CNC machining is subtractive. A rotating tool is driven along a tool path calculated from your CAD model, and material leaves the stock in chips. Every dimension on the finished part is the result of a chain: the machine moves, the tool cuts, the material pushes back, the fixture holds, and the temperature drifts. Nothing in that chain is perfect, so the achievable tolerance is the sum of those small errors.

The chain matters more than any single number. A machine that positions to ±0.005 mm still cannot hold ±0.005 mm on a part that is clamped on a 0.8 mm wall and then released. Springback moves the feature after the vise opens. Good programming accepts this and leaves a light finishing pass at low radial engagement, usually 5–10% of tool diameter, so cutting force stays low and the wall does not deflect.

Material behavior is the second half. Aluminum 6061 cuts clean but moves after roughing because residual stress releases. Stainless 316 work-hardens if the feed is too light, so a 0.05 mm chip load that feels safe will actually rub and dull the edge. Titanium Ti-6Al-4V conducts heat poorly, so most of the heat goes into the tool. Feed, speed and coolant are chosen per material, not per part.

This is the honest meaning of precision CNC machining when improving part quality and design: the tolerance is a system property. Changing one element, a tool, a clamp, a roughing allowance, shifts the outcome.

• 1
  Rough then finishLeave 0.3–0.5 mm on walls and floors for the finishing pass after stress has moved.
• 2
  Control the chipToo light a feed rubs the edge and adds heat instead of removing material.
• 3
  One datum, reusedEvery operation should reference the same datum or the stack-up doubles.

A part machined in one setup has one datum. A part machined in five setups has five chances to be off. Each re-clamp adds an error from the vise, the soft jaws, the parallels and the operator's touch-off. On a 100 mm part, a 0.02 mm shift in the second setup becomes 0.02 mm of true position error on every hole drilled there, and it will not show up until inspection.

This is why 5-axis work changes the design conversation. With a Ø400 mm rotary table and simultaneous 5-axis motion, we reach angled faces, undercuts and cross-holes without re-fixturing. Features that share a functional relationship, like a bolt circle on a sloped flange, hold their position relative to each other because they were cut in the same setup.

It is not a free upgrade. A 5-axis tool is stiffer and longer, so it deflects more on deep pockets. Thin floors still chatter. If a feature sits on an accessible face, a 3-axis cut on a rigid vise is often the tighter and cheaper route. The question is not which machine is better, it is which setup keeps the fewest error sources in the chain.

The same logic applies to soft jaws and custom fixtures. Spending an hour boring a set of jaws to the part's outer profile removes a whole class of clamping distortion. For runs above a few dozen pieces, that hour pays back.

• 1
  Fewer setups, fewer errorsConsolidate features that must stay in relation to each other.
• 2
  Clamp on thick sectionsNever let the vise close on a wall you care about.
• 3
  Probe the stockIn-process probing catches a shifted blank before the whole run is scrapped.

Most quality problems we see arrive in the CAD file, not on the machine. A sharp internal corner forces a small end mill into a radius it cannot clear, so the programmer either leaves a step or spends hours with a smaller tool. Adding a corner radius of at least one third of the pocket depth removes the problem entirely and costs nothing at the design stage.

Deep pockets follow the same pattern. A pocket deeper than about four times its width needs a long, slender tool that pushes away from the cut. The result is a tapered wall. Widening the pocket, or splitting it into two shallower steps, restores rigidity. If the depth is functional and cannot change, plan for a slower cut and accept a looser tolerance on the floor.

Holes have their own rules. A drilled hole is never perfectly round or straight, so a hole used as a bearing seat or a dowel location should be reamed or bored after drilling. Threads should stop before a wall or a shoulder, and a thread relief groove saves the tap and the operator. Standard drill sizes, standard reamer sizes and standard thread pitches all shorten lead time because the tool is already on the shelf.

Tolerances deserve the same scrutiny. Stacking ±0.005 mm on every dimension of a bracket that only needs to fit a cover drives cost with no benefit. Put the tight tolerance on the two or three dimensions that carry function, and let the rest sit at general machining tolerance. Engineers who do this get better parts, not just cheaper ones.

• 1
  Radius the cornersAt least one third of pocket depth, and match the tool you expect.
• 2
  Watch depth-to-widthPast 4:1, expect deflection and plan a slower pass.
• 3
  Tolerance what movesTighten only the dimensions that carry the fit.

Surface finish is a separate requirement from dimensional tolerance, and the two interact. As-machined finishes sit around Ra 1.6–3.2 μm with visible tool marks. A high finish at Ra 0.8–1.6 μm needs a lighter finishing pass and a sharper tool. Fine finishes at Ra 0.2–0.8 μm may need a dedicated finishing operation, sometimes with a smaller stepover, and they will not survive a rough handling step afterward.

Heat treatment changes dimensions. Stress relieving, hardening and aging all move the part, often by more than the tolerance itself. The sequence matters: rough machine, stress relieve, then finish machine. If the part is hardened to 45 HRC or above, the finishing cut needs carbide or ceramic tooling and smaller depths of cut, and some features may need to be ground rather than milled.

Coating and plating add material. Anodizing builds roughly 0.005–0.025 mm per surface depending on the type, and hardcoat sits at the upper end. Electroless nickel and zinc plating do the same. A hole that must accept a 6 mm shaft cannot be machined to 6.00 mm if it will be anodized afterward. Note the coating on the drawing and specify whether the dimension applies before or after.

The practical rule: decide the finish and the treatment before the machining plan, not after. Re-sequencing a part that is already half cut is the most expensive quality fix there is.

• 1
  Rough, treat, finishMove the final cut after any thermal process.
• 2
  Allow for coatingAnodizing and plating change dimensions by 0.005–0.025 mm per surface.
• 3
  Keep marks off sealing facesBead blasting and tumbling round edges and can damage a lapped face.

CNC machining has boundaries, and knowing them saves a redesign. Internal features that cannot be reached by a rotating tool cannot be cut. A closed internal channel, a square-bottomed blind pocket with sharp internal corners, or an undercut on an internal bore all fall outside what a mill can do. If the geometry needs them, it is a casting, a printed part, or a split design that is assembled afterward.

Very thin walls are the second boundary. Below roughly 0.8 mm in aluminum and 1.0 mm in stainless, chatter and distortion become hard to control, especially on tall walls. The part may measure correctly on the bench and move once it is bolted down. If the wall is structural and must stay thin, plan for a light finishing pass on both sides and a stress relief before the final cut.

Size is the third. Our largest travel is 4,000 × 400 × 150 mm, with medium envelopes at 750 × 1,150 × 550 mm and 600 × 600 × 600 mm. A part beyond the envelope has to be split and joined, which changes the design. Checking the envelope before detailing the model is faster than discovering it at quoting.

None of these limits make CNC machining a poor choice. They define the design space, and good engineers design inside it.

• 1
  Tools need line of sightNo rotating cutter, no internal feature.
• 2
  Thin walls moveBudget for a light pass on both faces and a stress relief.
• 3
  Check the envelope early4,000 × 400 × 150 mm is the largest single setup.
