Silicone 3D Printing: How the Process Works and Where It Stops
Silicone 3D printing builds soft parts from a liquid or paste that has to cure, not melt and freeze. This complete explainer covers the three main routes, what each one can hold in tolerance, and the point where a machined mold or a CNC part makes more sense.
In this article
- 1
- 2
- 3
- 4
- 5
- 6
- 7
What silicone 3D printing actually is
Silicone 3D printing is additive manufacturing where the build material is a silicone elastomer rather than a thermoplastic. That single change drives everything else. A thermoplastic is printed hot, then freezes solid as it cools. Silicone arrives as a two-part liquid or paste, is shaped at room temperature, then crosslinks into a rubber network. You cannot re-melt it afterward, so every error is permanent.
The chemistry matters for design work. Most printable silicones are platinum-cure addition-cure systems, which release no byproducts and shrink very little, typically under 1%. Condensation-cure and tin-cure systems are cheaper but give off alcohol or acetic acid and shrink more. For a part that must fit a machined housing, platinum cure is the safer bet.
Curing is the second constraint. A printed bead stays soft until the network locks. Until then it sags under its own weight, so overhangs and tall thin walls need either support material, a support bath, or a geometry that carries itself. This is why silicone 3D printing looks less like FDM than like dispensing icing on a cake.
The printed result is anisotropic to some degree. Layers bond chemically, but the bond line is still a weak plane. Tear propagation tends to follow layer boundaries, so a part loaded in peel or tension across layers will fail earlier than a molded one. Plan the print orientation around the load direction, not around build speed.
The three routes: DIW, vat and powder
Direct ink writing (DIW) is the most common silicone 3D printing method. A syringe or progressive-cavity pump pushes uncured silicone through a nozzle, usually 0.2-1.0 mm inner diameter, and the bead is laid down layer by layer at 0.2-0.5 mm layer heights. Print speed runs 5-30 mm/s depending on viscosity and nozzle size. DIW handles filled silicones well, including fumed-silica-thickened and thermally conductive grades.
Vat photopolymerization for silicone is less direct. True silicone is not photo-curable in the way a resin is, so most vat routes print a silicone-containing photopolymer or a sacrificial scaffold that is later filled with silicone and dissolved. Resolution is excellent, often 50-100 μm in XY, but the final chemistry is a hybrid, not a pure elastomer. Check the datasheet before you assume Shore hardness or biocompatibility.
Powder routes such as SLS do not print silicone itself in any common commercial form. What they print is a thermoplastic elastomer (TPE) or TPU powder that behaves like rubber but melts. If your requirement is simply a soft, flexible part and not silicone chemistry, SLS TPE is often faster and needs no support. If the requirement is silicone by name, for example a medical silicone specification, SLS will not satisfy it.
Pick the route from the requirement, not the marketing. Need a filled, high-viscosity silicone with real chemical resistance? DIW. Need fine surface detail on a small part and can accept a hybrid material? Vat. Need a soft part this week and chemistry is flexible? SLS TPE.
Design rules that decide success or scrap
Minimum feature size tracks nozzle diameter. With a 0.4 mm nozzle, treat 0.8 mm as the practical minimum wall and 0.5 mm as the minimum isolated rib. Below that the bead is thinner than it is wide and the extrusion becomes inconsistent. Fine details under 0.3 mm belong to vat processes, not DIW.
Overhangs are the hard limit. DIW can usually hold 45° from vertical without support if the silicone is thixotropic. Past 60° you need a support bath, a sacrificial support, or a redesign. A common fix is to chamfer the underside or split the part so each half prints with the overhang facing the build plate.
Draft and shrinkage matter when the printed silicone part must fit something else. Platinum-cure silicone shrinks roughly 0.5-2% linearly, and the mold or bath it was printed into adds its own tolerance. For a gasket that seats in a machined groove, specify the groove from the cured silicone dimensions, not the CAD model. Add 0.2-0.4 mm clearance on mating faces unless the part is meant to compress.
Wall thickness also sets feel. A 1 mm wall in Shore 40A feels firm; the same wall in Shore 20A feels floppy. Durometer and geometry trade against each other, so define hardness and thickness together. Printing a stiff geometry in a soft silicone rarely gives the spring rate you expected.
Where silicone 3D printing stops being the right answer
Silicone 3D printing is a poor fit for production quantities. Each part is built serially, so a 10,000-piece run is hours of machine time per part. Once geometry is frozen, casting into a machined aluminum mold is faster and cheaper per unit, and the mold can hold ±0.005 mm on the cavity so the molded part repeats far better than a print.
It is also a poor fit when the part carries real load. Printed silicone tears along layer lines, and its compression set is usually worse than molded silicone of the same durometer. If the part is a structural bumper or a load-bearing isolator, molding or a machined elastomer insert is the safer design.
Surface finish is the other boundary. DIW leaves visible layer lines, typically 0.2-0.5 mm peak-to-valley. If the customer sees the part, or if it seals against a smooth face, that texture is a problem. A machined mold produces a surface that follows the tool path, and we can hold Ra 0.8-1.6 μm on the cavity, or Ra 0.2-0.8 μm when the seal face needs it.
Speed is not a reason to print either. A printed mold for a small silicone batch can take days, while a machined mold can start production within 24 hours of drawing approval and ship parts in 3-5 days. For a bridge batch before hard tooling, that often decides the project.
