A broken tool detection cycle answers one question: is the tool that the program expects still there, and is it the right length? It does not measure wear, and it does not check surface finish. It is a presence-and-integrity check that runs between operations, usually after a retract and before the next tool change or the next cutting pass.

The classic failure it prevents is a snapped drill, tap, or end mill left inside a pocket or a deep bore. If the control keeps cutting with a missing tool, the next tool may enter an empty hole, rub instead of cut, or crash into the stub still clamped in the holder. On a part that already carries 40 minutes of machining, that is a total loss.

Detection happens at the machine level, not in the CAM system. The CAM file only says which tool to call. The machine decides whether that tool is real, using a sensor, a probe, or the spindle drive itself. That distinction matters when you compare methods, because each one sees a different physical property.

Touch probe and tool setter. The tool is moved down onto a hardened pad or against a stylus, and the control records the contact position. If the recorded length differs from the stored offset by more than a set limit, the cycle stops. Typical repeatability on a good tool setter is around ±0.002 mm to ±0.005 mm, which is enough to catch a missing 0.5 mm drill but not enough to judge edge chipping.

Laser tool breakage systems. A beam crosses the tool path at a known height. The tool interrupts the beam, and the control compares the break-through point with the stored length and diameter. Because there is no contact, the tool can spin during the check, so the system sees the full flute envelope. This is the method of choice when you run small-diameter tools or when you cannot afford to scratch a coated edge.

Spindle load and power monitoring. The drive current is sampled fast, often every few milliseconds. A broken tool usually shows up as a sudden drop in load, followed by a rise as the remaining shank rubs. The method needs no hardware inside the work envelope, which is why it is common on lathes and on older mills. The catch is that it sees the sum of all cutting forces, so a light finishing pass may not produce a clear signature.

Air pressure and coolant flow. In through-spindle coolant, a broken tool changes the flow rate and the pressure at the pump. A drop below a set threshold trips an alarm. This is a cheap add-on for deep-hole drilling, where a lost drill is hard to see and easy to leave behind.

Put the check where the cost of missing a break is highest. For a long roughing pass with an expensive casting underneath, check before the pass, not after. For a tap that runs at the end of a cycle, check right after the tap retracts, because a broken tap left in a blind hole will scrap the part on the next operation and may damage the rework tooling too.

The second placement rule is frequency. Checking every tool on every cycle adds non-cutting time. On a 200-part run with a 6-second check per tool and 8 tools, that is 96 seconds per part, which can exceed the cutting time on simple parts. Most shops check critical tools every cycle and non-critical tools every N parts, or only after a tool-life counter expires.

A third rule is the retract position. The tool must clear the part and any fixture before the check runs. If the check happens too close to the work, a long tool may sweep the probe or the laser housing. This is a programming detail, but it is the most common reason a detection cycle gives false alarms on the first run.

• 1
  Check before the expensive cutIf the material is costly, verify the tool before it touches the part.
• 2
  Check after the retractGive the tool enough clearance so the sensor sees the full length.
• 3
  Tier your toolsCritical tools every cycle, others on a counter.

Broken tool detection is a binary check, not a condition monitor. It will not tell you that a 6 mm end mill has worn 0.03 mm on the flank and is about to chatter. It will not catch a chipped corner that still has most of its length. For those problems you need in-process measurement of the part, or periodic tool-life data from the spindle load trend.

There is also a real false-alarm cost. A tool setter that is contaminated with chips will read short, trip the alarm, and stop a lights-out run at 3 a.m. Shops that run unattended usually add an air blast before the check and a confirmation pass, which catches the dirty-pad case without stopping the cycle.

Finally, detection adds cycle time and a small amount of risk. If the sensor itself is damaged by a crash or a chip, it can pass a broken tool. That is why the check is usually paired with a spindle load limit and a tool-life counter, so no single sensor is the only guard. On a 5-axis machine with a rotary table, the check must also be written for the rotary position, or the probe may not be where the program expects it.
