Four numbers describe almost every metal cutting operation: surface speed, chip load per tooth, depth of cut and the coolant you deliver. Everything else, spindle rpm, table feed in mm/min, stepover, follows from those four.

Surface speed is how fast the cutting edge travels through the material, measured in m/min. It is set by the combination of tool material and workpiece material, not by the machine size. A 3 mm end mill and a 50 mm face mill run at the same surface speed in the same aluminum; only the rpm differs.

Chip load, sometimes called feed per tooth, is the thickness of material each edge removes per revolution. It controls chip thinning, rubbing and tool deflection. Too low and the edge rubs instead of cutting, which work-hardens stainless and burns the coating off carbide.

Depth of cut sets how much axial and radial engagement the tool takes. It drives cutting force, spindle load and heat. On a light finishing pass it can be 0.1 mm; on a roughing pass in 6061 it can be 6 mm with the right cutter.

• 1
  Surface speedTool and workpiece material pair, in m/min
• 2
  Chip loadFeed per tooth, in mm/tooth; sets chip thickness
• 3
  Depth of cutAxial and radial engagement, in mm
• 4
  CoolantFlood, through-tool, air blast or MQL

On a lathe, surface speed becomes the number you care about most. Turning 6061-T6 at 300–500 m/min with a coated carbide insert is normal. Turning 316L at the same speed will destroy the insert in minutes; drop to 120–180 m/min and tool life returns.

Feed rate on a turning center is usually written as mm/rev, not mm/min. A finishing pass on stainless often runs 0.05–0.1 mm/rev; a roughing pass in mild steel runs 0.2–0.3 mm/rev. Push feed too high and you get chatter on slender shafts. Push it too low and the insert rubs.

Depth of cut in turning is radial, taken off the diameter. A typical roughing pass removes 1–3 mm per side on a rigid setup. On a long, thin part, 0.5 mm is more realistic because deflection grows with the cube of length over diameter.

Turning inserts also carry a nose radius, and that radius sets the theoretical surface finish. A 0.8 mm nose radius at 0.1 mm/rev produces a much smoother finish than a 0.4 mm radius at the same feed. If the print calls for Ra 0.8–1.6 μm, pick the nose radius and feed together.

Milling adds variables that turning does not have. Radial engagement, stepover, entry angle and tool overhang all change the load on each flute. A 12 mm end mill buried at full width cuts very differently from the same tool at 30 percent stepover.

The usual starting point for aluminum is 200–400 m/min surface speed with 0.05–0.15 mm/tooth chip load. For 4140 steel, 80–150 m/min with 0.05–0.1 mm/tooth. For titanium TC4 (Ti-6Al-4V), 40–70 m/min with 0.03–0.08 mm/tooth, and always with high-pressure coolant.

Tool overhang is the parameter people forget. A cutter hanging 4× diameter out of the holder will chatter no matter how good the speeds and feeds look on paper. Shorten the gauge length first, then tune the numbers.

On our 16 simultaneous 5-axis centers and 16 mill-turn centers, we keep a per-material cutting library so a new job starts from a proven window instead of a guess. That library is the reason a first article usually lands in tolerance without three iterations.

• 1
  Radial engagementStepover as a percent of cutter diameter
• 2
  Axial engagementDepth of cut along the tool axis
• 3
  OverhangKeep below 4× diameter where possible
• 4
  EntryRamp or helical entry beats plunging

Tool makers publish starting speeds for each material family, and those tables are a useful floor, not a target. The real ceiling depends on hardness, heat treatment and the condition of the stock.

Annealed 4140 turns and mills comfortably. The same alloy at 28–32 HRC forces you to cut surface speed by roughly 30 percent. At 45 HRC and above, you move to carbide grades with a harder coating and accept a slower cycle.

Aluminum is not one material either. 6061 machines cleanly at high speed. 7075 is stronger but more abrasive and tends to leave a gummy edge if the chip load drops too low. Magnesium AZ31B and AZ91D cut fast but demand strict chip control and no water-based coolant stagnation.

Plastics behave differently again. POM and PEEK need sharp, polished flutes and high surface speed with a generous chip load, because the failure mode is melting rather than tool wear. Heat goes into the part, not the chip.

Engineers often reach for the feed override when a part comes out wrong. Sometimes that works. Often it does not, because the root cause sits outside the cutting parameters.

Chatter that appears only on the finishing pass is usually a stiffness problem: long overhang, thin wall, weak workholding or a worn spindle bearing. Dropping the feed reduces the symptom and also slows the cycle. Fix the setup instead.

Dimensional drift across a batch points at thermal growth or tool wear, not at speed and feed. Measure the part at a stable temperature, then check the offset history in the control.

Poor finish in one direction only, for example a scalloped floor but clean walls, is a tool geometry issue. Wrong corner radius, wrong helix, or a cutter not suited to the feature. No parameter window repairs that.

• 1
  Setup issueStiffness, workholding, overhang
• 2
  Thermal issueSpindle and part growth over a batch
• 3
  Tool issueGeometry, coating, wear state
• 4
  Program issueEntry path, stepover, rest material
