours on standard materials. Parts then ship in 3–5 days. Those numbers only hold because programming, machining and finishing sit in the same building.

Material is the second delay. 6061 aluminium plate and 303 stainless bar are usually on the shelf. 7075 in a non-standard thickness, 17-4PH or Ti-6Al-4V may need ordering, and that alone can add a week. Ask whether the quoted material is in stock or on order. It is a fair question and it has a factual answer.

Finishing is where most schedules break. Anodizing, electroless nickel, powder coating and laser marking are separate process steps. If they leave the building, you inherit a truck schedule you cannot see. Ask for the finishing lead time separately from the machining lead time. When both are in the same quote, the vendor owns the risk.

• 1
  Ask for a start date, not just a ship dateMachine slot booking is the real commitment.
• 2
  Separate machining time from finishing timeTwo numbers expose outsourced steps.
• 3
  Check historical delivery, not promisesOur late-delivery probability has stayed below 2%.

Tolerance is not one number for the whole part. It is a per-feature agreement. A shop that quotes ±0.005 mm globally is either very confident or not reading the drawing. In practice, ±0.005 mm (±0.0002 in) is realistic on turned diameters, bored bores and ground faces held in a single setup, with stable temperature and a machine that is not thermally drifting.

Surface finish follows the same logic. As-machined surfaces land around Ra 1.6–3.2 μm and are fine for brackets, covers and internal frames. Ra 0.8–1.6 μm covers most sealing and sliding surfaces on milled or turned parts. Ra 0.2–0.8 μm is a lapping or fine-turning territory and should be reserved for bearing journals, hydraulic sealing faces and optical mounts. Specifying a fine finish everywhere raises cost without improving function.

The real risk is drift, not the first article. Aging spindles, worn tools and loose in-process checks produce samples that pass and production that wanders. This is why in-process monitoring matters more than a good first sample. We check raw material on receipt, monitor dimensions during the run and inspect before shipment, with reports on request. Our qualification rate has held at 99.99%.

Thin walls and long slender parts are the classic exceptions. A 0.8 mm aluminium wall will deflect under normal clamping pressure no matter how good the machine is. If your design has walls under 1 mm, flexible fins or long unsupported bores, say so early. The fix is often a process change, not a tighter tolerance.

• 1
  Mark only critical features with tight toleranceEverything else can run at general tolerance and cost less.
• 2
  Match finish to functionRa 3.2 μm for covers, Ra 0.8 μm for sealing faces.
• 3
  Warn about thin walls before quotingUnder 1 mm changes fixturing and cycle time.

Minimum order quantity is a signal about how a shop is organized. A supplier with a 500-piece minimum is set up for production runs and will price your five prototypes as an annoyance. A shop with no minimum order quantity is built around the opposite problem: one prototype this week, 10,000 parts next quarter. Both models are valid, but only one fits a development program that is still changing.

Certifications should be matched to your industry, not collected. ISO 9001:2015 covers general quality management and is the baseline. IATF 16949:2016 is what automotive and EV customers expect, and it brings traceability and change-control discipline. ISO 13485:2016 applies to medical device work. ISO 27001:2022 covers information security, which matters when you upload proprietary CAD files. If a supplier holds all four, the audit paperwork is already in place.

Confidentiality is a practical question, not a legal formality. Ask where files are stored, who can open them and how long they are retained. We sign NDAs on request and treat every upload as confidential. For unreleased products, an NDA before the RFQ is normal and costs nothing.

Finally, look at the commercial shape of the quote. A single lump sum hides where cost comes from. A quote broken into material, machine time, finishing and inspection lets you make real trade-offs, such as relaxing one tolerance or skipping a cosmetic finish to hit a budget target.

• 1
  No minimum order quantityFrom one prototype to 10,000+ part runs.
• 2
  Certification setISO 9001:2015, IATF 16949:2016, ISO 13485:2016, ISO 27001:2022.
• 3
  NDA available on requestSign before the RFQ for unreleased designs.

A typical custom part is not finished when the spindle stops. It may need bead blasting, anodizing, laser marking and a threaded insert pressed in place. Each step that leaves the building adds logistics time and a new point of failure. This is the single biggest difference between a supplier that is genuinely fast and one that is fast only on paper.

In-house finishing covers anodizing in clear, colour, hardcoat and conductive types; electroless nickel, zinc, silver and gold plating; powder coating and black oxide; bead blasting, tumbling, brushing and polishing; and laser marking with a minimum character height of 1.5 mm. The 1.5 mm limit is worth remembering: fine logos and dense data matrices below that size will not read reliably on a machined surface.

Assembly is the other handoff. Pressing bearings, installing inserts, gluing magnets or fitting O-rings is often done by the customer because no one quoted it. If the drawing shows a pressed component, ask whether assembly is included. It usually costs less to have it done where the parts are made than to open a second work order.

The test is simple. Ask the supplier to list which steps happen in their building and which are subcontracted, then ask for the lead time of each subcontracted step. If the answer is a single number for everything, you are not getting the breakdown you need.

• 1
  Ask which operations are subcontractedRequest separate lead times for each.
• 2
  Check laser marking limitsMinimum character height 1.5 mm for readable marks.
• 3
  Confirm whether assembly is quotedInserts, bearings and O-rings are easy to forget.
