Every supplier quotes a tolerance number. Few explain how they reach it. For precise manufacturing of CNC machining, the useful question is not what the tightest possible limit is, but what the shop holds on a feature that matters: a bearing bore, a sealing face, a dowel hole. Ask for the measurement method too. A ±0.005 mm callout checked with calipers is a claim; the same callout checked on a CMM with a reported datum scheme is evidence.

Geometry decides which machine does the job. A part with undercuts, deep pockets, or features on five faces needs simultaneous 5-axis work to avoid multiple setups. Each extra setup adds stack-up error and handling time. For prismatic parts with holes on two or three faces, a 4-axis mill or mill-turn center can be faster and cheaper. Match the machine to the part, not the other way around.

Feature size and aspect ratio set a practical limit. A Ø2 mm hole that is 40 mm deep is a different risk class than a Ø20 mm bore. Tell the supplier the function of the feature, not only the dimension. If a bore carries a bearing, the roundness and surface finish matter as much as the diameter. If a pocket only clears a cable, a looser tolerance saves cycle time and money.

Surface finish is often the hidden cost driver. As-machined surfaces land near Ra 1.6–3.2 μm. A sealing face at Ra 0.8–1.6 μm usually needs a finishing pass or a secondary operation. Below Ra 0.2–0.8 μm you are into polishing or lapping territory, which adds handling risk. Specify finish only where the drawing needs it.

• 1
  ToleranceAsk for the method, not just the number: CMM, gauge, or optical.
• 2
  Setup countFewer setups means less stack-up error and shorter cycle time.
• 3
  FinishRa 0.8–1.6 μm is a reasonable sealing-face target; tighter costs more.

Aluminum alloys such as 6061-T6, 7075, and 2024 cut fast and hold tight tolerances well on a rigid machine. Stainless grades 303, 304, 316L, and 17-4PH are common for corrosion resistance and strength, but they work-harden and need careful feeds and coolant. Titanium TC4 (Ti-6Al-4V) and Inconel are harder again: low thermal conductivity, high tool wear, longer cycle times. If a part can be made in 7075 instead of titanium, it usually should be.

Part size sets the machine envelope. Large frames and plates may need travels up to 4,000 × 400 × 150 mm. Mid-size housings often fit 750 × 1,150 × 550 mm or 600 × 600 × 600 mm envelopes. Compact parts run on 500 × 500 × 450 mm or 500 × 310 × 200 mm machines, which usually gives better accuracy per dollar because the structure is stiffer. A Ø400 mm rotary table covers most round or indexable work.

Thin walls and long slender features are the usual failure points. A 1 mm wall on a 200 mm aluminum part will move during and after cutting. Ask the supplier to flag those features in DFM and suggest a sequence: rough, stress-relieve, then finish. Sometimes the right answer is to redesign the rib pattern rather than chase the tolerance.

Material certificates matter for regulated work. For medical or automotive parts, ask whether the mill certificate travels with the batch and whether traceability is kept to the heat number. That is a paperwork question, but it decides whether your part passes incoming inspection.

• 1
  Aluminum6061-T6, 7075, 2024, 6082, ADC12 for fast, stable cuts.
• 2
  Stainless303, 304, 316L, 17-4PH; expect more tool wear and slower feeds.
• 3
  TitaniumTC4 and Inconel cost more per part but hold strength at temperature.
• 4
  SizeUp to 4,000 mm on large travels; smaller machines for tight accuracy.

Lead time is where most sourcing plans break. Ask when the clock starts. A quote that arrives with DFM notes within 12 hours tells you the shop read your model. Production that can start within 24 hours of approval keeps a prototype schedule alive. Parts that ship in 3–5 days is a common window for small and mid-size runs. If a supplier promises a date without asking about material stock, treat the date as a guess.

Minimum order quantity is a real constraint for prototype teams. No minimum order quantity means you can run one piece, check it, then scale to 10,000+ parts on the same process. That path is cheaper than paying for tooling before the design is frozen. Ask whether the prototype and the production run use the same machine type and the same inspection plan. If they do not, the prototype proves less than you think.

Quote format matters as much as the price. A useful quote breaks out material, machining time, finishing, and inspection. It lists the tolerance it is quoting to and any exclusions. If the quote is a single lump number, you cannot compare it with another supplier, and you cannot see where cost will move when the design changes.

Ask about historical delivery performance, but treat it as context, not a guarantee. A shop that tracks its own late-delivery rate and shares it is more likely to flag a risk early than one that only promises speed.

• 1
  Clock startConfirm whether lead time runs from PO, drawing release, or material arrival.
• 2
  Quote detailMaterial, machining, finishing, inspection as separate lines.
• 3
  Prototype pathSame machine and inspection plan for one-off and production.

Certificates are scoped documents. ISO 9001:2015 covers a general quality management system and is the baseline for most industrial work. IATF 16949:2016 adds automotive-specific controls such as APQP, PPAP, and traceability, which matter if your part feeds a vehicle program. ISO 13485:2016 is the medical device quality standard, relevant for implants, instruments, and housings that need a controlled process. ISO 27001:2022 covers information security, which matters when you send CAD files and process data to an outside shop.

Ask which certificate covers the site that will make your part. A group certificate does not automatically apply to every plant. If your part is medical or automotive, ask how the shop handles change control: who approves a process change, and how you are notified. That is the difference between a certificate on a wall and a system in use.

Inspection should be defined before the first chip. A typical plan checks raw material on arrival, monitors critical dimensions in process, and runs a final inspection before shipment. For tight-tolerance parts, 100% inspection on the critical features is reasonable. Ask for the report format: a dimensional report, a first article inspection report, or a certificate of conformance. Agree on sampling if 100% is not practical.

Keep the inspection scope tied to function. Measuring every dimension on a drawing is slow and adds cost. Measuring the features that carry load, seal, or locate is what protects the assembly.

• 1
  ISO 9001:2015General quality baseline for most industrial parts.
• 2
  IATF 16949:2016Automotive controls: APQP, PPAP, traceability.
• 3
  ISO 13485:2016Medical device process control.
• 4
  ISO 27001:2022Information security for CAD and process data.

Finishing is often quoted late and changes the schedule. Anodizing in clear, color, hardcoat, or conductive types protects aluminum and can add wear resistance. Electroless nickel, zinc, silver, and gold plating serve different needs: corrosion, conductivity, or solderability. Powder coating and black oxide are common for steel and cast parts. Bead blasting, tumbling, brushing, and polishing change the surface before or after coating, so the sequence matters.

Laser marking is a small feature with a hard limit. Minimum character height is 1.5 mm for legible, repeatable marks. If your part number or serial needs to be smaller than that, plan a different method or a larger marking area. Marking after anodizing removes the coating; marking before coating can fill the characters. Decide the order with the supplier.

Packing and shipping need a short conversation. Ask how parts are protected, whether they are bagged individually, and how they are separated to avoid nicks. For tight-tolerance parts, a soft liner and a rigid box are standard. For heavy parts, lifting points and pallet weight limits matter for freight cost.

Confidentiality is part of the commercial terms. Uploads should be secure and confidential, and an NDA should be available before you release detailed CAD. If a supplier hesitates to sign, that is useful information.

• 1
  AnodizingClear, color, hardcoat, conductive for aluminum parts.
• 2
  PlatingElectroless nickel, zinc, silver, gold for corrosion or conductivity.
• 3
  Laser markingMinimum character height 1.5 mm; agree order with coating.
• 4
  NDAAvailable on request before detailed drawings are shared.
