7 3D Printing Mistakes to Avoid for Cost-Effective Parts

Support material is the quiet cost center. In FDM, a 60° overhang can force support under most of the part and add hours of print time plus manual removal. In metal powder bed fusion, an unsupported ledge may survive one build and crash the recoater on the next. Either way, the geometry cost money before the part existed.

Sharp internal corners are a second tax. They concentrate residual stress during cooling and show up as warp on flat plates or cracks at fillets. A 0.5 mm corner radius is usually free to add and removes both problems. Ask for a DFM review before the file is sliced, not after the first build fails.

Blind holes that trap powder or resin are the third trap. A printed cavity with no escape path needs secondary drilling, and drilling a printed wall often breaks through. Orient the hole, add a drain, or plan the feature as a machined op from the start. A part that needs three processes is rarely the cheap one.

As-printed tolerance on FDM sits around ±0.5% of the dimension, and often worse on the Z axis. SLA and SLM hold tighter, but ±0.1 mm across a 300 mm build is still a normal day, not a guarantee. Writing ±0.05 mm on a printed drawing does not make the machine hold it. It makes the supplier quote a secondary operation.

The practical rule: tolerance only the features that mate. A bearing bore, a dowel hole, a sealing face and a connector pocket deserve a number. Cosmetic surfaces, cable channels and clearance holes do not. Every tight callout adds inspection time, scrap risk and sometimes a reaming step.

When a printed feature truly needs ±0.005 mm, plan to machine it after printing. That hybrid route is often cheaper than fighting the printer. Print the near-net shape, then face and bore the critical interfaces on a CNC. The additive step handles the complex geometry, the subtractive step handles the precision.

PLA is cheap and stiff until it sits in a warm car. ABS and ASA take impact and heat better but warp on large flat sections. Nylon is tough and chemical resistant, yet it absorbs moisture and grows over weeks. None of these are wrong choices. They are wrong when the load case, temperature and environment were never written down.

For functional prototypes, match three numbers to the application: continuous service temperature, tensile strength and elongation at break. A UV-exposed outdoor bracket, a 90 °C under-hood cover and a food-contact fixture do not share a material. When the part also carries load or sees fatigue cycles, the printed polymer is usually a stand-in.

Metal printing raises the same question at higher cost. Ti-6Al-4V and Inconel 718 print well but need stress relief and often HIP, plus support removal and surface finishing. For a one-off bracket, machining 6061-T6 or 7075 from bar is faster and cheaper. Printing wins on internal channels and lattice geometry that a cutter cannot reach.

The print quote rarely includes the finish. Support removal, sanding, bead blasting, dyeing, vapor smoothing and curing are separate line items, and on some parts they cost more than the build. Aesthetic surfaces are the worst case. Layer lines must be removed by hand, and hand work scales with surface area, not part count.

Threaded inserts, helicoils, tapped holes and press fits all land in this category. Printing a hole and tapping it works in some polymers, but the thread is weaker than a machined one. For anything that gets assembled more than twice, design a pocket for a heat-set insert or plan a machined thread.

Ask for the finished-part price, not the print price. That single change of question exposes the real gap between two suppliers. If one quote is 30% lower on printing and the finishing is missing, it is not a lower quote. It is an incomplete one.

Printing does not get much cheaper per part with volume. Machine time, support and post-processing stay roughly constant, so a run of 200 printed brackets costs about 200 times a run of one. Injection molding, die casting or CNC turning break that line. The crossover usually sits somewhere between 20 and 100 parts, and it moves with part size and finish.

Build volume is the other hard wall. A part that exceeds the chamber must be split, pinned and bonded, which adds a joint, a fixture and a failure mode. Metal printers are stricter still: a tall thin part may need a build plate anchor or it will warp off the substrate.

Both mistakes have the same fix. Check the part envelope against the real machine travel before you commit, and model the split if one is needed. If the part is larger than 300 mm and needs a tight bore, a CNC route on a 4,000 mm machine removes the joint entirely.

A printer is easy to buy. A documented process is not. Ask what happens when a build fails, how material lot traceability is recorded, and whether inspection reports travel with the parts. Suppliers with a real system answer in specifics. Others answer with adjectives.

For regulated work the certificates matter. ISO 9001:2015 covers general quality management, IATF 16949:2016 covers automotive, ISO 13485:2016 covers medical devices, and ISO 27001:2022 covers information security for your files. A supplier holding all four has been audited on process, not just on output.

Incoming material checks, in-process monitoring and a final inspection before shipment are the three gates that catch most escapes. Request the reports with the first order, not the tenth. If the data is not available on a small order, it will not appear on a large one.
