  What a CNC honing machine actually does to a bore
• 2
  Why honing fixes roundness, taper and straightness at once
• 3
  Crosshatch angle and surface finish: the two numbers to specify
• 4
  Where CNC honing fits in a machining sequence
• 5
  When honing is the wrong call
• 6
  Honing against the other bore finishing methods

Honing is an abrasive process that works on a hole that already exists. A mandrel carries bonded abrasive stones, expands them against the bore wall under controlled pressure, and rotates while stroking in and out. The stones cut a crosshatch pattern instead of a single-direction scratch. That crosshatch is the reason honing exists: it holds oil, it keeps a piston or shaft supported, and it does not leave a lead-in scratch path for wear to follow.

The important word in that description is controlled. Manual honing depends on an operator feeling the stone load and adjusting by hand. A CNC honing machine replaces that feel with a servo axis and a pressure or feed schedule. Stroke length, stone pressure, spindle speed and coolant flow all come off a program, so run 200 looks like run 1. That repeatability is what shops sell when they talk about honing, not the mirror finish.

Stock removal is small by design. Most jobs leave 0.02–0.10 mm of radial stock for the hone, and hard materials sit at the low end. Take too much and the stones load, the bore bell-mouths, and heat builds where you cannot see it. Think of honing as a geometry correction step, not a substitute for a boring bar that left 0.5 mm behind.

A boring bar cuts on one side of the hole and pushes the tool away from the cut. The result is a bore that is round enough to measure but not round enough to seal. Boring also inherits errors from the spindle, the setup and the material's residual stress. Drill a hole in 4140 and the stress releases unevenly, so the hole grows out of round after the tool leaves.

Honing attacks that error from every angle. Two opposed stones contact the wall at the same time, and the floating mandrel follows the existing hole instead of forcing a new centerline. High spots see more stone pressure and cut first. Low spots see less and cut last. The bore self-corrects toward round, and the correction happens along the full stroke length, not just at one depth.

That is why a honed bore can hold ±0.005 mm on diameter and still show a roundness value better than the boring machine that made it. The hone does not need a stiffer machine. It needs a bore that is close enough for the stones to reach.

Taper and straightness come along for the same ride. If the bore is tighter at the top than the bottom, the stones dwell longer where the wall pushes back. Stroke length and over-travel decide how much of that correction you get. Too little over-travel and the ends stay bell-mouthed. Too much and the stones flare the exits.

The crosshatch angle is set by the ratio of spindle speed to stroke speed. A 45° included angle is a common starting point for hydraulic cylinders and engine cylinders because it balances oil retention against load capacity. Shallower angles, around 30°, hold more oil and suit low-speed sliding contact. Steeper angles near 60° bleed oil faster and suit high surface speeds.

Ask for a crosshatch angle without specifying the finish and you get a guess. The two are linked. Coarse stones at high pressure cut deeper valleys and leave Ra 1.6–3.2 μm. Finer stones, lower pressure and a short spark-out pass bring the same bore to Ra 0.2–0.8 μm. GreatLight works to Ra 0.8–1.6 μm as a standard honed range and goes finer on request.

Plateau honing is the third option and often the right one. A rough pass cuts the deep valleys, then a fine pass knocks the peaks flat while leaving the valleys intact. The result is a surface that looks smooth to a profilometer but still holds oil. Cylinder liners, hydraulic valve bores and pneumatic actuators all benefit. A pure polish would remove the valleys and the part would scuff.

Do not chase a single Ra number. A bore at Ra 0.4 μm with no crosshatch can wear faster than one at Ra 1.2 μm with a proper 45° pattern. Grease and oil need somewhere to sit.

Honing sits at the end of the bore sequence, after drilling, boring and any heat treatment. It is a finishing step, so every operation before it should already be close. A typical route for a hydraulic cylinder is drill, rough bore, stress relief, finish bore to 0.05 mm of final size, then hone. The hone removes the last 0.02–0.05 mm and corrects what the boring bar could not.

Hardened parts change the picture. After induction hardening or nitriding, the bore may distort 0.01–0.03 mm and a reamer will not touch it. Cubic boron nitride or diamond stones cut through 58–62 HRC without softening the case, which is why honing is the standard finish for hardened hydraulic bores, gear bores and gun barrels.

Long bores favour honing more than short ones. A 4,000 mm bore cannot be reamed reliably, and a boring bar will deflect over that length. A honing mandrel with a long stroke follows the existing hole and corrects straightness as it goes. GreatLight machines bores up to 4,000 mm on the large travels and uses a Ø400 mm rotary table when the bore axis has to be indexed.

Cross-drilled holes, keyways and ports interrupt the bore wall and give the stones somewhere to catch. Deburr those features before honing. A stone that snags an edge chips, and a chipped stone scores the rest of the bore.

Honing is slow and it needs a hole to start from. A part with no bore, or a bore that is still 0.5 mm undersize, should go back to the boring bar first. Sending it to the hone wastes cycle time and wears stones.

Blind bores with a tight corner radius are difficult. The stones need over-travel at both ends of the stroke to correct the geometry, and a blind bottom gives them nothing. A short blind bore can be honed, but expect the last few millimetres to stay out of round. A bored or jig-ground bore often serves better there.

Thin-wall parts are another limit. A tube with a 1 mm wall will flex under stone pressure and the hone will chase the flex instead of cutting. The bore ends up lobed. Support the outside, reduce pressure, or pick another process.

Soft, gummy materials such as pure aluminium and some plastics load the stones and smear instead of cutting. They can be honed with the right abrasive and plenty of coolant, but a reamed or roller-burnished bore is usually cheaper. Honing earns its cost on hard, high-value, close-tolerance bores. Elsewhere, it is a luxury.
