Most drawings arrive with a title-block tolerance and a handful of tighter callouts. The title block is a default, not a promise. If a bore is marked Ø20 H7, that is the feature we hold; the rest of the part can move within the general band. When a buyer sends a drawing with ±0.01 mm everywhere, we usually push back, because tightening 40 dimensions when only three matter raises cost without improving function.

Ask each supplier how they decide which features get the tight tolerance. A shop that answers with a full inspection plan is different from one that answers with a machine spec sheet. Our own working limit is ±0.005 mm ( ±0.0002 in ) on critical features, measured on a CMM with the fixture still on the table when the geometry allows it.

Feature access decides the machine, not the other way around. A deep pocket with a 3 mm corner radius needs a small tool with a long reach, and long tools deflect. That is the moment a 5-axis center earns its rate: it tilts the part so the tool stays short and stiff. On a 3-axis machine the same pocket needs a special cutter and a second setup.

One more thing to settle early: datum strategy. If the drawing calls out datums that only exist after assembly, the shop has to invent a temporary datum and document it. That is normal, but it should appear on the inspection report so your quality team can follow the logic.

Machining is only the first operation. Anodizing, electroless nickel, zinc plating, powder coating, black oxide, bead blasting and laser marking all sit downstream, and each one adds handling, queue time and risk. A part that needs hardcoat anodizing cannot be re-machined after coating, so any rework must happen before the tank.

Masking is where quotes drift. If a threaded hole or a bearing seat must stay bare, someone has to mask it by hand. The more masked areas, the more labor, and the harder it is to keep the coating thickness even at the boundary. Tell the shop which surfaces are functional and which are cosmetic. It saves a round of questions.

Finish also sets your achievable surface roughness. As-machined surfaces land around Ra 1.6–3.2 μm. A high-quality cosmetic surface is Ra 0.8–1.6 μm, and fine work reaches Ra 0.2–0.8 μm. If your drawing asks for Ra 0.4 μm on an internal corner, the answer is usually a smaller stepover, a longer cycle and a higher price.

Laser marking deserves its own line on the checklist. Minimum character height is 1.5 mm in our shop. Logos with thin strokes, gradients or fine serifs do not survive the marking process. Send vector artwork with a clear minimum stroke width.

A certificate of conformance is a statement, not data. It tells you the shop believes the parts are good. What you want, at least on the first article and on any critical feature, is dimensional data with the instrument named. First article inspection, in-process checks and a final report are three different things, and a good supplier can explain where each one applies.

In-process monitoring matters on long runs. When a 4-axis mill cuts 800 identical brackets, the operator should be checking a key dimension on a fixed interval, not only at the end. If a tool wears past its limit at part 500, the last 300 parts are suspect. Ask how often the check happens and what triggers a tool change.

Before shipment we inspect 100% of parts. Raw material certificates come in with the bar stock, in-process checks happen at the machine, and the final inspection happens after finishing, because coating thickness can close a tolerance. Reports are available on request. Our qualification rate is 99.99%, which is a number we track rather than a slogan.

If your industry requires traceability, say so at the RFQ stage. Heat lot numbers, material certificates and inspection records need to be linked to the part from the beginning. Reconstructing that after shipping is expensive and sometimes impossible.

There is no minimum order quantity here. A single prototype and a 10,000+ part run use the same quotation process. The economics differ, though. On one part, setup and programming dominate the price. On 10,000 parts, cycle time and material dominate, and a dedicated fixture pays for itself within the first few hundred pieces.

Lead time has three parts: quoting, production start and shipping. Our quotation and free DFM analysis go out within 12 hours. Production can start within 24 hours of a released order and a settled drawing. Parts ship in 3–5 days for standard work. Our historical late-delivery probability is below 2%. Those are shop numbers, not a blanket promise for every geometry.

Read the quote line by line. Material, machining, finishing, inspection and freight should be separate. If a supplier quotes one lump sum, you cannot tell what happens when you change the anodize color or add a chamfer. A clear quote also names the drawing revision it was priced against, because a revision change after award is the most common cause of disputes.

Confidentiality is part of the commercial check. Uploads are handled as secure and confidential, and an NDA is available on request. If your part is a new product, sign the NDA before you send the STEP file, not after.

Certifications tell you which management systems a supplier already runs. We hold ISO 9001:2015, IATF 16949:2016, ISO 13485:2016 and ISO 27001:2022. For automotive and EV work, IATF 16949 means the process controls, traceability and change management expected by tier suppliers are in place. For medical device components, ISO 13485 covers the documentation discipline that audits look for.

ISO 27001 is less common in machine shops and more relevant than it sounds. It covers information security, which matters when you send CAD files, tooling drawings and production volumes to an overseas supplier. Design data is the part of a hardware business that leaks quietly.

Certification is not a substitute for process fit. A shop with the right certificate and the wrong machine will still struggle. Check the equipment list against your part: maximum processing size is 4,000 mm, with travels of 4,000 × 400 × 150 mm on the large frame, 750 × 1,150 × 550 mm and 600 × 600 × 600 mm on the medium frames, 500 × 500 × 450 mm and 500 × 310 × 200 mm on the compact frames, plus a Ø400 mm rotary table for 4-axis work.

We run 127 high-precision CNC machines across three plants in Dongguan and Singapore, including 16 simultaneous 5-axis centers, 12 four-axis mills, 27 three-axis machines and 16 mill-turn centers. Singapore matters for buyers who need an ASEAN shipping lane or a second source outside mainland China.
