A crystal slipper is a display or costume prop shaped like a shoe, with faceted stones set into the upper. It is not a wearable shoe. If you want a real shoe last, that is a different job with different tolerances. Here we machine a rigid shell: sole, arch, heel, toe opening, and a faceted upper that accepts glass or cubic zirconia stones.

The reason to do it on a CNC instead of by hand is repeatability. A pair must be mirror images, and the left and right uppers must sit at the same height above the floor. On a 5-axis machine we can hold the mirror relationship to a few hundredths of a millimeter. Carving two identical shells by hand takes days and they still drift.

Typical parts we see are 180–260 mm long, 60–90 mm wide, and 70–120 mm tall. That fits inside a 500 × 500 × 450 mm travel envelope with room for the fixture, so a compact 5-axis center is enough. Long display versions up to 4,000 mm are possible, but the toolpath strategy changes completely.

One more point on scope. If the slipper is going on a stage or a shop window, impact resistance matters more than optical clarity. If it sits in a museum case, clarity and facet sharpness win. Decide that before you buy material, because it drives every later choice.

• 1
  Display propRigid shell, stones set in pockets, no flex expected.
• 2
  Wearable lastDifferent geometry, needs shoe-last tooling, not covered here.
• 3
  Scale modelSame approach, scaled down, tighter tool reach limits.

Aluminium 6061-T6 is the default. It machines cleanly at 3,000–8,000 rpm with carbide tooling, holds Ra 0.8–1.6 μm after finishing, and takes clear anodizing or hardcoat. The anodized layer gives a cool silver look that reads as glass from a few metres away. If the part must be lighter, 7075 offers higher strength at the same wall thickness, but it is less forgiving of poor chip evacuation.

Transparent plastics are tempting and usually a mistake. PMMA and PC do transmit light, but they scratch fast, and a 1.5 mm acrylic shell deflects under its own weight at 200 mm span. If you want a see-through prototype for a client review, cut it in PMMA, show it, then cut the production piece in aluminium.

For a warm metallic look, brass C36000 and copper C110 machine well and polish to a mirror. Both are heavy. A 220 mm brass slipper can weigh 1.8 kg, which matters if it hangs on a display arm. Titanium TC4 is the other extreme: light, strong, and it takes a bright anodized colour, but cutting speed drops and tool wear climbs.

Stainless 304 and 17-4PH are the choice when the slipper lives outdoors or gets handled constantly. They polish to a hard shine that resists fingerprints better than aluminium, at roughly triple the cycle time. Budget the extra machine hours before you commit.

• 1
  6061-T6Best balance of finish, weight and cost for most builds.
• 2
  7075Stronger, lighter, harder to chip-clear in deep pockets.
• 3
  C36000 brassMirror polish, heavy, good for small display pieces.
• 4
  TC4 titaniumLight and tough, slow to cut, needs sharp tooling.

The upper is a curved surface with stone pockets. Two dimensions control everything else: the arch height and the wall thickness. Set arch height first, because it fixes where the toe opening lands and how the sole sits flat on the table. A 0.2 mm error in arch height shows up as a visible tilt when the pair sits side by side.

Wall thickness on the upper should run 1.5–2.5 mm. At 1.5 mm a 6061 shell is stiff enough to hold shape during polishing. Below 1.2 mm the wall flexes, and any polishing pressure leaves ripples that catch light badly. If the design demands a thin rim at the toe opening, taper the wall instead of thinning the whole upper.

Sole flatness is the other call. Hold it within 0.05 mm across the full length so the piece sits without rocking. On a 220 mm slipper that is well inside what a 5-axis center holds, but it only works if the fixture supports the underside during the finishing pass.

General tolerances of ±0.005 mm are available, but do not call them everywhere. Stone pockets need ±0.02 mm to keep the setting consistent. Outer cosmetic surfaces are fine at ±0.1 mm. Over-tolerancing cosmetic geometry adds inspection time and buys nothing.

• 1
  Arch heightSet first; drives toe opening and sole contact.
• 2
  Wall 1.5–2.5 mmStiff enough to polish without ripples.
• 3
  Sole flatness 0.05 mmStops the pair from rocking on a display base.
• 4
  Pockets ±0.02 mmKeeps stone depth even across the upper.

Finishing order matters more than the finish itself. Machine, deburr, polish or anodize, then set stones. Every step after polishing must be gentle. Bead blasting the whole part is fine if the pockets are masked; blasting an unmasked pocket rounds the rim and the stone sits loose.

For a glass-like look on aluminium, go to hardcoat anodizing after a two-stage polish. First stage: 400–600 grit abrasive to remove tool marks. Second stage: cloth wheel with fine compound to bring the surface to a near-mirror. Hardcoat then adds 25–50 μm of clear, hard oxide that resists handling marks.

Brass and copper skip anodizing. Polish them to mirror, then apply a clear lacquer if the piece will be touched. Without lacquer, brass darkens within weeks in a humid room. Lacquer also softens the facet edges slightly, so keep the coat thin.

Stones are set with UV-cure adhesive, one pocket at a time, working from the heel forward. Wipe excess adhesive before curing, not after. If a stone sits low, do not push it deeper; pull it, clean the pocket, and reset. Forcing it chips the chamfer and the damage is visible under any light.

• 1
  Mask pocketsBefore bead blasting or powder coating.
• 2
  Two-stage polishAbrasive first, cloth wheel second.
• 3
  Hardcoat 25–50 μmClear, hard, resists fingerprints.
• 4
  Set from heel forwardEasier access and less adhesive smearing.
