Laser powder bed fusion is the process most people mean by metal 3D printing. A recoater spreads alloy powder 20–50 μm thick across a build plate, a laser traces the slice, the plate drops one layer, and the cycle repeats. The part grows inside a bed of loose powder, not on a machined face.

That single fact explains most of the behavior engineers care about. Support is only needed where heat has nowhere to go, not everywhere. Undercuts cost nothing. Internal channels that a 6 mm end mill could never reach can be printed in one piece.

The trade is surface and residual stress. As-printed walls come out at Ra 8–15 μm with a staircase on sloped faces, and rapid cooling leaves stress locked into the part. A 40 mm tall bracket can bow 0.2–0.5 mm after it is cut off the plate.

So the printed blank is rarely the finished part. Most functional GT3 hardware gets printed near-net and then machined on the datums that matter. That two-step route is where the real cost sits, and it is the subject of the rest of this page.

Printing wins where the geometry is the problem. A charge pipe with a 3D bend, an airbox plenum with a tuned internal volume, a brake cooling duct that has to snake around a control arm. These are single-piece parts in AM and multi-piece weldments in sheet metal.

Printing also wins on low counts. One-off aero trim for a track car, a restoration bracket for a car whose part number is long dead, a jig that holds a subframe during welding. No tooling, no minimum order quantity, and the file can change between builds at no cost.

Printing loses where the part is a surface. Pistons, cylinders, brake rotors, cam covers with a gasket face, anything that has to seal, slide or spin against another body. Those need Ra 0.2–0.8 μm and a flatness you can measure on a granite plate, which is milling and turning work.

The hard cases sit in the middle. A printed titanium upright is light, but you must prove the internal porosity is below the acceptance limit your series requires. Without CT or destructive sectioning, that claim is a guess. For safety-critical suspension and brake hardware, machined 6061-T6 or 7075 is the defensible answer.

A few numbers govern whether a file prints cleanly. Minimum wall thickness runs 0.4–0.5 mm for a stable wall in aluminum, thicker in titanium. Smallest hole diameter is around 0.4 mm, and holes below 1 mm usually need drilling afterwards to hold a tolerance.

Overhangs are the usual failure point. Anything past 45° from the build plate needs support, and support leaves witness marks on the mating face. Rotate the part instead. Reorienting a bracket so its flange sits flat often removes the need for support entirely.

Trapped powder is the quiet problem. A closed internal cavity with no escape hole holds powder that you cannot clean, and it will show up as loose material in service. Add 2–3 mm drain holes at the lowest points of any sealed volume.

Shrinkage is predictable but not uniform. Aluminum alloys pull roughly 1–2% overall, and thin sections pull differently from thick ones. Scale the model, then leave 0.3–0.5 mm on any surface that will be machined so the finishing pass has something to cut.

The first step after a build is not machining. It is stress relief. A 2-hour anneal at 300 °C for aluminum, or a full HIP cycle for titanium, drops the residual stress before the part is wire-cut from the plate. Skip this and the part moves after cutting.

Support removal comes next, by hand tool or wire EDM. Do not cut supports off with a grinder on any face that will be a datum. The heat and the gouge both cost you the reference.

Then the part goes on a 5-axis center. Flanges get faced, bores get reamed to H7, threaded holes get tapped. On our 16 simultaneous 5-axis machining centers, a printed blank is held on a custom fixture and located from the printed datum pads left in the design for exactly this purpose.

The final operation is usually finishing. Anodizing, bead blasting or polishing brings the as-printed skin to the look the rest of the engine bay has. Laser marking handles part numbers, with a minimum character height of 1.5 mm so the mark stays readable after coating.
