Every additive process does the same thing: it slices a solid model into thin layers, then deposits, sinters or cures material one layer at a time. The tool never reaches into a pocket the way an end mill does. That single difference explains almost every strength and weakness of 3D printing tools.

Layer thickness sets vertical resolution. Powder bed fusion for metal usually runs 20–60 μm per layer. Material extrusion runs 100–300 μm. A thinner layer bonds better to the one below and leaves a smoother surface, but build time climbs roughly in proportion. Doubling layer thickness can halve build time and double the stair-step on sloped faces.

The bond between layers is the weak point. In metal powder bed fusion the laser or electron beam melts a shallow pool that fuses to the previous pass. If the pool is too cold, porosity hides inside the wall. If it is too hot, the melt pool sags or keyholes. Both defects sit below the skin, so a part can look perfect and still fail a leak test.

Orientation decides more than any machine setting. A cylinder printed upright is round in plan and stepped on its wall. Printed on its side, the same cylinder needs support under the whole length and often ovalizes near the overhang. There is no neutral build direction. Pick the one that puts the critical face away from supports.

• 1
  Layer height20–60 μm for metal powder bed, 100–300 μm for extrusion
• 2
  Weak planeLayer interfaces, not the bulk material
• 3
  OrientationChoose before supports, not after

Additive wins where a cutting tool cannot reach. Internal cooling channels that spiral inside an injection mold insert, conformal channels in a manifold, lattice blocks that save weight, and one-piece housings that replace four bolted parts. These are real gains, not marketing. A milled manifold with drilled cross-holes needs plugs and O-rings. A printed one is a single sealed body.

Additive also wins on low volume. No minimum order quantity means one prototype or a 10,000-part run is a production decision, not a tooling commitment. There is no mold to cut, no fixture to design, no first-article delay from a tool shop. That matters most when the design is still moving and you expect three more revisions.

The limit is not shape, it is surface and tolerance. As-printed metal surfaces usually land around Ra 8–15 μm. Internal channels keep that roughness, so flow resistance is higher than a honed bore. Printed threads are unreliable at fine pitches. A Ø6 mm H7 bore will not come off the machine at H7; it comes undersized and needs reaming or boring.

Thin walls behave differently too. A 0.4 mm wall in stainless may print fine on a good day and fail on a cold one. Below roughly 1 mm, wall thickness becomes a process variable rather than a drawing callout. Where a wall must hold pressure or carry load, design it thicker or plan a machining pass.

• 1
  Good fitConformal channels, lattices, consolidated assemblies
• 2
  Poor fitFine threads, H7 bores, mirror finishes
• 3
  Wall ruleKeep load-bearing walls above 1 mm

Metal parts must be anchored to the build plate. The laser heats a thin layer, it cools and contracts, and the shrink pulls against whatever holds it down. Supports resist that pull. They also conduct heat away from the melt pool and give the part a path to the plate. Removing them is manual work, and the marks they leave are the reason printed faces look different from machined ones.

Stress builds in the same place supports do. A long thin rib printed flat will curl at the ends. A tall column will bow. Orientation that puts the largest cross-section against the plate usually reduces curl, even if it means more support volume. Preheating the plate and the powder helps, but it does not remove the effect.

Stress relief annealing after the build is normal for metal. It relaxes the internal stresses before they become distortion during support removal or heat treatment. Skip it and a part can move 0.2 mm overnight with nothing touching it. That is the kind of shift that ruins a fixture bore.

For a machined face, plan around 0.3–0.5 mm of stock on any surface that will be cut after printing. That gives the finishing cutter something to bite and lets you hold the datum from the printed body. It is the standard way to combine additive geometry with a controlled interface.

• 1
  AnchoringSupports resist shrink and conduct heat
• 2
  Stress reliefDo it before support removal, not after
• 3
  Machining stockLeave 0.3–0.5 mm on cut faces

The practical split is simple. Additive makes the shape, subtractive makes the interface. Any face that seats against another part, carries a bearing, seals with an O-ring or takes a dowel pins needs a machined surface. Printed surfaces do not hold those callouts.

That is why hybrid routing is common on real programs. Print the body with conformal cooling, then face the mounting flange, bore the bearing seats and tap the thread inserts on a 5-axis machine. Tolerances of ±0.005 mm and finishes down to Ra 0.2–0.8 μm come from the CNC side, not the printer.

The reason is metrology as much as cutting. A printed surface has no single datum you can trust, because it varies with orientation and support contact. Once you skim a face, you have a datum. Everything downstream can be measured against it, and inspection reports mean something.

So the decision is not additive versus subtractive. It is which features need each one. Count the surfaces that must mate, seal or rotate. If that count is zero, print and ship. If it is more than zero, print then machine.

• 1
  Print onlyBrackets, ducts, covers, lattice panels
• 2
  Print then machineSealing faces, bearing bores, threaded inserts
• 3
  Finish sourceRa 0.2–0.8 μm comes from CNC, not the printer