Cure, finish and inspection
Cure is not a single step. Most platinum-cure silicones need a post-cure to reach full mechanical properties, and the datasheet usually asks for 1-4 hours at 60-80 °C. Skip it and the part feels right on day one but drifts in hardness over the following week. For a seal, that drift changes the compression force.
Support removal is delicate. If you printed into a support bath, wash it out with the recommended solvent and let the part dry before measuring. If you printed sacrificial supports, cut them with a blade while the part is still slightly green, then finish the cut face. Tearing the support off cured silicone leaves a notch that will propagate.
Surface treatment options are limited compared to metal. You can tumble, brush or wipe a printed silicone part, but you cannot polish it to a mirror the way you polish an aluminum cavity. If a smooth skin is essential, print the mold and cast the silicone into it. The cavity finish transfers directly to the part.
Inspection follows the same logic. Measure hardness on the finished part, check critical dimensions after cure, and keep a first-article record. For medical or automotive programs we inspect 100% before shipment and can supply reports on request, backed by ISO 9001:2015, IATF 16949:2016 and ISO 13485:2016 systems.
How to run a silicone print project without scrap
A sequence we use when a customer brings a soft part to us.
- 1Define the function firstWrite down durometer (Shore 20A-80A), compression target and chemical exposure. These three pick the route before any CAD is opened.
- 2Check the geometry against the processWalls at 0.8 mm minimum, overhangs under 45° from vertical, no isolated features under 0.5 mm. Redesign before printing, not after.
- 3Choose the route and materialTrue silicone spec means DIW or casting. Soft part with no chemistry requirement means SLS TPE. Fine detail means vat with a hybrid.
- 4Decide print orientation from the loadKeep tension and peel loads in-plane with the layers. Rotate the part on the build plate rather than accept a weak bond line.
- 5Tune bead and cureSet nozzle 0.4-0.6 mm, layer 0.2-0.3 mm, speed 10-20 mm/s, then cure per the silicone datasheet, often 1-4 hours at 60-80 °C.
- 6Measure the cured part, not the modelAccount for 0.5-2% linear shrink. If the part seats in a machined groove, quote and inspect against the cured dimensions.
- 7Switch to a machined mold when volume appearsAbove a few hundred identical parts, a CNC machined mold holds tolerance and cuts unit cost.
Silicone 3D printing routes compared
Use this to narrow the route before you ask for a quote.
| Route | Typical resolution | Material reality | Best for |
|---|---|---|---|
| Direct ink writing | 0.2-0.5 mm layers | True silicone, filled grades | Gaskets, pads, soft seals |
| Vat photopolymerization | 50-100 μm XY | Silicone hybrid or scaffold | Fine detail, small parts |
| SLS TPE / TPU | 0.1 mm layers | Thermoplastic elastomer | Soft parts, no chemistry spec |
| Silicone casting in printed mold | Mold-limited | True silicone, any durometer | Small batches, smooth skins |
| CNC machined mold + cast | ±0.005 mm mold | True silicone, any durometer | Repeatable production runs |
| CNC machined part | ±0.005 mm | Rigid metal or plastic | When flexibility is not required |
The verdict
Print silicone for one-off soft geometry with real silicone chemistry and no tight tolerance stack. Cast into a CNC machined mold when you need repeatability, a smooth sealing surface, or more than a few hundred parts.
Common questions
Can you print true silicone on a normal FDM printer?
No. A standard FDM printer melts filament, and silicone does not melt into a printable filament that re-solidifies. You need a paste or liquid dispensing head, a syringe or progressive-cavity pump, plus a cure step.
What people call silicone filament is usually a TPU or TPE blend that behaves like rubber. It prints well, but it is not silicone chemistry and will not meet a silicone specification.
What Shore hardness can silicone 3D printing hold?
DIW covers roughly Shore 20A to 80A with off-the-shelf and filled grades. Softer than 20A gets difficult because the printed bead sags before cure. Harder than 80A is closer to a rigid plastic and usually better machined.
Tolerance on hardness is typically ±3 to ±5 Shore A points, so specify a range rather than a single number.
How tight a tolerance can a printed silicone part hold?
Tighter than most people expect is not realistic. Layer height and shrinkage dominate, so treat ±0.2 mm as a reasonable working figure on a well-tuned DIW setup, and looser on thin walls.
When a soft part must fit a machined groove, we machine the mold instead and hold the cavity to ±0.005 mm, which makes the molded silicone repeat far better.
Is printed silicone biocompatible?
It depends on the grade, not the process. Some platinum-cure silicones carry medical-grade documentation; many do not. Ask for the material certificate before assuming a printed part is suitable for skin or implant contact.
If the program is regulated, casting a certified silicone into a clean machined mold is usually the easier path to document.
Why does my printed silicone part tear at the layers?
Layer bonds are the weak plane. If the load pulls layers apart, the part fails there even when the silicone itself is fine.
Rotate the print so tension and peel loads run in-plane, increase the overlap between beads slightly, and make sure the post-cure is complete. If it still tears, the geometry wants to be molded.
When should we switch from printing to a machined mold?
When the design is frozen and you need more than a few hundred identical parts, or when the sealing surface must be smooth and repeatable. A machined aluminum mold can start production within 24 hours and ship parts in 3-5 days.
Below that volume, printing is fine for fit checks and one-off soft parts.
