A CNC automatic part is machined from bar stock on a machine that feeds, indexes and cuts without an operator loading each piece. The bar goes into a guide channel, the spindle moves along the Z axis, and the tools work close to the bushing that supports the stock. That is the whole idea: the workpiece stays supported right where the cutting force lands.

This is different from a machining center, where a vise or fixture holds a sawn blank and the tool travels around it. On an automatic lathe the tool rarely moves far in Z. The spindle does the traveling. Tools sit in fixed positions around the guide bushing and get selected by rotation or by a slide.

Practically, this means automatic parts are long and round relative to their diameter. Shafts, pins, bushings, nozzles, connectors, sensor housings, small valve bodies, implant screws and drive components all fit the pattern. The bar diameter sets the starting envelope, and everything else is cut away from it.

The name comes from the cam-controlled screw machines that ran these parts before CNC existed. Modern versions replace cams with servo axes, add a sub-spindle for back-working, and can carry live tools for milling flats, slots and cross holes. The kinematic idea is unchanged.

• 1
  Guide-bushing machinesBar slides through a carbide bushing; best for slender parts and tight diameter control.
• 2
  Chucker-style machinesNo bushing; the part is held in a collet. Better for short, stiff parts and larger diameters.
• 3
  Mill-turn centersAdds a B axis or a second turret with live tooling; covers features a pure lathe cannot reach.

Tolerance on an automatic part is the sum of several errors: thermal growth of the spindle and ballscrews, tool wear, material springback, and how far the cut sits from the support point. On a guide-bushing machine, the last term is small. The bar is held a few millimeters from the tool, so the bending moment is limited even when you turn a 3 mm diameter on a 6 mm bar.

On a chucker, the same 3 mm diameter might be 40 mm out from the collet. Cutting force bends it, the tool pushes it away, and the resulting diameter drifts. That is why slender work moves to a sliding-head machine and stubby work stays on a chucker. It is a deflection argument, not a preference.

Achievable tolerance depends on the feature. A turned outside diameter on a stable setup can hold ±0.005 mm and reach Ra 0.2–0.8 μm with a fine finishing pass. A cross-drilled hole is looser, often ±0.05 mm on position, because the drill is long and the entry surface is curved. Bore roundness on a bored hole typically lands between the two.

Thermal control matters more than most people expect. A spindle running for hours will grow. Shops that hold tight tolerance let machines warm up, keep coolant temperature stable, and check the first article against a known master rather than trusting the last setup. We run raw material checks, in-process monitoring and a final inspection, with reports available on request.

• 1
  Turned OD / IDTightest band; ±0.005 mm is realistic on short, supported lengths.
• 2
  Ground or hard-turned surfacesUsed when the material is above 45 HRC or the finish spec is below Ra 0.2 μm.
• 3
  Cross-drilled featuresPosition tolerance widens; plan for ±0.05 mm unless you add a second op.

Start with the turned profile. Steps, grooves, tapers, radii, threads and face features all come off the main spindle and sub-spindle with no extra setup. If the part is mostly a revolved shape, an automatic lathe is usually the cheapest route per piece, especially once quantity passes a few hundred.

Then look at what leaves the axis. A single cross hole is fine. Four cross holes at 90° need either a C axis with live tooling or an indexing sub-spindle, and both eat cycle time. A slot that runs along the side of a shaft is harder still, because the tool has to reach past the guide bushing without hitting it.

Features on both ends are the strong point. The sub-spindle picks up the part, cuts the back face, and drops it. No second operation, no re-fixturing error, no queue. Parts that need a tight concentricity between a front bore and a back bore benefit the most, because both are cut in one cycle on the same machine.

What you should not force onto an automatic lathe: large flat surfaces, deep pockets off-axis, and anything needing a 5-axis contour on a big body. If more than about a third of the machining time is milling on faces the lathe cannot reach, the part belongs on a 5-axis center instead.

• 1
  Good fitShafts, pins, spacers, nozzles, fittings, small housings, threaded studs.
• 2
  Possible with live toolingFlats, hexes, single cross holes, shallow slots, laser-marked IDs.
• 3
  Poor fitWide flat plates, deep off-axis pockets, parts above bar capacity.

Free-machining grades exist for a reason. Stainless 303 and 416 cut cleanly on an automatic lathe and give good chip control. Stainless 304 and 316 work too but tend to work-harden if the feed is too light, so the shop has to keep the tool engaged and the surface speed up. Aluminum 6061, 2024 and 7075 run fast and hold tolerance well.

Brass and copper alloys such as C36000 and C110 are close to ideal: low cutting force, little built-up edge, easy chip evacuation. Beryllium copper needs dust control, which changes how the shop handles chips and coolant. Titanium TC4 and Inconel 718 are machinable but slow, and the tool wear rate means the tolerance band should be checked more often.

Plastics are a different problem. POM and PA hold tolerance reasonably, PEEK is stable but abrasive, and ABS or PP will move after machining because of internal stress. If the part is plastic and slender, the guide bushing helps, but thermal drift between the cut and the measurement can exceed the tolerance you asked for.

Finishing follows the usual routes. Anodizing, electroless nickel, zinc, black oxide, bead blasting, tumbling and laser marking all apply to automatic parts. Laser marking needs a minimum character height of 1.5 mm to stay legible after plating, so plan the marking area on the print before the first article.

• 1
  Easy6061-T6, 303, C36000, C110; good chip control at moderate speeds.
• 2
  Watch the feed304, 316L, 17-4PH; light cuts work-harden the surface.
• 3
  Slow and costlyTC4, Inconel 718; expect more tool changes and more inspection.

The first limit is bar capacity. If the finished part is much larger than Ø32 mm, you are cutting away most of the stock and paying for chips. A mill-turn center with a Ø400 mm rotary table or a 3-axis machine with a 4,000 mm travel envelope will do the job with less waste.

The second limit is feature distribution. Automatic lathes win when the work is concentrated around one axis. If the part needs five-sided access, deep pockets, or a contoured surface that only a ball-nose tool on a tilting head can reach, the setup cost on the lathe climbs past the benefit. Move it early rather than after two failed first articles.

The third limit is quantity versus geometry. For one prototype, the bar feed and guide bushing still work, and there is no minimum order quantity here, so a single piece is fine. But if the geometry is simple and the quantity is one or two, a 3-axis mill with a vise may be faster to set up. The automatic route pays back on repeat work.

A useful rule: if the part is round, under Ø32 mm, and longer than about four times its diameter, ask for the automatic lathe. If it is round but stubby, ask for a chucker. If it is not round at all, ask for a mill.

• 1
  Keep it automaticSlender, round, one dominant axis, repeat quantity.
• 2
  Switch to mill-turnStubby part, several cross features, larger diameter.
• 3
  Switch to 5-axisContoured faces, deep pockets, non-round envelope.
