PMMA is a brittle thermoplastic. There is no plastic zone ahead of the tool tip the way there is in aluminium or POM. The edge either cuts or it fractures. Every parameter question comes back to that one fact: you are managing crack initiation, not chip flow.

Cutting generates heat, and PMMA conducts heat poorly, so the heat stays at the edge instead of spreading into the part. Above roughly 80 °C the material starts to soften and smear. Above 105 °C it deforms under its own clamping load. By the time a tool looks like it is melting its way through, the surface is already ruined.

The second mechanism is residual stress. Cast acrylic sheet is not stress-free out of the box. Machining removes material from one side and unbalances the internal stress field, which is why a part that measures flat on the machine can bow overnight or develop fine hairline crazing along a radius. This is the slow failure that catches most first-time buyers.

So the process is really two jobs at once. Keep the edge cool enough to cut cleanly, and keep the stress balance close enough that the part stays where you machined it. Everything below is a way of doing one of those two things.

• 1
  Brittle, not ductileNo built-up edge to absorb shock, so tool sharpness matters more than coating.
• 2
  Low conductivityHeat concentrates at the contact point; air blast does more than flood coolant.
• 3
  Built-in stressRemoving stock releases it. Symmetrical stock removal keeps the part flat.

Cast acrylic is made between glass plates, so it has higher molecular weight and a more uniform structure. It machines to a cleaner edge, polishes to optical clarity, and behaves predictably under solvent bonding. Extruded acrylic is cheaper and comes in tighter thickness tolerance, but it smears more readily and crazes faster around a machined hole.

For a light pipe, a sight glass, a fluid manifold or a display cover, cast is worth the material premium. For a spacer, a jig plate or an internal bracket where nobody looks at the surface, extruded is fine and saves money.

PMMA is the wrong choice when the part will see impact, alcohol or ketone-based cleaners, or sustained load above about 60 °C. Polycarbonate takes impact far better but scratches easily and costs more. For chemical resistance, look at PP or PVDF. We would rather tell you this at the quotation stage than machine a part that fails in the field.

We machine PMMA on the same 3-axis, 4-axis and 5-axis centres we use for metals, up to 4,000 mm of travel. Clear plastics demand different tooling and different feeds, not different machines. Tooling is where the money is saved or lost.

• 1
  CastOptical clarity, clean edges, good bonding. Best for transparent functional parts.
• 2
  ExtrudedCheaper, tighter thickness, smears more. Fine for non-visible brackets.
• 3
  PolycarbonateSwitch when impact resistance matters more than scratch resistance.
• 4
  Not PMMAAvoid solvents, ketones, sustained heat above 60 °C or repeated impact.

Use two-flute solid carbide end mills with polished flutes and a high rake angle, uncoated. Coatings are designed for steel and hold heat at the edge, which is the opposite of what PMMA needs. A sharp uncoated cutter with a mirror-polished flute evacuates chips and runs cooler.

For roughing, a single-flute or two-flute cutter at 8,000–12,000 rpm with a chipload of 0.10–0.20 mm per tooth works well on cast sheet. Depth of cut around 0.5 × tool diameter keeps radial engagement low. Climb milling gives a better wall finish because the tooth enters at maximum chip thickness and leaves cleanly.

For finishing passes, step over 5–10% of tool diameter and keep the chipload above 0.05 mm per tooth. Too light a chip rubs instead of cutting, which generates heat and burnishes the surface. This is the most common mistake we see in customer-supplied programs.

Cooling is air or a light mist of clean compressed air. Flood coolant on PMMA can leave water marks and, if the coolant contains alcohol or glycol, promotes crazing. If the chip comes off as a fine powder rather than a clean flake, the tool is rubbing and the feed is too low.

• 1
  Roughing8,000–12,000 rpm, 0.10–0.20 mm/tooth, 0.5 × D depth.
• 2
  Finishing5–10% stepover, chipload above 0.05 mm/tooth.
• 3
  CoolingCompressed air or light mist. Avoid alcohol-based coolant.
• 4
  NeverDo not dwell in the cut. Stopping mid-pass burns a mark into the wall.

Transparent parts show every clamp mark. Vacuum fixtures on a flat plate are the default for thin sheet and flat covers, because they hold the part uniformly and leave no local pressure points. For thicker blocks, machine soft jaws from POM or aluminium with a conformal pocket so the load spreads over a large area.

Never clamp directly on a face that will stay visible. Even a light bite from a hardened jaw leaves a mark that polishing cannot fully remove, because the damage goes below the surface. Clamp on a sacrificial margin and cut it off in a later operation.

Stress relief matters for parts with tight flatness or a large open area. Rough the part, leave 0.5–1.0 mm of stock, then anneal before finishing. A typical cycle for cast PMMA is a slow ramp to 80 °C, a hold of 2–4 hours depending on section, then a controlled cool of no more than 10 °C per hour. Rushing the cool is how you reintroduce the stress you just removed.

Even without annealing, symmetrical stock removal helps. Take equal amounts from both faces where the geometry allows. A part machined 3 mm from one side and 0.2 mm from the other will cup toward the heavily machined face every time.

• 1
  Vacuum firstBest for flat sheet; no local pressure and no visible marks.
• 2
  Conformal soft jawsFor blocks. POM or aluminium, cut to the part profile.
• 3
  Rough, anneal, finish80 °C hold, then cool under 10 °C per hour.
• 4
  Balance the cutsUneven stock removal equals uneven stress relief.

A machined PMMA surface comes off the tool at roughly Ra 1.6–3.2 μm and looks hazy. Fine finishing with a small stepover gets to Ra 0.8–1.6 μm, which is acceptable for many industrial covers and light guides. Going below that with the cutter alone is slow and rarely worth it.

For true optical clarity, the part is machined to Ra 0.2–0.8 μm, then flame-polished or vapour-polished. Flame polishing passes a controlled hydrogen-oxygen flame across the surface and melts a microscopic layer, which removes tool marks and leaves a glass-clear finish. It works on edges and simple curves, not on deep pockets or fine internal features.

Vapour polishing uses solvent vapour in a closed chamber and gives a more uniform result, including inside small features. It also softens sharp edges slightly, so it is a poor fit for parts that need a crisp functional edge or tight dimensional tolerance held after polish.

If the part needs printed identification, laser marking works on PMMA with a minimum character height of 1.5 mm. Engraved and paint-filled characters are more durable but break the optical surface, so most transparent parts use a frosted laser mark instead.

• 1
  As machinedRa 1.6–3.2 μm. Fine for internal or non-optical surfaces.
• 2
  Fine machinedRa 0.8–1.6 μm. Good for covers and light guides.
• 3
  Flame polishedGlass-clear on edges and open curves. Not for deep pockets.
• 4
  Vapour polishedUniform, reaches internal features, softens sharp edges.
