A router is a moving gantry carrying a spinning tool over a fixed bed. Vevor builds that concept at low cost: aluminium extrusion or light steel tube for the frame, V-slot wheels or small linear rails for the axes, a trim-router or air-cooled spindle for the cutting head. The structure is the machine. Everything else is electronics bolted to it.

Cutting force pushes back on the tool. That force travels through the gantry into the frame and finally into the table. A bolted assembly with thin wall tube bends a little under every pass. The bend does not show up when you jog the machine empty. It shows up in the finished part as taper, chatter marks and a depth that drifts from one end of the bed to the other.

Mass helps here. Cast iron and welded steel frames absorb vibration because they are heavy and stiff. A hobby router trades that mass for price and shipping weight. That trade is reasonable for signage and furniture parts. It becomes a problem when the drawing calls for a bore that must fit a bearing.

So the first question is not which model is bigger. The first question is which material and which tolerance the part needs. That answer decides whether a router is the right machine at all.

Most Vevor routers use open-loop stepper motors driven by a GRBL-compatible board. The controller counts pulses and assumes the motor moved exactly that far. If the tool bites too deep and the motor stalls, the controller never notices. The rest of the job is then cut in the wrong place.

That is why depth of cut matters more than feed rate on a light machine. A typical rule for a hobby router in softwood is 1–2 mm per pass with a 6 mm two-flute cutter, at 8,000–12,000 rpm. Push to 4 mm in one pass and you may hear the stepper skip. The sound is a sharp knock, not a smooth cut.

GRBL also limits how the tool path is executed. It handles arcs and linear moves well, which suits 2.5D pockets, profiles and drilling. Complex 3D surfacing needs a huge number of short segments, and the board can choke on the data rate. The result is stuttering motion and a rough surface on curved forms.

Closed-loop motors and industrial controllers solve this. They cost several times more. For a first router, the practical approach is to keep tool paths simple and accept that curved surfaces will need sanding.

Spindle power is usually quoted in watts. A 500 W trim router is a hand tool bolted to a plate. It has enough torque for wood, MDF, acrylic and foam, and it will cut aluminium if you go slowly with a single-flute cutter and a lubricant. It will not cut steel, and it will not cut stainless at all.

A 1.5 kW to 2.2 kW air-cooled spindle changes the picture for aluminium. The extra torque lets you take 0.5–1 mm radial cuts at 12,000–18,000 rpm with a 6 mm single-flute end mill, with a light mist of cutting fluid. Chip evacuation becomes the bottleneck rather than power. Aluminium chips weld to the cutter if they sit in the slot.

Collet size sets the tool shank you can hold. An ER11 collet tops out at 7 mm, an ER16 at 10 mm, an ER20 at 13 mm. Larger shanks are stiffer and deflect less, which matters on deep pockets. If the machine only takes 6 mm shanks, plan your tool paths around that.

Spindle runout is the hidden number. A cheap spindle can show 0.05 mm of runout at the collet, which doubles the effective chipload variation. Measure it with a dial indicator before you trust any tolerance claim.

Good candidates share a few traits: flat parts, soft material, generous tolerances, and features that are mostly 2D. Cabinet panels, signs, jigs, fixtures, model boat frames, acrylic display stands and prototype enclosures all fit. These parts tolerate a few hundredths of a millimetre of variation without failing.

Marginal candidates are aluminium brackets, heat sinks and thin plates. They can be cut on a router with the right spindle, but the finish will need deburring and the flatness will depend on how well you tram the spindle to the bed. Expect to spend time on setup for every new job.

Parts that do not fit are hardened steel, stainless, titanium and anything with a press-fit bore, a thin wall under 1 mm, or a tolerance tighter than about ±0.05 mm. A router cannot hold those numbers because the frame moves under load. No amount of tuning removes that.

The useful rule is this: if the part can be measured with a tape and a square, a router is fine. If it needs a micrometer and a bore gauge, it belongs on a machining centre.

A kit router arrives in pieces. Assembly takes a weekend, and the first cuts will be wrong. That is normal. The bed needs to be flat relative to the gantry, the gantry needs to be square to the rails, and the spindle needs to be perpendicular to the bed in both directions. Tramming is the step most builders skip.

Check tram with a dial indicator held in the collet, sweeping a 100 mm circle on the bed. A difference of more than 0.05 mm across that circle will show as a step between adjacent passes. Shim the spindle mount until it is inside that range.

Belt tension and wheel preload matter too. Loose V-slot wheels let the gantry rock when the cutter changes direction. You can feel it by pushing the gantry side to side with the motors energized. Any visible movement is lost accuracy on every corner.

Budget time for this. A hobby router that is well trammed and lightly loaded will hold about ±0.1 mm on wood. The same machine, bolted together and never aligned, will hold nothing repeatable.

The purchase price is the smallest number. Consumables add up: cutters break, collets wear, V-slot wheels develop flat spots and belts stretch. A hobby machine used daily will need a new set of wheels and a belt check within a year. Spindle bearings are the next item, and a cheap spindle is often replaced rather than rebuilt.

Dust and chip control is a real cost too. Wood dust needs extraction, and aluminium chips need a lubricant and a tray. Without them, the machine wears faster and the finish suffers. This is the part that hobby buyers underestimate.

There is also the time cost. Setting up a new job, tramming, testing a tool path and deburring can take longer than the cut itself. If the part is a one-off that must be right the first time, paying a shop is often cheaper than learning on your own machine.

That is where outsourcing fits. Keep the router for repeat flat work where the fit is loose. Send the parts with real tolerances to a shop that has the spindles, the metrology and the tool changers to hold them.
