Most print failures we see start in CAD, not on the machine. A model drawn as a solid block with sharp internal corners and 0.5 mm walls will print badly no matter which printer runs it. Before you draw a single feature, decide which process family you are designing for: material extrusion (FDM), vat photopolymerization (SLA/DLP), powder bed fusion (SLS, SLM, DMLS), or binder jetting. Each one builds material in a different way, so each one imposes different limits on wall thickness, overhang angle, and minimum feature size.

The reason is mechanical, not cosmetic. FDM lays a bead of molten polymer that must bond to the bead below it. SLA cures liquid resin with a laser spot, so unsupported regions sag into the vat. SLS and SLM spread a powder layer and melt it, which leaves the part supported by surrounding powder but leaves internal channels full of trapped material. Those three mechanisms produce three different sets of modeling rules.

Ask one question early: does this part need to be isotropic, or is directional strength acceptable? A bracket loaded along one axis can be oriented so the layers run perpendicular to the load. A manifold with pressure on every face cannot. That single answer usually decides whether you print the part at all, or send it to 5-axis CNC machining instead.

We often see designers model for printing and then specify ±0.005 mm on every dimension. That is a machining tolerance, not a printing one. Printed as-built tolerance depends on layer height, thermal shrinkage, and support removal, so it is looser and less predictable. Decide which dimensions actually matter before you finish the model.

Wall thickness is the first number to fix. On FDM, keep load-bearing walls at 2 mm or more, or an exact multiple of the nozzle diameter (commonly 0.4 mm) so the slicer lays full beads instead of thin, weak partial ones. SLA holds 0.5–1 mm walls well because the resin cures as a solid skin, but thin tall walls warp during post-cure. SLS and SLM need roughly 0.7–1 mm minimum in most metals and 1 mm in nylon, mostly so the part does not distort when it cools.

Overhangs are a geometry problem with a geometric fix. In FDM, surfaces above about 45° from vertical need support; below that they usually print clean. SLA tolerates 30–40° but needs drain paths. Powder processes support themselves, which is why SLS and SLM can build nested or interlocking geometry that FDM cannot. If your design has a 20° overhang on a visible face, either rotate the part in the build or add a chamfer.

Holes and slots come out undersized. A 5 mm circular hole printed in FDM typically measures 4.8–4.9 mm because the extruder rounds the top of the arc and the plastic shrinks inward. Model small holes 0.1–0.2 mm oversize, or drill them after printing if the fit matters. For SLS and SLM the shrink is smaller and more uniform, but holes under 1 mm may close entirely.

Sharp internal corners are a stress riser in the model and a print defect on the machine. Add a fillet of at least half the wall thickness at every inside corner. On metal powder parts this also reduces residual stress that can crack the part during cutting from the build plate.

• 1
  Minimum wallFDM 2 mm load-bearing; SLA 0.5–1 mm; SLS/SLM 0.7–1 mm.
• 2
  Overhang thresholdFDM 45°, SLA 30–40°, powder processes self-supporting.
• 3
  Hole compensationAdd 0.1–0.2 mm to small FDM holes; ream if fit is critical.
• 4
  Corner filletsAt least half the wall thickness at every internal corner.

Printed parts are not isotropic. In FDM, the bond between layers is weaker than the filament itself, often by 30–50% in tension. In SLM, columnar grains grow along the build direction, so fatigue life depends on whether the load runs with or across the layers. This is the single biggest difference between a printed part and a machined one, and no amount of modeling fixes it. You manage it by choosing orientation.

Orientation also drives tolerance. A flat face printed parallel to the build plate is smooth and dimensionally stable. The same face at an angle shows stair-stepping, and the effective surface roughness depends on layer height. At 0.1 mm layers you get roughly Ra 8–15 μm on a sloped surface; at 0.2 mm it doubles. If a sealing face needs Ra 1.6 μm, model it as a machining allowance and cut it later.

The third effect is support marks. Every contact point where support meets the part leaves a witness mark. Put those marks on non-critical faces by rotating the part, even if it costs build height. On a part with one cosmetic face, that decision is worth more than any tolerance callout in the drawing.

On our 5-axis and mill-turn side we routinely receive printed prototypes that need one or two critical faces machined. Designing in 0.3–0.5 mm of stock on those faces from the start saves a redesign round. When the printed part and the machined part must share a datum, model the datum as a machined feature, not a printed one.

A drawing with ±0.1 mm on every dimension doubles cost and still fails inspection, because printed tolerance is not uniform across a part. It is tighter in the XY plane and looser in Z, tighter on small features than large ones, and worse after support removal. Tolerance only the dimensions that define function: mating bores, mounting hole patterns, and any face that seals or slides.

For those critical features, decide early whether to print them or cut them. Printed bores typically run 0.1–0.3 mm under nominal and are not round within 0.05 mm. If a bearing press-fit matters, model the bore undersize and ream it, or design a separate machined insert. This is normal practice, not a workaround.

Shrinkage is the other variable. SLS nylon shrinks about 3% and the printer compensates, but the compensation is uniform and your part may not be. Long thin parts warp more than compact ones. Where length matters, break the tolerance chain: put one datum at each end and let the middle float.

For metal printed parts, we plan the finishing operations into the model. Threads print poorly below M4, so model them as pilot holes and tap afterward. Flatness on a printed metal face is rarely better than 0.1 mm over 100 mm, so any face that must seat against another gets 0.5 mm of stock and a face-milling pass.

Moving assemblies printed in place need clearance, and the clearance depends on process. FDM needs 0.3–0.5 mm between sliding surfaces; SLA can hold 0.2 mm; SLS parts come out with powder in the gaps, so 0.5 mm minimum and a way to evacuate the powder. If the joint must be tight, print the two halves separately and assemble.

Threads, snap fits, and living hinges all behave differently in printed material. Printed threads below M6 are unreliable, so model a clearance hole and use a threaded insert or tap. Snap fits need the flexure oriented so bending does not delaminate the layers. Living hinges only work in thin PP or TPU printed flat in the XY plane, and even then cycle life is limited.

Text and logos raise another issue. Raised or engraved text below about 1.5 mm character height fills in or blurs. Keep lettering at 1.5 mm or larger, and put it on a face that prints vertically so the strokes stay sharp.

Finally, consider whether the printed part is the final part at all. Many of the models we review exist to validate fit and function before tooling. In that case, model for the printing process that gives the fastest answer, not the one that matches production. Then move to CNC machining, vacuum casting, or die casting with a model that reflects that process instead.
